- Page 1 User’s Manual – A S Heavy Loading Corner Shelf REBO Heavy Loading Corner shelf AR-HE-ERN Please follow all security measures in this user´s manual to ensure a secure use. Thank you for trusting in AREBOS.
- Page 2 User’s Manual – A S Heavy Loading Corner Shelf REBO List of contents 1. Safety Instructions ........3 1.1 Symbols ............3 1.2 General safety instructions ......3 2. Description ..........3 3. Construction ..........3 3.1 Before Assembly ..........3 3.2 Parts ..............
-
Page 3: Safety Instructions
User’s Manual – A S Heavy Loading Corner Shelf REBO Please read and save these instructions. Read through this user’s manual carefully before using product. Protect yourself and others by observing all safety information, warnings and cautions. Failure to comply with instructions could result in personal injury and/or damage to product or property. - Page 4 User’s Manual – A S Heavy Loading Corner Shelf REBO 3.2 Parts 3.3 Assembly • Assemble the first shelf support as shown in diagram. • Assemble the second and third shelf support in the same way.
- Page 5 User’s Manual – A S Heavy Loading Corner Shelf REBO • Continue with the fourth and fifth shelf support by using parts 7 and 8 as shown in diagram. • Place the shelves (9) on each level. • Fit the plastic feet (10 and 11) as shown in diagram.
-
Page 6: Technical Specifications
User’s Manual – A S Heavy Loading Corner Shelf REBO 4. Technical Specifications Model AR-HE-ERN Total load capacity: 1929 lbs (875 kg) Load capacity per shelf 386 lbs (175 kg) Number of shelves Material shelves MDF wood fiber board Material frame... - Page 7 User’s Manual – A S Heavy Loading Corner Shelf REBO Imprint Name of the product: Arebos Heavy Loading Corner Shelf Model Nr.: AR-HE-ERN Art. Nr.: 4260627421459 If this product is modified without our consent, it loses the right to any warranty.
