DOWNLOADABLE CONTROL COMMUNICATOR
1. GENERAL DESCRIPTION ......................................................................................................P.2
2. STANDARD AND OPTIONAL PARTS LIST ..........................................................................P.2
3. FEATURE DEFINITIONS .......................................................................................................P.3
4. TERMINAL DRAWING AND SPECIAL NOTES .....................................................................P.4
5. TERMINAL DESCRIPTION .....................................................................................................P.5
6. PROGRAMMING PROCEDURES & EXAMPLES ............................................................. P.6-7
7. SPECIAL APPLICATION NOTES ...........................................................................................P.8
8. USERS 1-15 ARM/DISARM CODE ENABLING .....................................................................P.9
9. AVAILABLE ZONE TYPES.................................................................................................... P.15
10. PROGRAMMING THE AUXILIARY OUTPUTS .................................................................. P.22
11. PROGRAMMING FOR PARTITIONS ................................................................................. P.25
12. PROGRAMMING WORKSHEETS ................................................................................. P.38-45
13. APPENDIX 1, 2, & 3 ............................................................................................................. P.46
14. SPECIFICATIONS & WARRANTY ..................................................................................... P.50
DIRECT ALARM SUPPLIES CONDELL PARK NSW
SERVICE / TECHNICAL (02) 97092811 OR 1 800 252213
DL-250
INSTALLATION MANUAL

TABLE OF CONTENTS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DL-250 and is the answer not in the manual?

Questions and answers

Related Manuals for DAS DL-250

Summary of Contents for DAS DL-250

  • Page 1: Table Of Contents

    DL-250 DOWNLOADABLE CONTROL COMMUNICATOR INSTALLATION MANUAL TABLE OF CONTENTS 1. GENERAL DESCRIPTION ......................P.2 2. STANDARD AND OPTIONAL PARTS LIST ................P.2 3. FEATURE DEFINITIONS .......................P.3 4. TERMINAL DRAWING AND SPECIAL NOTES ..............P.4 5. TERMINAL DESCRIPTION .....................P.5 6. PROGRAMMING PROCEDURES & EXAMPLES ............. P.6-7 7.

  • Page 2: General Description

    General Description The DAS DL250 is a versatile 8 expandable to 16 zone security control. Its microcomputer design gives some of the most versatile, yet easy to use features available for most security applications today. Some of the features of the DL250 include;...

  • Page 3: Feature Definitions

    FEATURE DEFINITIONS Smart Buss The DL250 must be converted from the Standard Buss to a more advanced communication buss protocol called “Smart Buss” when Partitioning and or Expansion devices are utilised. When the DL250 is set to Smart Buss, only Smart Buss compatible code pads and accessories can be used.

  • Page 4: Terminal Drawing And Special Notes

    TERMINAL DRAWING & SPECIAL NOTES...

  • Page 5: Terminal Description

    TERMINAL DESCRIPTION TERMINAL # DESCRIPTION 1 - 4 Connect Code Pad wires as follows; Yellow to terminal 1, Green to terminal 2, Black to terminal 3, and Red to terminal 4. Maximum run with 7/020 cable is 70 metres. Maximum run with 14/020 cable is 120 metres.
  • Page 6 PROGRAMMING The DL250 can be placed into the "Program" mode by use of the new FS4610 Smart Programmer, or the original FS4597 programmer, or for Code Pad programming, by utilising the FS4534 LCD Code Pad (the preferred method) or the FS4531 LED Code Pad.
  • Page 7 PROGRAMMING EXAMPLE - FIGURE 2 DIAGRAM MUST BE CHANGED TO- “MAXIMUM OF 4 CODE PADS PER SYSTEM”...

  • Page 8: Special Application Notes

    SPECIAL APPLICATION NOTES 12 Volt Siren/Piezo and Strobe Connections For The DL250 Horn Speaker Connections For The DL250 Box Tamper Diagram 1 x 8 Ohm 30-40 Watt speaker is connected directly across terminals 25 & 26. Code Pad Dip Switch Settings For The DL250 Telecom Mode 3 Connections...

  • Page 9: Partitioned Systems

    LOCATIONS 000-003: PROGRAMMING THE MASTER ARM/DISARM CODE Locations 000-003 contain the master arm/disarm code (user number 1). Location 000 contains the first digit of the code; location 003 contains the fourth digit of the code. THE CODE MUST CONTAIN FOUR (4) DIGITS. The master code can then be used in the RUN mode to enter arm/disarm codes 1 - 15.
  • Page 10 LOCATIONS 080-094: AUTHORISATION LEVEL FOR CODES 1-15 Locations 080-094 can be used to control the arming and disarming authority of the individual arm/disarm codes. A code can be given limited authority by programming a number from 1 to 15 in the corresponding location for that code. Add the values in the table below that correspond to the desired arm/disarm characteristics, and program the sum in the appropriate locations.
  • Page 11 LOCATION 118: PRIMARY FORMAT The primary format is transmitted when the primary phone number is dialled. Select a format from below, and program the appropriate number in this location. DATA FORMAT DESCRIPTION LOCAL ONLY COMMUNICATOR IS DISABLED ADEMCO CONTACT ID DTMF FORMAT ADEMCO 4/2 EXPRESS DTMF FORMAT...

  • Page 12: Split Reporting

    LOCATIONS 135-139: SECONDARY ACCOUNT CODE Locations 135-139 contain the account code for phone #2. The second account code can be programmed as per the primary account code. This account code is reported when partition two is programmed or split or dual reporting is enabled. If the account code is three digits long, use locations 135, 136, and 137.
  • Page 13 LOCATION 147: NUMBER OF RINGS TO ANSWER A DOWNLOAD CALL Location 147 contains the number of rings a DL250 must detect before answering the telephone when initiating a download session. If a number from "1" to "15" is entered in this location, the DL250 will answer after the number of rings entered in this location times two (2) has been detected ("1"...
  • Page 14 LOCATION 152: PRIMARY ENTRY TIME Location 152 contains the number of 5 second increments in the entry delay. The entry delay can be programmed in 5 second increments from 5 to 75 seconds ("1" = 5 seconds through "15" = 75 seconds). For example, programming a "2" in this location will produce an entry delay of 10 seconds.

  • Page 15: Available Zone Types

    LOCATION 158: TWIN TRIP ZONE SOUNDER CONTROL Location 158 controls the audible characteristic of the DL250 for the twin trip activation refer to location 183-190 for further detail on a twin trip zone type, Twin trip zones are also individually enabled in locations 183-190. The audible characteristic programmed will be activated when the first trip occurs on a twin trip zone.
  • Page 16 Locations 167 - 174 are used to assign zone characteristics for zones 1 through 8. Location 167 is for zone 1 and location 174 is for zone 8. Each zone can have any or all of the following characteristics regardless of the zone type selected in locations 159-166 excluding Fire zones, which cannot be Isolated.
  • Page 17 LOCATIONS 183-190: REPORTING / SPECIAL CHARACTERISTICS FOR Zones 1-8 Locations 183-190 are used to assign communicator characteristics to individual zones 1 through 8. Location 183 is for zone 1, and location 190 is for zone 8. Each zone can have one, or a combination of these characteristics. Factory default for all zones is (1 + 2 = "3").
  • Page 18 LOCATION 195: RESTORE / SIREN CONTROL Location 195 is used to assign the restore/siren control characteristic for the DL250. If immediate restore (Value = 1) is enabled the DL250 will report communicator event restores as they occur, if the restore communicator code in location 332 is selected and Report limited to once per arming (Value = 4) in this location is not enabled.
  • Page 19 LOCATION 198: BELL TEST CONTROL Location 198 is used to assign the BELL TEST Control characteristics for the DL250. There are four options in this location, each of which will cause a siren output on a different system condition. You are able to program one of these options or any combination of.
  • Page 20 LOCATION 204: SILENT ENTRY ENABLE Programming a "1" in location 204 will disable the pre-alarm during entry delays. The silent entry time applies to all entry/exit and Partial Arm zones. Factory default for this location is "0", making the entry delay pre-alarm audible. LOCATION 205: PARTITION SIREN INHIBIT / CONTACT I.D GROUP DIGIT REPORTING Factory default is "0"...
  • Page 21 LOCATION 214: CHIME TIME Location 214 is used to program the Chime activation time. The number programmed in this location represents the amount of time that the Chime sounder will remain activated. This duration time is selectable in 1 second increments from 1 to 14 seconds.
  • Page 22 Locations 220 through 235 control the output options for the four auxiliary outputs. Each of the four outputs have four individual programming locations that will be referred to in this section as DATA 1, DATA 2, DATA 3, and DATA 4. There are 60 events or conditions that can be programmed to activate these four auxiliary outputs.
  • Page 23 DESCRIPTION OF EVENT DATA 3 DATA 4 CATEGORY EVENT Activation of "BURGLARY SIREN" “1" "ANY SIREN" “2" "ARMED WITH ISOLATED ZONE(S)" “3" "ALARM MEMORY" “4" "LOW BATTERY" “5" "ENTRY DELAY TIME" “6" "EXIT DELAY TIME" “7" "ENTRY AND EXIT DELAY TIME" “8"...
  • Page 24 LOCATION 240-243: AUXILIARY OUTPUT CLOSING WINDOW To enable the auxiliary output to activate on a pre-determined time a 24 hour (military) closing time must be programmed into locations 240-243. For example, to enter a closing time of 6:30pm (18:30) program a "1" into location 240, an "8" in location 241, a "3"...

  • Page 25: Programming For Partitions

    PROGRAMMING FOR PARTITIONS Locations 246, 247 and 248 are used to program and control the DL250 partition feature. The number of zones in partitions 1 and 2, can be programmed in locations 247 and 248 with the remaining zones automatically assigned to the next numerical partition, which would be 3 if both locations are programmed.
  • Page 26 COMMUNICATOR CODES Each of the following communication codes contain four (4) locations referred to as Data 1, Data 2, Data 3 and Data 4. The first three locations are used for either enabling or disabling and or determining the reporting channel or event number for the selected communication code.
  • Page 27 Locations 268-271 are used to control the communicator code for zone 4. Zone 4 is automatically enabled and when contact I.D is selected the default report is event "130 - Burglary" with point “04" when in alarm. Refer to appendix 1 if a different event type is required.
  • Page 28 The DL250 has the ability to report an auxiliary 2 code and activate the pulsing buzzer each time the [4] and [6] keys are pressed simultaneously on the Code Pad. The desired reporting code must be programmed into these locations. When contact I.D is selected, program Data 1 with the required event code from appendix 1 to enable this report event.
  • Page 29 The DL250 has the ability to report a low battery code to the base station when AC power has been lost and the battery has discharged down to 10.3 Volts. Low battery will also report if the dynamic battery test fails. The desired communicator code must be programmed into these locations.
  • Page 30 These locations should remain at factory default when Contact I.D and Ademco High Speed are selected. LOCATION 336: TROUBLE CODE FOR Zones 1-8 Location 336 is used to program reporting of the Trouble code for zones (1 thru 16), when Contact I.D and Ademco High Speed is selected.
  • Page 31 communicator event report and a “0" will disable the communicator event report. LOCATIONS 344-347: LATE TO CLOSE COMMUNICATOR CODE The DL250 has the ability to report a 1-3 digit late closing code to the base station, when these locations are programmed and a closing time has been programmed into locations 368-371.
  • Page 32 LOCATIONS 368-371: LATE CLOSING/AUTO ARMING TIME The Late Closing/Auto Arming Time is used to determine the Closing time, I.E. If a user Arms the DL250 after this time, the Late to Close code will be reported is enabled. User code with authorisation restriction such as “Arm Only After Closing Time”...
  • Page 33 LOCATION 377: WEEKLY AUTO TEST ENABLE Location 377 is used to select the day of the week, in which an autotest report will occur. Program a number from 1 (Sunday) to 7 (Saturday) for the day of the week to perform the autotest. The test will be performed at the hour specified in locations 380-383.
  • Page 34 LOCATIONS 388-395: PROGRAMMING THE ZONE TYPES FOR ZONES 9-16 Locations 388 through 395 contain a number identifying the characteristics of zones 9 through 16. Location 388 corresponds to zone 9 and location 395 corresponds to zone 16. These zones have been factory defaulted to instant (6) zone types. Other zone characteristics can be found in the table on page 15.
  • Page 35 LOCATION 424-427: PROGRAMMING THE COMMUNICATOR CODE FOR ZONE 10 Locations 424-427 are used to control the communicator code for zone 10. Zone 10 is automatically enabled and When contact I.D is selected, the default report is an event "130 - Burglary" with point “10" when in alarm. Refer to appendix 1 if a different event type is required.
  • Page 36 LOCATIONS 452-453: NUMBER OF ELAPSED HOURS SINCE LAST AUTOTEST Locations 452-453 sets the number of elapsed hours since the last auto test and is only used in conjunction with the “Hourly autotest interval” feature in locations 378-379 . EG If you want the Autotest to be reported at 01:30 AM every 24 hours and the current time is 12:50 PM.
  • Page 37 Locations 000-007 contain the eight digit access code the DL250 must receive from the downloading software before the panel will permit downloading to occur. The factory default code is listed in the instructions provided with the DAS download software package.
  • Page 38 ARM/DISARM CODES 1 - 15 LOCATION PAGE DESCRIPTION DATA 1 DATA 2 DATA 3 DATA 4 "DEFAULT" 000-003 USER #1 ARM/DISARM CODE "1-2-3-4" 004-007 USER #2 ARM/DISARM CODE "15" DISABLED 008-011 USER #3 ARM/DISARM CODE "15" DISABLED 012-015 USER #4 ARM/DISARM CODE "15"...
  • Page 39 DIAL ATTEMPTS LOCATION PAGE DESCRIPTION DATA "DEFAULT" DIAL ATTEMPTS FOR PHONE #1 OPT=("1" THRU "15") "6" DIAL ATTEMPTS FOR PHONE #2 OPT=("1" THRU "15") "6" PRIMARY PHONE NUMBER LOCATION PAGE DESCRIPTION PHONE NUMBER "DEFAULT" 97-104 PRIMARY PHONE NUMBER, DIGITS 1 - 8 "14"...
  • Page 40 PROGRAMMING OPTIONS LOCATION PAGE DESCRIPTION DATA "DEFAULT" NUMBER OF RINGS TO ANSWER DOWNLOAD CALL OPT=("0" THRU "15") "0" DISABLED ANSWERING MACHINE DEFEAT OPT=("0" THRU "3") RINGS "0" DISABLED TELEPHONE LINE MONITOR OPT=("0" THRU "7") "0" DISABLED TELEPHONE LINE MONITOR DELAY OPT=("0" THRU "15") 10 SEC INC "0"...
  • Page 41 REPORTING CHARACTERISTICS FOR ZONES 1-8 LOCATION PAGE DESCRIPTION DATA "DEFAULT" ZONE #1 - REPORTING CHARACTERISTICS "3" ZONE #2 - REPORTING CHARACTERISTICS "3" ZONE #3 - REPORTING CHARACTERISTICS "3" ZONE #4 - REPORTING CHARACTERISTICS "3" ZONE #5 - REPORTING CHARACTERISTICS "3" ZONE #6 - REPORTING CHARACTERISTICS "3"...
  • Page 42 AUXILIARY OUTPUT OPTIONS LOCATION PAGE DESCRIPTION DATA 1 DATA 2 DATA 3 DATA 4 "DEFAULT" 220-223 AUX PIN #1 "0 - 0 - 1 - 2" 224-227 AUX PIN #2 "0 - 15 - 1 - 2" 228-231 AUX PIN #3 "0 - 0 - 1 - 10"...
  • Page 43 COMMUNICATOR CODES LOCATION PAGE PAGE PAGE "DEFAULT" AC POWER RESTORE COMMUNICATOR CODE "1" LOW BATTERY RESTORE COMMUNICATOR CODE "1" AC POWER FAIL REPORT DELAY "5" RESERVED "0" RESTORE CODE FOR ZONES 1-8 "1" RESTORE CODE FOR ZONES 9-16 "0" ISOLATE CODE FOR ZONES 1-8 "1"...
  • Page 44 PROGRAMMING EXPANSION DEVICES LOCATION PAGE DESCRIPTION DATA "DEFAULT" NUMBER OF EXPANSION DEVICES OPT=("1" THRU "7") "0" DISABLED EXPANDER TROUBLE COMMUNICATOR CODE "0" DISABLED EXPANDER TROUBLE PHONE SELECTOR "1" EXPANDER TROUBLE RESTORE COMMUNICATOR CODE "0" DISABLED ZONE TYPES FOR ZONES 9 -16 LOCATION PAGE DESCRIPTION...
  • Page 45 COMMUNICATOR CODES FOR ZONES 9 -16 LOCATION PAGE DESCRIPTION DATA 1 DATA 2 DATA 3 DATA 4 "DEFAULT" 420-423 ZONE # 9 COMMUNICATOR CODE "3 - 0 - 9 - 5" 424-427 ZONE #10 COMMUNICATOR CODE "3 - 1 - 0 - 5" 428-431 ZONE #13 COMMUNICATOR CODE "3 - 1 - 1 - 5"...
  • Page 46 APPENDIX 1 This document lists the event reporting codes for Contact ID reporting in the DL-250. The event codes are programmed by placing a number from 0-15 in the "100's" location of the communicator code for the event being reported. The 10's and 1's digit programmed are sent as the zone identifier.
  • Page 47 APPENDIX 2 This document describes the DL-250 reporting event codes when using the SIA format (format 14). The following codes are programmable and are sent when the 100's digit is programmed as the event code. The 10's and 1's digit are then sent as a zone identifier.
  • Page 48 Included in these overrides is the ability to call and report to a personal pager. The timer adjustment options allowed in locations 250 and 255 sometimes can compensate for substandard, or older telephone exchanges. It is suggested that you call DAS technical assistance the first time you attempt to use these override options.
  • Page 49 NOTES...

  • Page 50: Specifications

    DEFECTIVE PARTS AND WORKMANSHIP FOR TWENTY-FOUR (24) MONTHS FROM DATE OF PURCHASE. IF ANY DEFECT APPEARS DURING THE WARRANTY PERIOD RETURN IT TO DAS, POSTAGE PREPAID. THE UNIT WILL BE REPAIRED AND RETURNED. DAS ASSUMES NO LIABILITY FOR CONSEQUENTIAL OR INDIRECT DAMAGE AND ACCEPTS NO RESPONSIBILITY FOR REPAIRING DAMAGE TO THE PRODUCT CAUSED BY MISUSE, CARELESS HANDLING, OR WHERE REPAIRS HAVE BEEN MADE BY OTHERS.
