Portable Air Conditioner
COOLING
10,000 BTU
Model No.
COOL 410
Rollibot.com
USER MANUAL
In order to continue serving our customers and providing the best products, our product information including our user
manuals may receive updates from time to time. Please check our website for the latest user manuals and product materials.
Advanced Remote Technology-
Turn it on and o from anywhere!
R32

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the COOL 410 and is the answer not in the manual?

Questions and answers

Summary of Contents for rollibot COOL 410

  • Page 1 Portable Air Conditioner COOLING 10,000 BTU Model No. COOL 410 Rollibot.com Advanced Remote Technology- Turn it on and o from anywhere! USER MANUAL In order to continue serving our customers and providing the best products, our product information including our user...
  • Page 2 Customer Service: 1-844-585-6295...
  • Page 3 All of the unit’s features are available through the RolliCool app. After pairing your unit with your smartphone, you’ll be able to stay comfortable however you like! Thank you for being a part of the Rollibot family! — The RolliBot Team...
  • Page 4: Table Of Contents

    6.1 – How to Clean the Filters ........................20 6.2 – How to Drain the Unit ..........................20 Section 7. Storage ..............................21 Section 8. Troubleshooting ............................21 Section 9. Warranty ..............................22 9.1 – Violation ..............................22 9.2 – Information ..............................23 RolliBot RolliCOOL 410 Portable AC User Manual...
  • Page 5: Section 1. Information & Safety Warnings

    • Do not pull on the power cords or cables. • In the event that the product is malfunctioning, shut the power off immediately. • Switch off the product before cleaning. • Only use parts you have received from RolliBot or that have been included in the original packaging.
  • Page 6: Fcc Information

    For additional information about where you should drop off your RolliCool unit, please contact your local or regional waste management office, your household waste disposal service, or your point-of-sale. RolliBot RolliCOOL 410 Portable AC User Manual...
  • Page 7: Section 2. Rollicool Parts

    Window Kits RolliCool 410 Portable A/C Unit Exhaust Hose Outer Connector Exhaust Hose Inner Connector Exhaust Hose 2.2 – Components Overview Control Panel Closed Air Vents (non-oscillating) Front Housing Casters Open Air Vents (non-oscillating) RolliBot RolliCOOL 410 Portable AC User Manual...
  • Page 8: Control Panel

    Down Button: Press to lower temperature or adjust timer duration. Speed: Press to cycle through 2 fan speeds (High or Low). Mode Button: Press to cycle between cool, dehumidify, and fan modes. Power Button: Press to turn the unit on or off. RolliBot RolliCOOL 410 Portable AC User Manual...
  • Page 9: Timer Mode

    This icon will light up when the unit is in cool mode. Dehumidify Mode: This icon will light up when the unit is in dehumidify mode. • Scheduling can be done and/or adjusted via the control panel or the app. See Section 4 for information about the app. • The control panel displays Fahrenheit temperature as default, and it can be changed to display Celsius temperiature if need. RolliBot RolliCOOL 410 Portable AC User Manual...
  • Page 10: Remote Overview

    Fan Mode: Press to switch to fan mode. Dehumidify Mode: Press to switch to dehumidify mode. Cool Mode: Press to switch to cool mode. • Avoid pressing two remote buttons simultaneously as this may cause malfunctions. • Avoid using the remote in areas with extreme temperature fluctuations. • If the remote will not be used for extended periods of time, remove the battery. • The remote control’s range is approximately 23 ft. Use it within this range. • Use only two AAA batteries with the included remote. Do not mix old and new batteries or batteries from different brands. RolliBot RolliCOOL 410 Portable AC User Manual...
  • Page 11: Tips For Optimal Use

    8. Always connect the upper drainage tube when using cool or dehumidify modes. 9. Always connect the exhaust hose to the window kit for proper ventilation. 10. Keep the exhaust hose as short and free of curves as possible. 11. Do not use outdoors. RolliBot RolliCOOL 410 Portable AC User Manual...
  • Page 12: Section 3. Setting Up The Unit

    Remove the cap from the upper drainage hole. Step 3. Place one end of the draining tube in the container and connect the other end to the unit’s upper drainage hole. • If the draining tube is too stiff and/or cannot be attached, try soaking the end in hot water to soften it first. • For optimal experience, use a large container for water drainage. Container should not exceed height of the upper drainage hole. RolliBot RolliCOOL 410 Portable AC User Manual...
  • Page 13 These sections thread into one another and These parts are used to secure the sections should be placed within a window gap. together and can be loosened or tightened when adjusting the sections according to window height. RolliBot RolliCOOL 410 Portable AC User Manual...
  • Page 14: Installation

    It is recommended that the gap between the adapter and the sides of the window should be sealed off for maximum efficiency. Window Kit Window Kit Sliding Window Hung Window Slide Window Hung Window RolliBot RolliCOOL 410 Portable AC User Manual...
  • Page 15: Section 4. Wireless Setup

    Amazon Echo Family. You must have the RolliCool app on your smartphone to use Alexa with the RolliCool. 4.1 – App Installation Step1. Use your smartphone to search the Play or App Store for the “RolliCool” application. Step2. Download and install the app according to your operating system. RolliBot RolliCOOL 410 Portable AC User Manual...
  • Page 16: App Installation

    Turn on the AC unit, then turn on your smartphone’s Bluetooth. Open the Rollicool app. Step 2. Register for an account. Then sign in with your Rollicool account details on the app (fig. 1) to log in. If you already have a Rollibot account, simply log in. Step 3. Tap the “Add Device”...
  • Page 17: Amazon Alexa Setup

    (RolliCool-smart-12517). Do not use “AC”, “A/C”, “A-C”, or similar iterations, as this will interfere with some Alexa features. Most features can be used by pressing the buttons on the unit’s control panel, through Alexa voice commands, or via the Rollicool app. List of Alexa Commands: 1. “Turn on <device name>”: Powers on the RolliCool 410. 2. “Turn off <device name>”: Powers off the RolliCool 410. 3. “Set temperature to <degree>”: Sets RolliCool temperature to specified number. • Make sure Amazon Alexa app and RolliCool are connected to the same wi-fi; otherwise, Alexa may not be able to discover your AC unit. • Make sure you’re connecting to a stable wi-fi network. If your wi-fi is unstable, Alexa may disconnect and/or work correctly with your RolliCool. • You must have the RolliCool app on your smartphone to use Alexa with the RolliCool. RolliBot RolliCOOL 410 Portable AC User Manual...
  • Page 18: Section 5. How To Use The Rollicool

    3. Use the speed button to switch between fan speeds. 5.3 – Cool Mode With this mode, the unit will turn on and regulate temperature as selected. 1. Press the power button on the control panel or remote. RolliBot RolliCOOL 410 Portable AC User Manual...
  • Page 19: Dehumidify Mode

    20minutes, the unit starts defrosting for 5 minutes and the power indicator blinking. 5. 7 – Overload Protection In the event of a power loss, to protect the compressor there is a 3-minute delay until the compressor restarts. RolliBot RolliCOOL 410 Portable AC User Manual...
  • Page 20: Section 6. Maintenance

    (~10s Beep sound) and the display’s “FL“ light will turn on to indicate the water reservoir inside is full. • Please make sure your AC unit is completely powered off before performing any type of maintenance. • If relocating the unit before draining, move it carefully so as not to spill the water inside the reservoir. • Make sure the drainage pipe has adequate space underneath for draining. If using the lower drainage opening, ensure there is a suitable area for water runoff. If using the upper drainage opening, fetch a container for water runoff before connecting the tube. • Keep the drainage cover and the water plug on at all times when not draining the unit. • When draining the unit, do not allow the power cord to come in contact with water. • During drainage, the unit may be tilted slight backwards to promote faster drainage. • Keep in mind the unit may hold more water than expected. Do not use a small container to drain. Or drain the RolliCool 410 outdoors. RolliBot RolliCOOL 410 Portable AC User Manual...
  • Page 21: Section 7. Storage

    The cooling are a lot of people; or there are Close doors and windows. effect is weak. other sources of heat nearby. The filter is dirty. Clean or replace the filter. The air inlet or outlet is blocked. Clear obstructions. RolliBot RolliCOOL 410 Portable AC User Manual...
  • Page 22: Section 9. Warranty

    Condensate water high level alarm. Empty the drain pan by removal the rubber plug. If none of the above information resolves your issue, please visit our website at www.rollibot. com or contact customer service at 1-844-585-6295. Section 9. Warranty 9.1 –...
  • Page 23: Information

    CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU. THE DURATION AND REMEDIES OF ALL IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE LIMITED TO THE DURATION OF THIS EXPRESS LIMITED WARRANT RolliBot RolliCOOL 410 Portable AC User Manual...
  • Page 24 Copyright © 2023. Rollibot, LLC. All Rights Reserved...
