Summary of Contents for rollibot ROLLICOOL COOL 100H-20

  • Page 2 Customer Service: 1-844-585-6295...
  • Page 3 All of the unit’s features are available through the RolliCool app. After pairing your unit with your smartphone, you’ll be able to stay comfortable however you like! Thank you for being a part of the Rollibot family! — The RolliBot Team...

  • Page 4: Table Of Contents

    9.2 – Information ........21 RolliBot RolliCOOL 100H-20 Portable AC User Manual...

  • Page 5: Section 1. Information & Safety Warnings

    • Do not pull on the power cords or cables. • In the event that the product is malfunctioning, shut the power o immediately. • Switch o the product before cleaning. • Only use parts you have received from RolliBot or that have been included in the original packaging.

  • Page 6: Fcc Information

    For additional information about where you should drop o your RolliCool unit, please contact your local or regional waste management o ce, your household waste disposal service, or your point-of-sale. RolliBot RolliCOOL 100H-20 Portable AC User Manual...

  • Page 7: Section 2. Rollicool Parts

    Drainage Pipe RolliCool 100H-20 Portable A/C Unit Exhaust Pipe Outer Connector Exhaust Pipe Inner Connector Exhaust Pipe 2.2 – Components Overview Control Panel Closed Air Vents (non-oscillating) Front Housing Casters Open Air Vents (non-oscillating) RolliBot RolliCOOL 100H-20 Portable AC User Manual...

  • Page 8: Control Panel

    Display: This section will light up to show temperature and other information. Power Button: Press to turn the unit on or o . Down Button: Press to lower temperature or adjust timer duration. Oscillate Button: Press to turn on or o oscillate function. RolliBot RolliCOOL 100H-20 Portable AC User Manual...
  • Page 9 • Scheduling can be done and/or adjusted via the control panel or the app. See Section 4 for information about the app. • The control panel displays Fahrenheit temperature as default, and it can’t be changed. RolliBot RolliCOOL 100H-20 Portable AC User Manual...

  • Page 10: Section 3. Setting Up The Unit

    Take out one screw base to insert it Thread section B onto the end of into one end of section A. section A and make sure the screw base is also inserted into the screw hole of section B. RolliBot RolliCOOL 100H-20 Portable AC User Manual...
  • Page 11 Slide it from right to left to t the them. When rotating the connectors, both the air vent. inner connector and outer connector rotate clockwise to secure them onto the pipe. Unfurl the pip to the necessary length. RolliBot RolliCOOL 100H-20 Portable AC User Manual...
  • Page 12 • Make sure that the machine is placed in a at position and the air outlet is not blocked • Make sure the machine is placed at least 11.8 in. (30 cm) away from the wall. RolliBot RolliCOOL 100H-20 Portable AC User Manual...

  • Page 13: Section 4. Wireless Setup

    After powered down for an extended time, the RolliCool app may not automatically sync with your RolliCool once you turn the unit back on. Wait a few minutes, then restart the AC unit. Follow the pairing steps to pair your smartphone with the unit again. Fig. 1 Fig. 2 Fig. 3 RolliBot RolliCOOL 100H-20 Portable AC User Manual...

  • Page 14: Amazon Alexa Setup

    5 GHz. (E.g., myATT24GHZ and myATT5GHZ) Be sure to select the 2.4 GHz band. Your Internet service provider combines the 2.4 GHz and 5 GHz bands into a single band with the same SSID broadcasted name). RolliBot RolliCOOL 100H-20 Portable AC User Manual...
  • Page 15 2.4 GHz band. Step 2. Complete the app pairing steps from section 4.2. With all options, when the Rollicool has been disconnected for an extended period, you may need to follow these steps again. RolliBot RolliCOOL 100H-20 Portable AC User Manual...

  • Page 16: Section 5. How To Use The Rollicool

    2. Press the mode button on the control panel until the display’s COOL light turns on. 3. Use the up and down buttons to set the desired temperature 62~86°F (16~30°C). 4. Use the speed button to switch between fan speeds. RolliBot RolliCOOL 100H-20 Portable AC User Manual...

  • Page 17: Dehumidify Mode

    3. Press the mode button on the control panel until the display’s DEHUM light turns on. You must attach the drainage hose to the upper draining opening when using dehumidify mode. In dehumidify mode, the fan speed is automatically set to low and cannot be adjusted. RolliBot RolliCOOL 100H-20 Portable AC User Manual...

  • Page 19: Section 7. Storage

    • Cover the unit to protect it from dust. Do not store in a dusty environment. As with all electronic devices, dust may cause damage over time. • Store the unit indoors at a dry and stable temperature. Do not store in an unheated garage, shed, or other locations with extreme temperature uctuations. RolliBot RolliCOOL 100H-20 Portable AC User Manual...

  • Page 20: Section 8. Troubleshooting

    Open the front air vent. The oscillator is Front air vent is closed. inside the front air vent and is vertical. When the RolliCool encounters errors, the display may show certain error codes. Refer to the table below. RolliBot RolliCOOL 100H-20 Portable AC User Manual...

  • Page 21: Section 9. Warranty

    Warranty services are provided by Rollibot Warranty Pro (“WP”). If a hardware defect arises and a valid claim is received within the Warranty Period, at its option and to the extent permitted by law, WP will: (1) repair the hardware defect by using new or refurbished parts that are equivalent to new in performance and reliability;...
  • Page 22 DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU. THE DURATION AND REMEDIES OF ALL IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE LIMITED TO THE DURATION OF THIS EXPRESS LIMITED WARRANT RolliBot RolliCOOL 100H-20 Portable AC User Manual...
  • Page 23 RolliBot RolliCOOL 100H-20 Portable AC User Manual...
  • Page 24 Copyright © 2020. Rollibot, LLC. All Rights Reserved...
