Loreme ELL100 Configuration Handbook

Pulse concentrator / remote digital inputs parallel to ethernet converter
Hide thumbs

Advertisement

Table of Contents

Pulse concentrator / remote digital inputs
Parallel to Ethernet converter
CONFIGURATION HANDBOOK
ELL100
LOREME 12, rue des Potiers d'Etain Actipole BORNY - B.P. 35014 - 57071 METZ CEDEX 3
Phone 03.87.76.32.51
Contact : Commercial@Loreme.fr - Technique@Loreme.fr
Download manual at : www.loreme.fr
REV 0.5 - 19/10/21
E 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ELL100 and is the answer not in the manual?

Questions and answers

Related Manuals for Loreme ELL100

Summary of Contents for Loreme ELL100

  • Page 1 Pulse concentrator / remote digital inputs Parallel to Ethernet converter CONFIGURATION HANDBOOK ELL100 LOREME 12, rue des Potiers d'Etain Actipole BORNY - B.P. 35014 - 57071 METZ CEDEX 3 Phone 03.87.76.32.51 Contact : Commercial@Loreme.fr - Technique@Loreme.fr Download manual at : www.loreme.fr...
  • Page 2 4-6) Table of unit ..........................p17 4.7) Command word for reset counters ..................... p17 WEB SERVER ................................p18 WIRING ................................p20 WIRING EXAMPLE ..............................p21 LOREME 12, rue des Potiers d'Etain - 57071 Metz  03.87.76.32.51 - Email: Commercial@Loreme.fr - Technique@Loreme.fr...

  • Page 3: Device Presentation

    3 and 4 The ELL100 is a module of 16 logical inputs. Divide into 4 groups of 4 inputs. The device can used for a wide possibili- ties, from simple state monitoring, via energetic or calorific counting, flow measure or control start and stop times.
  • Page 4 Measure = (pulse weight x coefficient) / delay between 2 pulses. To avoid a loss of counter in case of supply loss, the ELL100 make a backup of all counters (ON time, OFF time and total pulse count) every 5 minutes in non volatile memory.
  • Page 5 369Wh 2) Configuration The ELL100 is fully configurable via the front face. A press on “config” button access to menus. The configuration process depends on the page displayed. In page 0, the user can setting general parameters and the input parameters common to all channels if they are identi- cal (see paragraph 2.1 page 6)
  • Page 6 SOMMAIRE Remarks: In the case of energy counting (Wh, VARh, Vah) and a measurement time of hour, the ELL100 display automatically a power unit (W, VAR, VA) for the instantaneous measure. The time-out is the delay without pulse beyond which the instantaneous measurement (flow,…) is reset to zero. It is adjustable from 1 to 60 minutes.
  • Page 7  SOMMAIRE Device with /CMTCP option   Change the field value with buttons IP ADDRESS? ‘Config’ to validate and go to the next field. 192.168.000.253   Change the field value with buttons IP MASK? ‘Config’ to validate and go to the next field. 255.255.255.000 The factory configuration is 192.168.0.253 for the ip address and 255.255.255.0 for the mask.
  • Page 8 RESET COUNTERS VIA FRONT FACE The ELL100 has a function to reset to zero the counters TON and TOFF, total pulse counter, and instantaneous meas- ure for all inputs or for selected input. The choice is function of displayed page on LCD.

  • Page 9: Emc Considerations

    1) Introduction To meet its policy concerning EMC, based on the Community directives 2014/30/EU & 2014/35/EU, the LOREME company takes into account the standards relative to this directives from the very start of the con- ception of each product. The set of tests performed on the devices, designed to work in an industrial environment, are made in ac- cordance with IEC 61000-6-4 and IEC 61000-6-2 standards in order to establish the EU declaration of con- formity.

  • Page 10: Rs232 Link Setting

    Note: To modify the parameters of terminal session whereas this one is connected, it is necessary to disconnect it, mod- ify the parameters and then to reconnect it. E 10 LOREME 12, rue des Potiers d'Etain - 57071 Metz  03.87.76.32.51 - Email: Commercial@Loreme.fr - Technique@Loreme.fr...

  • Page 11: Firmware Update

    FIRMWARE LOADER Rev3 READY TO TRANSFER... The device is now in the firmware load mode and is waiting for the firmware file. This file is provide by LOREME and contain the firmware code in Intel HEX format. Select the « Transfer », « Send a text file ... » in the HyperTerminal menu.
  • Page 12 The device have a total of 161 registers for reading. The maximum registers who can be read in one request is limited to 125. Therefore at least 2 request are required for reading all registers. E 12 LOREME 12, rue des Potiers d'Etain - 57071 Metz  03.87.76.32.51 - Email: Commercial@Loreme.fr - Technique@Loreme.fr...
  • Page 13  SOMMAIRE BUS100 System The BUS100 is a modular system composed of one master (/CMTCP module. Module with Ethernet link) and slaves modules (/BUS model without Ethernet link). All modules are reachable by the Ethernet link. Each module is accessible via its own address range.

  • Page 14: Modbus Tcp Communication

    2) Read function The ELL100 have a total of 161 registers. The maximum register can be read at time is limited to 125. So, 2 reading re- quest are necessary to read the totality of the registers.
  • Page 15  SOMMAIRE 4) Table of data registers 4.1) Table for input state Register address in dec- Designation Total imal( in Hexadecimal) Words 0000 ($0000) State of input IN1 to IN16 ( bit15: IN16 ... bit0: IN01 ) 4.2) Table of TON counters in minute Register address in dec- Designation Total...
  • Page 16 0125 ($007D) Measure IN15 (Msb) IEEE 32 bits float number (Lsb) 0127 ($007F) Measure IN16 (Msb) IEEE 32 bits float number (Lsb) E 16 LOREME 12, rue des Potiers d'Etain - 57071 Metz  03.87.76.32.51 - Email: Commercial@Loreme.fr - Technique@Loreme.fr...
  • Page 17  SOMMAIRE 4.6) Tableau des units ( Unit is a suite of 4 ASCII characters either 2 words or 4 bytes ) Register address in dec- Designation Total imal( in Hexadecimal) Words 0129 ($0081) Unit IN01 Character 1 and 2 0130 ($0082) Character 3 and 4 0131 ($0083)

  • Page 18: Web Server

    SOMMAIRE WEB server The ELL100 embedded a WEB server that allows the user to see all counters via the WEB browser. Simply point to the device’s IP address to access the measurement page which looks like this : This page provides a view of all the measurements available in the device. When an input is active, the corresponding “channel status”...
  • Page 19  SOMMAIRE Important note for the BUS scan function After a scan, ensure that all slave module present on bus are detected by the master module. If not, start the scan func- tion again. It is important to understand that all modules not present on bus, will also be absent on MODBUS TCP commu- nication! =>...
  • Page 20     COVER  (lift this way)   PNP input Dry contact NO or NC Voltage input NPN input E 20 LOREME 12, rue des Potiers d'Etain - 57071 Metz  03.87.76.32.51 - Email: Commercial@Loreme.fr - Technique@Loreme.fr...

  • Page 21: Wiring Example

     SOMMAIRE Wiring example Example with dry contact polarised with ELL100 24V output ELL100 Montage avec le 0V commun Montage avec le 24V commun Example with individual voltage source for each input ELL100 “0” level : 0 V to 2 V “1”...
