Sony ICF-SW15 US Service Manual

ICF-SW15
Canadian Model
AEP Model
UK Model
E Model
Australian Model
Tourist Model
SPECIFICATIONS
Frequency range FM: 76 — 108 MHz (US, Canadian,
SW3: 9.375 — 10.025 MHz
SW4: 11.615 — 12.265 MHz
SW5: 15.00 — 15.65 MHz
SW6: 17.50 - 18.15 MHz
SW7: = 21.325 — 21.975 MHz
1stIF: 10.7 MHz
2nd IF: 455 kHz
MW: 530—1,710kHz (US, Canadian,
E, Australian, Tourist models)
531—1,602kHz (AEP, UK,
Italian, Saudi Arabia models)
IF: 455 kHz
Antenna FM/SW: Telescopic antenna
MW: Built-in ferrite bar antenna
from the DC IN 4.5 V jack and from a wall outlet.
AC power adaptor AC-E45M (not
¢ Use only the AC power adaptor AC-E45M (not supplied). Do not
use
supplied)
Battery life
Approx. 27 hours with Sony SUM-3
of,
(NS)
;
