VIU B210 Technology Manual

B210 R220 | Room Technology Guide
This room contains a TV, a built-in PC, HDMI connection for laptops and other
devices, a webcam, overhead mics, and wireless collaboration. The equipment in this
room is controlled by a wall-mounted touch panel interface.
System On
Touch the panel to wake it and
press the ON button.
If the panel is already on, use the Monitor Control on
the left side to turn the TV on.
The system starts with the PC screen displayed.
Use the PC
1. Move the mouse or press a keyboard key to wake the PC. If nothing displays on the monitor:
a. Check if the monitor power is on.
b. Check if the PC power is on.
2. Sign in with your VIU credentials.
3. Select PC on the touch panel.
4. Sound volume can be controlled from the PC and the touch panel.
Connect your own device
An HDMI cable is located at the instructor station.
1. Ensure your device is powered on.
2. Plug the HDMI cable into your device.
3. Select HDMI on the touch panel.
If the picture doesn't appear:
Windows: Press
Mac: Go to System > Preferences > Display > Arrangement > Mirror.
If you still see a black screen, toggle the Black Screen
button on the touch screen.
For assistance, contact the IT Service Desk by phone at 250-740-6300.

+ P to select a presentation option (usually Duplicate).
System Off
Press the System Off button on the
touch panel and confirm shutdown.
Wait a few seconds before powering on again.
Please turn the AV System off before leaving the
room. Sign out of the PC, but do not turn it off.
