User's Manual
Wall mount unit for Projectors
HAS-WM03
Model name
Thank you for purchasing a wall mount unit specially designed for Projectors.
Be sure to read this manual and the User's Manual supplied with the Projector before use so you will know how to
change without prior notice.

Disclaimer

incorrect use or handling that exceeds normal operating limits.

Table of Contents

Disclaimer ................................................ 1
Table of Contents ..................................... 1
Safety Symbols ........................................ 1
Overview ................................................... 2
Installation Precautions .......................... 2
Tools needed for installation .................. 2
To the customer ....................................... 3
To service personnel ............................... 3
Routine Inspections ................................ 3
Contents of this package ........................ 4
Template sheet usage .............................. 6
Adjusting arm length ............................... 7
Installation procedure ............................. 8
to the wall ............................................. 8
Attaching Adjusting block (C) .................. 9

Safety Symbols

The following symbols are used in this manual to help you use this product safely and correctly, and to prevent injury
to yourself and others or damage to property. Read through the safety instructions below so you can operate the
product correctly.
WARNING
CAUTION
This symbol indicates information that, if ignored, could result in serious personal injury
or even death due to incorrect handling.
This symbol indicates information that, if ignored, could result in personal injury or
physical damage due to incorrect handling.
Indicates a prohibited action.
This symbol is accompanied by text indicating an action that must not be taken.
Indicates a mandatory action.
This symbol is accompanied by text indicating an action that must be taken.
Removing screws ....................................11
Attaching bracket (D) ...............................11
Attaching Projector ..................................12
Connecting cables ...................................12
Adjustments ............................................13
adjustments .........................................13
Image adjustments ..................................14
Installing exterior parts ..........................17
Connecting cables ...................................19
Attaching the cable cover ....................... 20
Adjustment precautions ........................ 21
Applicable models ................................. 23
1
.................... 22

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HAS-WM03 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Maxell HAS-WM03

Summary of Contents for Maxell HAS-WM03

  • Page 1: Table Of Contents

    User’s Manual Wall mount unit for Projectors HAS-WM03 Model name Thank you for purchasing a wall mount unit specially designed for Projectors. Be sure to read this manual and the User’s Manual supplied with the Projector before use so you will know how to change without prior notice.

  • Page 2: Overview

    HAS-WM03 Overview This product is designed to mount a Projector on a wall. Installation Precautions Installation of this product requires special technical skills. Ask your dealer or service center (for details, see the User’s Manual supplied with the Projector) to handle the installation work.

  • Page 3: To The Customer

    HAS-WM03 WARNING To the customer installation work. Note that Maxell will accept no liability whatsoever for accidents or injuries resulting from an incorrect installation or improper use. when the projector is used. down or bend the arm resulting in injury or damage.

  • Page 4: Contents Of This Package

    HAS-WM03 Contents of this package Check that the items listed in the table below are included in this package. If any are missing, please contact your dealer immediately. (The fasteners (screws, etc.) required for wall mounting are not supplied with the wall mount unit.

  • Page 5: Base Bracket Attachment Diagram

    HAS-WM03 Base bracket attachment diagram Note: The wall hole center is 34.6 mm (1.36 inches) to the right of the screen center. Important dimension Screen center Install 70 mm (2.8 inches) or more away from the top edge of the screen.

  • Page 6: Template Sheet Usage

    HAS-WM03 Template sheet usage Determining location of wall holes Place the template sheet (O) where you want to project the image. Vertical orientation: Align the top of the sheet with the upper edge of the image you want to project.

  • Page 7: Adjusting Arm Length

    HAS-WM03 Adjusting arm length Arrows at the right and left sides of the template sheet (O) indicate the distance from the screen surface to the back of the projector. During rough adjustments of arm length, adjust it according to the dimension of distance from the screen surface to the back of the projector.

  • Page 8: Installation Procedure

    HAS-WM03 Installation procedure Attach the base bracket (B) to a wall using the anchor bolts (M8). The holes in the base bracket (B) are oval to permit horizontal adjustment. see “Tools needed for installation” on page 2. Refer to page 5 for instructions on attaching the base bracket.

  • Page 9: Extending The Arm Bracket (In)

    HAS-WM03 Loosen the securing screws (at the four locations indicated by the arrows in the drawing below) and extend the arm bracket. Note: Orient part as shown in the figure. Arm bracket (IN) Note: The adjusting knobs should face the direction Attach the adjusting block (C) to the arm bracket (IN) using four M4 dish screws (J).

  • Page 10: Securing Arm Bracket (Out) Using Screws

    HAS-WM03 Insert the U-groove at the bottom of the arm bracket (OUT) in the groove of the vertical adjusting nut in the base bracket. Arm bracket (OUT) Base bracket(B) Vertical adjusting nut WARNING U-groove condition. Quickly perform step (5) described below.

  • Page 11: Removing Screws

    HAS-WM03 Remove the M5 shoulder screws. M5 shoulder screw WARNING have been properly tightened. Vertical adjustment will not be possible unless the M5 shoulder screws have been removed. Attach the bracket (D) to the Projector using four M4 × 8 (G) hexagon head screws.

  • Page 12: Attaching Projector

    HAS-WM03 Attach the Projector to which the bracket (D) has been attached to the adjusting block (C). Tighten the four M4 x 8 round head screws (G). Tightening torque: 0.98 N•m (10 kgf•cm) M4 × 8 hexagon head screws(G) M4 × 8 hexagon head screws(G)

  • Page 13: Adjustments

    HAS-WM03 Adjustments Turn the projector on and project an image to make adjustments. -1. Project an image, adjust the image settings and focus on the Projector. • Adjust the focus. • Select MIRROR. • Set the D-ZOOM to its maximum value (full screen).

  • Page 14: Image Adjustments

    HAS-WM03 Adjust the image. -1. Loosen the securing screws. -2. Adjustment of image size. 1. Slide the arm forward and backward to adjust image size. The scale on the supplied template sheet information on how to use the template sheet.
  • Page 15 HAS-WM03 -3. Make a rough focus adjustment. (Green) (Red) Rear view (Blue) (Red) Rear view (Green) 1. Fine adjustment of horizontal position Green 2. Fine adjustment of horizontal keystone Blue 3. Fine adjustment of vertical keystone 4. Fine adjustment of lateral position 5.
  • Page 16 HAS-WM03 7. Fine adjustment of vertical position Note: Do not loosen these Four screws. 2. Turn the height adjusting screw to adjust the height. Supplied Allen wrench (N) See page 22 for details on adjustment range. -5. Retighten the eight previously loosened securing screws.

  • Page 17: Installing Exterior Parts

    HAS-WM03 Installing exterior parts Procedure for installing exterior parts -1. The knobs indicated by the arrows can be removed. After you have removed it, put it away in a safe place. (Green) (Red) Rear view (Blue) (Red) Rear view (Green) WARNING of their reach.
  • Page 18 HAS-WM03 -2. Attach the front cap (E) at the front end of the Arm bracket (IN). Engage the left and right claws. Attach the cable cover. Insert the two tabs (1) and (2) in the cable cover with the two holes (1) and (2) in the Projector.

  • Page 19: Connecting Cables

    HAS-WM03 Connecting cables -1. Use the cable clamp (L) to secure the cables. Cable Cable -2. Leading the cables out from the bottom Route one cable to the right and the other to the left. Side view Cable Side view...

  • Page 20: Attaching The Cable Cover

    HAS-WM03 Attaching the cable cover -1. Attach the cable cover (F) to the arm assembly (A). Engage the four claws. Leading the cables out from the top Cable Leading the cables out from the bottom How to Remove the Cable Cover...

  • Page 21: Adjustment Precautions

    HAS-WM03 Adjustment precautions Bead-type screens with a high screen gain are not suitable for this projector. Use of a matte screen with a wide viewing angle and a gain of about 1.0 is recommended. Interaction between the screen pattern and LCD pixels may result in interference fringes (moiré). This is not a malfunction.
  • Page 22 HAS-WM03 (See page 14 for adjusting procedure.) ± 20 mm (0.78 inches) ± 20 mm position (0.78 inches) (See page 16 for adjusting procedure.) 308 mm 317 mm (12.1 inches) (12.5 inches) 625 mm (24.6 inches) Description of Item Image movement...

  • Page 23: Applicable Models

    HAS-WM03 Applicable models Supported Projector models Model Screen size Projector MC-AX3006 model A MC-AX3506 Approx. 4.3kg 16:10 Approx. 4.5kg Approx. 5.8kg...
