Maxell FL-720 User Manual

Projector lens unit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User's Manual
Projector Lens Unit
FL-720 Projector Lens Unit
Model
Thank you for purchasing this lens unit for Projectors.
Prior to use, read the user manuals of both this product and your projector thoroughly and follow their instructions.
After reading the User's Manual, keep it in a safe place for future use.
This product consists of the lens mount brackets and option lens (FL-710) for Projectors.
Notice
● T hecontentofthismanualissubjecttochangewithoutnotice;thisincludestheproductspecifications.
● M axellwillnotbeliableforanyinjuriesordamageduetoimproperuseorapplicationoutsidetheintendedscope.

Table of Contents

Symbols ..................................................1
Overview.................................................2
Periodic Inspection .................................3

Symbols

This manual uses the following symbols to help you and any helpers use the product safely and according to
instructions, in order to prevent any injury or property damage. Please read thoroughly so you understand them and
use the product accordingly.
Warning
Caution
Ignoring this symbol and handling the product incorrectly may result in serious injury or
death.
Ignoring this symbol and handling the product incorrectly may result in injury and/or
property damage.
This symbol indicates prohibited actions.
The description after this symbol indicates actions that are not allowed to be performed.
This symbol indicates mandatory actions.
The description after this symbol indicates actions that must always be performed.
Mounting the Brackets ............................7
When Using on a Tabletop ...................10
(HAS-404U) ..........................................10
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FL-720 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Maxell FL-720

Summary of Contents for Maxell FL-720

  • Page 1: Table Of Contents

    User’s Manual Projector Lens Unit FL-720 Projector Lens Unit Model Thank you for purchasing this lens unit for Projectors. Prior to use, read the user manuals of both this product and your projector thoroughly and follow their instructions. After reading the User's Manual, keep it in a safe place for future use.

  • Page 2: Overview

    FL-720 Overview This product includes the lens mount brackets and option lens (FL-710) for Projectors. Important Considerations for Installation Special skills are necessary for installing this product. Be sure to ask the sales outlet or a service company (See the User's Manual of your Projector) to perform the installation job.

  • Page 3: Periodic Inspection

    FL-720 Warning To the customer: ■ T hecustomershouldneverattempttoperformtheinstallationwork.Pleasehavethesalesoutlet or service company perform the installation. Please be warned that we shall bear no responsibility whatsoever for any accidents or injuries that occur from improper installation or handling. ■ I nstallataheightwherepeoplewillnothittheirheadontheprojector.Iftheprojectorisinstalledata lowposition,beextremelycarefulwhenusing.

  • Page 4: Checking The Contents Of Packaging

    FL-720 Checking the Contents of Packaging Makesurethefollowingitemsarepackedinsidethebox.Ifsomethingshouldbemissing,contactthesalesoutletright away. Accessories Packaged with FL-720 Lens Unit Lens Mount bracket User's Manual (this manual) Option lens FL-710 Lens mount bracket...
  • Page 5 FL-720 Names of parts are indicated with codes in the table below and on subsequent pages. ●AccessoriesPackagedwithFL-720 Code Part Name Qty. Appearance Code Part Name Qty. Appearance Option lens Option Lens ( I ) (FL-710) User's Manual ●AccessoriesPackagedwithLensMountBracket Code Part Name Qty.
  • Page 6 FL-720 Removing the Packaged Items 1.RemovetheoptionlensFL-710(H)fromthebox. For details on operating the option lens FL-710 (H), refer to the Option Lens User's Manual (I). FL-710 (H) Option Lens User's Manual (I) 2.Removethemountbrackets(A)andaccessorypartsfromthebox. Mount bracket A Accessory parts...

  • Page 7: Mounting The Brackets

    FL-720 Mounting the Brackets 1. Attach the option lens FL-710 (H) to the projector. (For details, refer to the Option Lens User's Manual (I). 2. Provide a worktable so that no force is applied to the option lens FL-710 (H).
  • Page 8 FL-720 6.Usethehexkey(F)toloosenthescrew(Q)untilitstops. Screw (Q) 7. Mount the mount bracket (A) to the mount bracket (B). (Hole) Mount bracket (A) Screw (Q) Insertion direction Mount bracket (B) Protrusion...
  • Page 9 FL-720 8. Move the screw (Q) of mount bracket (A) up and down as well as left and right to insert it into the protrusion of mount bracket (B). It can be easier to insert when viewing from the top (hole) of mount bracket (A).

  • Page 10: When Using On A Tabletop

    FL-720 When Using on a Tabletop UsethefourM6×16hex-headscrews(C)toattachthemountbracket(A)totheprojector. TightentheM6×16hex-headscrews(C)intheorder to . Tightening torque: 1.96N·m (20kgf·cm)  M6×16hex-headscrews(C)   M6×16hex-headscrews(C)  9. Return the projector to its original state. Screw (Q) 10. Use the vertical and horizontal shift adjustment to adjust to the proper screen position.
