Exhausto VEX280HX Mechanical Installation Instructions

Without control system
Hide thumbs Also See for VEX280HX:

Advertisement

Quick Links

3005509-2019-09-10
VEX280HX without control system
Mechanical installation instructions
Product information........................................ Chapter 1 + 6
Mechanical assembly..................................... Chapter 2 + 3
Electrical installation.......................................Chapter 4
Maintenance...................................................Chapter 5
EXHAUSTO A/S
Odensevej 76
DK-5550 Langeskov
Tel.: +45 65 66 12 34
Fax: +45 65 66 11 10
exhausto@exhausto.dk
www.exhausto.dk
VEX280-X
Unit supplied with (factory fitted):
Rotor with standard temperature efficiency
Rotor with high temperature efficiency
Compact filters FP
Bag filter FB
Trim damper and blowout zone, TB280
OD (roof for outdoor)
The following accessories are supplied
separately:
HCW heating coil
HCE heating coil
CCW cold water coil
DX cooling/heating coil
Mounting base, MSVEX280H
Closing damper, LS600x1400, (LSA exhaust)
Closing damper, LS600x1400, (LSF outdoor)
Closing damper, LSR600x1400, with
spring-return (LSFR outdoor)
Serial no.:
Prod. order no.:
Sales order no.:
Original instructions
