Summary of Contents for golmar AIO-KEY
- Page 1 AIO-KEY StandAlone INSTALLER MANUAL IM_ENG_REV0124_AIO-KEY STANDALONE...
-
Page 2: Table Of Contents
AIO-KEY 1.INDEX 1.INDEX........................................2 2.INTRODUCTION ....................................3 3.SPECIFICATIONS ....................................3 4.PRODUCT CONTENT ..................................3 5.INSTALLATION ..................................... 4 6.CONNECTION....................................... 4 7.STANDALONE CONNECTION DIAGRAM ............................. 4 8.USERS MANAGEMENT ..................................6 8.1. USER MANAGEMENT IN READER ..........................6 8.1.1.BASIC USER MANAGEMENT IN READER ......................6 8.1.1.1.USER REGISTRATION .......................... -
Page 3: Introduction
AIO-KEY 2.INTRODUCTION Manual for the installation of the AIO-KEY reader in standalone operation. The possible identifications are: proximity, PIN, fingerprint and smartphone via TUYA APP. 3.SPECIFICATIONS Material Zinc alloy and black ABS plastic Protection degree IP-66 Input voltage 12/18Vdc Current Standby: ≤... -
Page 4: Installation
AIO-KEY 5.INSTALLATION base. Unfasten the screw at the bottom and remove the reader from the Ø 3x3mm Ø 4x6mm Drill a pair of holes in the wall (A,C) for the fixing blocks and another for the cables. 39mm Place the fixing blocks in the holes (A,C). - Page 5 USERS MANAGEMENT...
-
Page 6: Users Management
AIO-KEY 8.USERS MANAGEMENT User registrations can be made on the reader or on the smartphone through the Tuya APP: Through the reader Through mobile phone via the APP Tuya IMPORTANT: before proceeding with user registration, please note that users can’t be transferred from the reader to the Tuya APP or vice versa. -
Page 7: 2.Delete User
AIO-KEY 8.1.1.2.DELETE USER 2) Approach the card or enter the PIN or fingerprint to be registered. 1) Approach the “Master Card” card to the reader 2 times at *For PIN enter PIN of 4 to 6 digits plus #. an interval of less than 5 seconds. -
Page 8: 4.Pin Registration (Auto Id)
AIO-KEY 8.1.2.4.PIN REGISTRATION (AUTO ID) PIN registration with automatic recording. Enter administrator mode MASTER CODE * 987654 # 1 4543 # Example: 8.1.2.5.PIN REGISTRATION (SPECIFIC ID) Maximum number of records is 888. User IDs from 100 to 987. Enter administrator mode... -
Page 9: User Management In App Tuya
(IOS) IMPORTANT: - Golmar is not the developer of the Tuya APP, Tuya is a cloud platform that allows the management of IoT devices, Golmar offers the possibility to make use of the reader with Tuya technology. - The APP is supported by smartphones with iOS (7.0 or higher) or Android (4.3 or higher) version. -
Page 10: Add Reader
AIO-KEY AIO-KEY 8.2.3.ADD READER Once the above steps have been completed, the account will be created and with the session started, the APP wizard will suggest to add device. Proceed as follows: 1 - Press the “got it” option and then the “+” or “add device” symbol. -
Page 11: Users
AIO-KEY 1 - Press on the “Member manage” option located at the bottom of the main screen of the reader. 2 - Then press the “ordinary member” tab and then “+”. 3 - Enter an identifiable name in the “user name” field and enter the email address of the TUYA user in “user account”, uncheck the “administrator”... -
Page 12: Main Reader Screen
AIO-KEY 8.2.6. MAIN READER SCREEN The main screen of the reader is described below: Information/Rename Name of the reader reader Door opening from smartphone Door status Access log Management of members who use the reader. Temporary code management (one-time or temporary). -
Page 13: Pin Registration
AIO-KEY 8.2.9. PIN REGISTRATION Set a 6-digit PIN and a name to identify the registered PIN, then press “save”. 8.2.10. CARD REGISTRATION 1 - Press on the “Start add” option. 2 - Approach the card to be registered on the reader. -
Page 14: Delete Identification
AIO-KEY 8.2.12. DELETE IDENTIFICATION 1 - Select the access credential of the user to be deleted. 2 - Press the “delete” option highlighted in red. 3 - Press “confirm” to complete the deletion process. 9.TUYA APP ADDITIONAL FUNCTIONS 9.1. TEMPORAL CODE PER TIME PERIOD Press on the “temporary code”... -
Page 15: One-Time Use Temporary Code
AIO-KEY 9.2. ONE-TIME USE TEMPORARY CODE Press on the “temporary code” option located at the bottom of the device management screen. 1 - Select “One time” code type. - Name the temporary access you are about to generate. 2 - Confirmation of the generated temporary access will be displayed. In case it is desired to share the code, follow step 3 described in the previous point. -
Page 16: Reader Configuration
READER CONFIGURATION... -
Page 17: Other Settings
AIO-KEY 10.OTHER SETTINGS 10.1. IDENTIFICATION MODE Identification by fingerprint Enter administrator mode MASTER CODE * 987654 # 40 # Example: Identification by card Enter administrator mode MASTER CODE * 987654 # 41 # Example: Identification by PIN Enter administrator mode... -
Page 18: Alarm Settings (Tamper)
AIO-KEY 10.3. ALARM SETTINGS (TAMPER) Enter administrator mode MASTER CODE 5(0-3) * 987654 # 52 # Example: The tamper alarm activation time is from 0 to 3 minutes. In the example, the value 52 has been entered, so it would be active for 2 minutes. -
Page 19: Reset To Factory Settings
AIO-KEY Keyboard backlighting always off Enter administrator mode MASTER CODE * 987654 # 74 # Example: Backlit keyboard always on Enter administrator mode MASTER CODE * 987654 # 75 # Example: Keyboard backlighting automatically deactivated (factory setting) Enter administrator mode... -
Page 20: Status Displays
Black NOTE: The AP (door release) of the intercom does not activate the door opener until the pulse of the AIO-KEY reader has finished. To avoid opening delays, set the minimum pulse to 1 second on the reader: Enter administrator mode MASTER CODE www.golmar.es... - Page 21 AIO-KEY NOTES ............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................www.golmar.es www.golmar-seguridad.es...
- Page 22 AIO-KEY NOTES ............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................www.golmar.es www.golmar-seguridad.es...
- Page 23 AIO-KEY NOTES ............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................www.golmar.es www.golmar-seguridad.es...
- Page 24 Sistemas de comunicación S.A. C/ Silici 13. Poligon Industrial Famadas 08940 – Cornellà del llobregat – Spain golmar@golmar.es Tel: 93 480 06 96 www.golmar.es www.golmar-seguridad.es Golmar deserves the right for any modification without prior notice.
