WIRES
BLACK
Connect to Battery GROUND
RED
Connect to Battery +12Vdc thru +24Vdc to activate Tail
BLUE
Connect to Battery +12Vdc thru +24Vdc to activate Steady Stop
YELLOW
Connect to Battery +12Vdc thru +24Vdc to activate Flashing Stop
ELECTRICAL
Input Voltage:
12Vdc thru 24Vdc
Input Current:
R37
R46
R79
Note: Complete installation with wire rated for 125% of amperage draw
CONFIGURATION
The Revolution STT series is configured as internal flasher with active high inputs as described below.
Internal Flasher – All flash patterns are controlled by the on-board flasher.
Active High Inputs – Functionality is activated by applying +12Vdc through +24Vdc to the desired mode
wire.
(480) 497-4400 (800) 338-3133 E-mail: sales@tomar.com
Revolution
Stop/Tail Series LED Lightheads
Installation and Programming Instructions
Steady Burn
Steady Burn
Tail Mode
12Vdc
24Vdc
12Vdc
0.17 A
0.27 A
2.32 A
0.23 A
0.29 A
3.75 A
0.22 A
0.30 A
2.23 A
™
Stop Mode
24Vdc
1.34 A
2.1 A
1.35 A
www.tomar.com
IS0744A-01
09-18-2019
Page 1 of 2
