Omron Microscan Visionscape CMG03 Manual

Gige camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Visionscape GigE Camera Guide
v9.0.1, June 2018
84-100029-02 Rev M

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Visionscape CMG03 and is the answer not in the manual?

Questions and answers

Related Manuals for Omron Microscan Visionscape CMG03

Summary of Contents for Omron Microscan Visionscape CMG03

  • Page 1 Visionscape GigE Camera Guide v9.0.1, June 2018 84-100029-02 Rev M...

  • Page 2: Technical Support

    All rights reserved. The information contained herein is proprietary and is provided solely for the purpose of allowing customers to operate and/or service Omron Microscan-manufactured equipment and is not to be released, reproduced, or used for any other purpose without written permission of Omron Microscan.
  • Page 3 • All new products introduced in 2015 are expected to be WEEE & RoHS2 compliant. Omron Microscan will mark the products with the ‘CE’ marking that complies with the RoHS2 process to acquire ‘CE’ certification per the example given: Example >> Machinery directive + EMC directive + RoHS2 = Declaration of...

  • Page 4: Table Of Contents

    Contents Welcome vi PREFACE Purpose of This Manual vi Manual Conventions vi Introduction 1-1 CHAPTER 1 Product Summary 1-2 Features and Benefits 1-3 Applications 1-3 Package Contents 1-4 Visionscape GigE Camera Models 1-4 System Components 2-1 CHAPTER 2 Basic Components 2-1 Visionscape Digital I/O (DIO) 2-7 Visionscape GigE Camera I/O 2-7 Visionscape PCIe Digital I/O Boards 2-9...
  • Page 5 Contents Optics 3-1 CHAPTER 3 Optics 3-2 Connector Pinouts A-1 APPENDIX A Visionscape GigE Camera Connectors A-2 Cable Specifications B-1 APPENDIX B 98-000129-01 Visionscape GigE Camera Power M8-3 to Pigtail 5M B-2 98-000126-01 Visionscape GigE Camera Strobe/Trigger M8-4 to Pigtail 5M B-3 98-000133-01 and 98-000134-01 Cat 6 Ethernet with Jack Screws to RJ45 High Flex B-4 General Specifications C-1...

  • Page 6: Preface

    Preface Welcome PREFACE Purpose of This Manual This manual contains detailed information about how to configure and operate Visionscape GigE Cameras. Manual Conventions The following typographical conventions are used throughout this manual. • Items emphasizing important information are bolded. • Menu selections, menu items and entries in screen images are indicated as: Run (triggered), Modify..., etc.
  • Page 7 Preface Visionscape GigE Camera Guide...

  • Page 8: Introduction

    Introduction CHAPTER 1 Visionscape GigE Camera FIGURE 1–1. Visionscape GigE Camera Guide...

  • Page 9: Product Summary

    Chapter Introduction Product Summary Omron Microscan GigE cameras are a range of cameras that are designed to perform the imaging and image transmission functions in a Visionscape PC based machine vision system that uses the GigE Vision standard for image transfer.

  • Page 10: Features And Benefits

    • Power connection (8-to-30VDC) • Strobe/Trigger and Power connections are standard M8 with positive retention Features and Benefits Omron Microscan GigE Vision: • Low cost solutions for PC based machine vision • High usable bandwidth for imaging • Multiple camera support •...

  • Page 11: Package Contents

    Visionscape GigE Camera — Your package contains one of the. available GigE Camera models listed on the next page (see Table 1–1) • Omron Microscan Tools Drive • Visionscape License Key • Required accessories such as a power supply or power cable and...

  • Page 12: System Components

    System Components CHAPTER 2 This section contains information about system components as well as information to help you connect the Visionscape GigE Camera. Specific information describes connectors, adapters, cables, pinouts, signals, and network configuration. Note: There are no user-serviceable parts inside. Basic Components Table 2-1 lists the Visionscape GigE Camera hardware components.
  • Page 13 Chapter System Components Visionscape GigE Camera Hardware Components (Continued) TABLE 2–1. Part Number Description 98-000126-01 GigE Camera Strobe/Trigger M8-4 to Pigtail 5M 98-000129-01 GigE Camera Power M8-3 to Pigtail 5M 98-000133-01 Cat6 Ethernet with Jackscrews to RJ45 High Flex 2M 98-000134-01 Cat6 Ethernet with Jackscrews to RJ45 High Flex 5M I/O Boards...

  • Page 14: Front Panel

    Basic Components Front Panel Figure 2–1 shows the front C-Mount Lens threads for the Visionscape GigE Camera. Front Panel FIGURE 2–1. Rear Panel Figure 2–2 shows the layout of the rear panel which contains the RJ45 socket for the Gigabit Ethernet network connection, an M8-3 connector for power and an M8-4 connector for trigger and strobe signals.

  • Page 15: Mode/Status Leds

    Each Visionscape GigE Camera has its own label, which contains important information about that camera. • P/N – The Omron Microscan part number of your Visionscape GigE Camera. • S/N — The serial number of your Visionscape GigE Camera. •...
  • Page 16 Basic Components Mounting and Wiring the Visionscape GigE Camera • Mount the camera securely in its camera stand (not supplied). • Make sure the camera is mounted at the correct distance for the optics you’ve purchased. • Connect the Ethernet cable and the power cable to the Visionscape GigE Camera.
  • Page 17 Chapter System Components Mounting Using Base Mounting Plate You can mount the Visionscape GigE Camera using the base mounting plate that is supplied with the camera (see Figure 2–5). Base Mounting Plate FIGURE 2–5. ¼-20 threaded mounting hole 6 mm from edge Length: 47 mm Width: 36 mm Top View...

  • Page 18: Visionscape Digital I/O (Dio)

    Visionscape Digital I/O (DIO) Visionscape Digital I/O (DIO) Visionscape supports interfaces to discrete digital signals from three types of hardware. These are: • Smart cameras • Visionscape GigE cameras • Visionscape PCIe Digital I/O boards The DIO capability oft GigE cameras and PCIe boards is described below. Visionscape GigE Camera I/O Built-In Trigger Input 2 The Visionscape GigE cameras incorporate an input for a trigger signal...
  • Page 19 Chapter System Components Trigger Signal Requirements: Logic Low: 0 to 4.5 Vdc Logic High: 11 to 30 Vdc Current Input: 20ma (typical) Trigger Delay: 3usec (Minimum) Trigger Pulse Width: 2usec (Minimum) DebounceHigh: 0 to 5 usecs (User-Defined) DebounceLow: 0 to 5 usecs (User-Defined) Built-In Strobe Output The Visionscape GigE cameras incorporate an output for a strobe signal that is coordinated with image acquisition.

  • Page 20: Visionscape Pcie Digital I/O Boards

    Visionscape PCIe Digital I/O Boards Visionscape PCIe Digital I/O Boards Extended discrete digital I/O is provided for GigE/PC based systems by two PCIe (PCI Express) add-in boards. These boards both provide 16 channels in and 16 channels out of optically isolated I/O at 24 volts nominal signal level.
  • Page 21 Chapter System Components Both DIO kits are supplied with a 1.5m cable (Shielded Cable with two 37-pin D-Sub Connectors) for connection to a 32 DIN rail mount terminal strip, the dimensions of which are shown below. Visionscape GigE Camera Guide 2-10...
  • Page 22 Visionscape PCIe Digital I/O Boards The critical specification items for the two boards are listed below: 98-000142-01 98-000130-01 (Sourcing) (Sinking) Input Format Opto-isolated input Opto-coupler isolated (Compatible with current input (Compatible with source output) (Negative current sink output) logic *1) (Negative logic *1) Number of Input Signal 16 channels (all available for interrupts)(One...
  • Page 23 Chapter System Components Connector Pin Assignments are as shown below for each board. 98-000142-01 (Sourcing) 98-000130-01 (Sinking) Using Input Points for Triggering Acquisition Hardware input points located on the DIO board may be specified in the Visionscape Acquire Step to trigger acquisition. Acquisition can be specified on either the leading edge or trailing edge of a pulse.
  • Page 24 Visionscape PCIe Digital I/O Boards Digital I/O Input Response Time The response time of Visionscape to a change of an input signal is a combination of the hardware and software response times. The hardware response time for all inputs is within 200?s from voltage change on an external pin to go through the optical isolation and be received by the PC.
  • Page 25 Chapter System Components within 400?s this is calculated by taking the 200?s hardware response for inputs + 200?s software response of the two changes at 100?s each. The above diagram represents the scenario of 4 input triggers transitioning simultaneously. After the voltage goes from high to low on the pins 0-3, it can take up to 200?s for the computer to register the level of inputs 0-3 and be read as logic highs.
  • Page 26 Visionscape PCIe Digital I/O Boards Field Wiring for Current Sourcing Configurations Input Wiring The input circuits of interface blocks of the current sourcing DIO board is illustrated in the image below. The signal inputs are isolated by opto- couplers (ready to accept current sinking output signals). The board therefore requires an external power supply to drive the inputs.
  • Page 27 Chapter System Components Digital I/O Trigger Wiring As noted above, the event notification on input lines is mono-directional. Inputs 0 to 7 can be used as a low-to-high trigger only, while inputs 8 to 15 can be used as a high-to-low trigger. In cases where trigger events are needed from both edges of a signal, the signal needs to be simultaneously wired to a low-to-high sensitive input pin and a high-to-low sensitive pin as shown in the above diagram.

  • Page 28: Output Wiring

    Visionscape PCIe Digital I/O Boards Connecting a Switch Input Output Wiring Connect the output signals to a current-driven controlled device such as a relay or LED. The connection requires an external power supply to feed currents. The board controls turning on/off the current-driven controlled device using a digital value.
  • Page 29 Chapter System Components The output circuits of interface blocks of the DIO-1616RL-PE are illustrated above. The signal output section is an opto-coupler isolated output (current source type). Driving the output section requires an external power supply. The rated output current per channel is 100mA at maximum.
  • Page 30 Visionscape PCIe Digital I/O Boards Field Wiring for Current Sinking Configurations Input Wiring Connect the input signals to a device which can be current-driven, such as a switch or transistor output device. The connection requires an external power supply to feed current. The board inputs the ON/OFF state of the current-driven device as a digital value.
  • Page 31 Chapter System Components Connecting a Switch Output Wiring Connect the output signals to a current-driven controlled device such as a relay or LED. The connection requires an external power supply to feed current. The board controls turning on/off the current-driven controlled device using a digital value.
  • Page 32 Visionscape PCIe Digital I/O Boards The output circuits of interface blocks of this product is illustrated in the image above. The signal output section is an opto-coupler isolated, open- collector output (current sink type). Driving the output section requires an external power supply.

  • Page 33: External Strobe And Sensor

    Chapter System Components External Strobe and Sensor For continuous motion or high-speed indexing applications, an external strobe and sensor may be required to freeze each part before the image can be acquired. When choosing your part sensor, you must consider the time interval between the part passing into the sensing zone and an electrical signal being generated.

  • Page 34: Configuring Your Network Adapter For Gige Visionscape

    QoS Packet Scheduler Internet Protocol (TCP/IP) Some systems split internet protocol into two separate entries: TCP/IP Rev 4 and Rev 6. All Omron Microscan cameras use TCP/IP Rev 4. There may also be anti-virus filters such as “McAfee NDIS Intermediate Filter”.
  • Page 35 Chapter System Components Important: If you are using a third-party camera and you have installed that manufacturer’s control software make sure that you disable it in the Properties dialog below. It will almost certainly conflict with the JAI software that Visionscape uses to receive images from the cameras.  ...
  • Page 36 Configuring Your Network Adapter for GigE Visionscape The filter driver requires no setup whatsoever. Clicking on the TCP/IP Properties button will bring up the following dialog:   There is usually no need for cameras to be on a DHCP network, so choose a static address that starts with 192.168.x.x.
  • Page 37 Chapter System Components Omron Microscan recommends that you set your NIC to end in .2. For instance 192.168.2.2. If you have more than one camera NIC then set the second one to 192.168.3.2, and so on. Optimizing the Network Adapter for use with GigE Cameras To reduce the load on the PC to a minimum you need to optimize the NIC.
  • Page 38 Configuring Your Network Adapter for GigE Visionscape Next, click on the Advanced tab and you should see a list of parameters that can be tuned by the user.   Look for Jumbo Frames (sometimes called Jumbo Packets). Set this to the maximum available –...
  • Page 39 Chapter System Components Then select Receive Descriptors (if available). This is sometimes grouped within Performance Options:   Click on the Properties button to bring up this view:   Visionscape GigE Camera Guide 2-28...
  • Page 40 Configuring Your Network Adapter for GigE Visionscape The default value for receive descriptors is 256. Set this to the maximum available - typically 2048. Save changes by clicking OK. The NIC is now enabled to handle larger packets. This means that, instead of sending image data from the camera in chunks of 1500 bytes they can now come in chunks of 8192.
  • Page 41 Chapter System Components When you open the tool you will see a dialog similar to this:   The camera here is set to use DHCP and the address is 192.168.254.3. However, a persistent IP address is preferable. Check the “Use persistent IP” box and uncheck the “Use DHCP” box. Enter 192.168.254.3 in the lower IP address box and 255.255.255.0.
  • Page 42 Configuring Your Network Adapter for GigE Visionscape Cycle power to the camera. The config tool will now show the following:   Now, every time the camera is rebooted it will automatically set this IP address so it will not have to search the network to determine what IP address to use.
  • Page 43 Chapter System Components Then go to: My Computer\HKEY_LOCAL_MACHINE\SOFTWARE\Visionscape\ GigEVision\Camera_0 Note: In newer builds of Visionscape there are more entries in these directories. Depending on how many cameras you have connected you may have Camera_0, Camera_1, Camera_2 and Camera_3 directories – these all have the same things inside.

  • Page 44: Setting The Inter-Packet Delay

    Configuring Your Network Adapter for GigE Visionscape Change Base to Decimal:   Now enter 8192 in the Value Data text box:   Click on OK and you are done for setting the packet size. You’ve told Visionscape to use jumbo packets but the camera is still going to be sending data at the same rate –...
  • Page 45 Chapter System Components The inter-packet delay is the parameter that will allow us to control the rate of data from the camera. Let’s assume that we are using a CMG03c camera transmitting bayer data. This camera is capable of running at 91 fps with an 8 millisecond exposure time.
  • Page 46 Configuring Your Network Adapter for GigE Visionscape – Add in the 2.59 milliseconds to actually send the data. 2.59 + 27.71 = 30.3 milliseconds per frame. – The camera could run at 33 fps. – Set the inter-packet delay in the registry in exactly the same way as you set the packet size.
  • Page 47 Chapter System Components per second. Furthermore, this was not when the packet size was minimized but when it was set to 9000. The rate shown in FrontRunner is the display rate. The camera itself is running at least twice as fast. The rate displayed on-screen when in live video is meaningless in terms of the application runtime performance.

  • Page 48: How To Modify The Dm.config File To Change Camera And System Assignments

    System Assignments Explaining and Modifying the dm.config file The first time you plug a Omron Microscan GigE camera into a PC and start FrontRunner, a new file is created. This file is called dm.config and it can be found in the C:\Vscape\DM directory. DM stands for Device Manager, and this file is intended to manage all GigE devices attached to the PC.
  • Page 49 Note that only cameras that are connected via gigabit ethernet will be listed. We do not recommend or even allow the use of 100baseT networks with Omron Microscan GigE cameras. If you look closely, you'll notice that the assignment uid listed in the device section is the same as that shown for the resource uid for the attached camera.
  • Page 50 How to Modify the dm.config File to Change Camera and System Assignments <Devices> <Device name="GigEVision1" devClass="GigE"> <Assignments> <Assignment type="ACQ" uid="94d2afa3-95bb-4e6d-83bd- 098e5ed439d2" /> <Assignment type="ACQ" uid="189b1b90-624b-4eec-b282- 839558dc0f6c" /> </Assignments> </Device> <Device name="SoftSys1" devClass="Software" /> </Devices> <Resources> <Resource uid="94d2afa3-95bb-4e6d-83bd-098e5ed439d2" type="GigE_Camera" MACAddress="00-06-BE-00-09-4A"> <gige> <CameraID>TL=&gt;GevTL , INT=&gt;FD::MAC-&gt;00-1B-21-0A-0C- 72::National Instruments GigE Vision Adapter - Packet Scheduler Miniport , DEV=&gt;::MAC-&gt;00-06-BE-00-09-4A::Baumer...
  • Page 51 Chapter System Components 11:19:13 Channel 0 (Filter Driver): Microscan VISIONSCAPE CMG20 (1624x1236) MAC="00-06-BE-00-09-4A" IP="192.168.254.3" Connected 11:19:13 Channel 1 (Filter Driver): Microscan VISIONSCAPE CMG20 (1624x1236) MAC="00-06-BE-00-09-4B" IP="192.168.254.2" Connected 11:19:13 Creating SW System 1: SoftSys1 11:19:15 Creating IO Server for System GigEVision1 11:19:16 Creating IO Server for System SoftSys1 If you look at the FrontRunner device bar you will see that there is still...
  • Page 52 How to Modify the dm.config File to Change Camera and System Assignments running the other three lines. This is theoretically possible with multiple GigE systems. How do you do this? By making some relatively simple changes to the dm.config file. Start by quitting FrontRunner and the Backplane. Taking our two camera file as a starting point, we are going to duplicate the GigEVision1 device as follows.
  • Page 53 Chapter System Components </Device> <Device name="GigEVision2" devClass="GigE"> <Assignments> <Assignment type="ACQ" uid="189b1b90-624b-4eec-b282- 839558dc0f6c" /> </Assignments> </Device> <Device name="SoftSys1" devClass="Software" /> </Devices> Bring up FrontRunner again and you should see the following in the device bar: Two GigE systems are available, each with one camera. The Backplane debug window also shows the change: 14:01:47 QuerySWRights: GigE license rights detected, features: Visionscape GigE (x8): YES / IntelliFind: YES / Third Party GigE...
  • Page 54 How to Modify the dm.config File to Change Camera and System Assignments 14:01:49 Channel 0 (Filter Driver): Microscan VISIONSCAPE CMG20 (1624x618) MAC="00-06-BE-00-09-4B" IP="192.168.254.2" Connected 14:01:49 Creating SW System 1: SoftSys1 14:01:50 Creating IO Server for System GigEVision1 14:01:51 Creating IO Server for System GigEVision2 14:01:52 Creating IO Server for System SoftSys1 You can now use the two cameras and systems independently.
  • Page 55 Chapter System Components </Device> <Device name="SoftSys1" devClass="Software" /> </Devices> <Resources> <Resource uid="2ca5cfd1-14c2-45dd-b692-9a2948d18361" type="GigE_Camera" MACAddress="00-06-BE-00-09-4B"> <gige> <CameraID>TL=&gt;GevTL , INT=&gt;FD::MAC-&gt;00-1B-21-0A-0C- 72::National Instruments GigE Vision Adapter - Packet Scheduler Miniport , DEV=&gt;::MAC-&gt;00-06-BE-00-09-4B::Baumer Optronic::VISIONSCAPE CMG20</CameraID> <IPAddress>192.168.254.2</IPAddress> <MACAddress>00-06-BE-00-09-4B</MACAddress> <VendorName>Microscan</VendorName> <ResolutionX>1624</ResolutionX> <ResolutionY>618</ResolutionY> <ModelName>VISIONSCAPE CMG20</ModelName> </gige> </Resource> </Resources>...
  • Page 56 How to Modify the dm.config File to Change Camera and System Assignments <Assignment type="ACQ" uid="07a05837-f79e-4827-8773- 399c72bb1d63" /> </Assignments> </Device> <Device name="SoftSys1" devClass="Software" /> </Devices> <Resources> <Resource uid="2ca5cfd1-14c2-45dd-b692-9a2948d18361" type="GigE_Camera" MACAddress="00-06-BE-00-09-4B"> <gige> <CameraID>TL=&gt;GevTL , INT=&gt;FD::MAC-&gt;00-1B-21-0A-0C- 72::National Instruments GigE Vision Adapter - Packet Scheduler Miniport , DEV=&gt;::MAC-&gt;00-06-BE-00-09-4B::Baumer Optronic::VISIONSCAPE CMG20</CameraID>...
  • Page 57 Chapter System Components 16:24:05 Creating SW System 1: SoftSys1 16:24:10 Creating IO Server for System GigEVision1 16:24:11 Creating IO Server for System SoftSys1 In this state, FrontRunner comes up and, although you only have the one camera connected, there are two cameras in the vision system step list: The original camera is still camera 1 although it is noted as being disconnected.
  • Page 58 How to Modify the dm.config File to Change Camera and System Assignments If the original camera is no longer required, delete it by erasing the first line in the GigEVision1 assignments as follows: Before <Devices> <Device name="GigEVision1" devClass="GigE"> <Assignments> <Assignment type="ACQ" uid="2ca5cfd1-14c2-45dd-b692- 9a2948d18361"...
  • Page 59 Chapter System Components Miniport , DEV=&gt;::MAC-&gt;00-06-BE-00-09-4A::Baumer Optronic::VISIONSCAPE CMG20</CameraID> <IPAddress>192.168.254.2</IPAddress> <MACAddress>00-06-BE-00-09-4A</MACAddress> <VendorName>Microscan</VendorName> <ResolutionX>0</ResolutionX> <ResolutionY>0</ResolutionY> <ModelName>VISIONSCAPE CMG20</ModelName> </gige> </Resource> </Resources> After <Resources> <Resource uid="07a05837-f79e-4827-8773-399c72bb1d63" type="GigE_Camera" MACAddress="00-06-BE-00-09-4A"> <gige> <CameraID>TL=&gt;GevTL , INT=&gt;FD::MAC-&gt;00-1B-21-0A-0C- 72::National Instruments GigE Vision Adapter - Packet Scheduler Miniport , DEV=&gt;::MAC-&gt;00-06-BE-00-09-4A::Baumer Optronic::VISIONSCAPE CMG20</CameraID> <IPAddress>192.168.254.2</IPAddress>...
  • Page 60 Imagine you’re using a CMG03. The camdef file is in the C:\Vscape\Drivers\CamDefs directory and it’s called: microscan_visionscape_cmg03_656x494_gigevision.cam Open this file with the text editor of your choice (Notepad, for example). It looks like this: Camera Name Microscan VISIONSCAPE CMG03 656x494 Digitizer Type 1073741824 // GigeVision Camera Help File Stride 656...
  • Page 61 Chapter System Components If you only want to use the middle 100 lines you would change this as follows: Camera Name Microscan VISIONSCAPE CMG03 656x100 Digitizer Type 1073741824 // GigeVision Camera Help File Stride 656 Rows X Offset 0 Y Offset...
  • Page 62 How to Modify the dm.config File to Change Camera and System Assignments cameras give 128MB per second which is more than the 1000Base/T link can handle). The Correct Procedure The first thing to do is to make sure that the NIC is configured correctly. Hopefully this is an Intel Pro/1000 NIC card.
  • Page 63 Chapter System Components Now that the NIC is all set up to handle cameras in the most efficient way possible we can start working with the cameras. Connect the switch to the NIC and turn it on. Connect the camera you want to be camera 1 to the NIC. Bring up FrontRunner or just the Backplane.
  • Page 64 How to Modify the dm.config File to Change Camera and System Assignments Go to My Computer\HKEY_LOCAL_MACHINE\SOFTWARE \Visionscape\GigEVision\Camera_0 You will actually have Camera_0, Camera_1, Camera_2 and Camera_3 directories – these all have the same things inside. You’ll need to repeat the procedure for Camera_0 on all 4 cameras. The two parameters InterPacketDelay and PacketSize are both set to 0, which tells Visionscape to use its default values.
  • Page 65 Chapter System Components Change to Decimal in the Base group: Now enter 8192 in the Value Data text box: Click OK and you are done setting the packet size. Repeat this for all four cameras. We’ve told Visionscape to use jumbo packets but the four cameras are still going to be sending data at the same rate (128MB per second overall).
  • Page 66 PC on the motherboard or as PCI or PCIe cards and there are also some USB-to-Ethernet adapters available. Omron Microscan recommends the use of NICs that make use of the Intel Pro/1000 chipsets. Visionscape GigE Camera Guide...
  • Page 67 QoS Packet Scheduler Internet Protocol (TCP/IP) Some systems split internet protocol into two separate entries: TCP/IP Rev 4 and Rev 6. All Omron Microscan cameras use TCP/IP Rev 4. There may also be anti-virus filters such as “McAfee NDIS Intermediate Filter”.
  • Page 68 How to Modify the dm.config File to Change Camera and System Assignments In the example below, note the two check boxes at the bottom of the dialog box. If you have these checked then you will see a small icon for each NIC in the task bar.
  • Page 69 Chapter System Components The filter driver requires no setup whatsoever. Clicking on the TCP/IP Properties button will bring up the following dialog:   There is usually no need for cameras to be on a DHCP network, so choose a static address that starts with 192.168.x.x. 192.168 is reserved for private networks.
  • Page 70 How to Modify the dm.config File to Change Camera and System Assignments the box the cameras should now assign themselves addresses in the 192.168.254.x range. They are still receiving information about the network from outside in order to make this choice. You can simplify things still further by assigning each camera its own persistent IP address.
  • Page 71 Chapter System Components Check the Use persistent IP box and uncheck the Use DHCP box. Enter 192.168.254.3 in the lower IP address box and 255.255.255.0 for the Subnet mask. Click Apply. You will be prompted to reboot the camera as follows: Cycle power to the camera and you are ready.
  • Page 72 How to Modify the dm.config File to Change Camera and System Assignments What To Do When Visionscape Is Not Working Within Normal Operational Parameters Sometimes when you install or upgrade Visionscape (or install something after Visionscape) things start to work incorrectly. This can be caused by registration problems.

  • Page 73: Visionscape Gige Network Configuration

    If multiple high resolution cameras (such as the CMG20 or CMG50) are employed in applications with high trigger rates, Omron Microscan recommends that each camera is connected directly to its own PC network port.
  • Page 74 Visionscape GigE Network Configuration Run regedit; Navigate to: Select InterPacketDelay; Select Decimal and enter desired values. Recommended Values for InterPacketDelay (IPD) and Maximum Frames per Second (FPS) 2 Cameras on 3 Cameras on 4 Cameras on a Single Port a Single Port a Single Port CMG20 Camera...

  • Page 75: Trigger Debounce

    The min value for "IO Line Debounce Time" is 0 μs, which disables software debounce altogether. The maximum value is 5000 μs. Camera Definition File Example Camera Name Omron Microscan VISIONSCAPE CMG03 656x494 Digitizer Type 1073741824 // GigeVision Camera Help File...

  • Page 76: Optics

    Optics CHAPTER 3 This section contains information specific to the Optics options for the Visionscape GigE Camera. Visionscape GigE Camera Guide...
  • Page 77 Chapter Optics Optics The Visionscape GigE Camera uses C-Mount lenses. Table 3–1 contains lens sizes and Omron Microscan part numbers. Lens Sizes and Omron Microscan Part Numbers TABLE 3–1. Part Number Size 98-92800571 Lens: 8.5mm 98-92800572 Lens: 12mm 98-92800573 Lens: 16mm...

  • Page 78: Connector Pinouts

    Connector Pinouts APPENDIX A This section contains information about Visionscape GigE Camera connectors: • Power Connector on page A-2 • Strobe and Trigger Connector on page A-3 • Gigabit Ethernet Connector on page A-4 Visionscape GigE Camera Guide...

  • Page 79: Visionscape Gige Camera Connectors

    Appendix Connector Pinouts Visionscape GigE Camera Connectors Power Connector Figure A–1 shows the pinout of the power connector. Power Connector FIGURE A–1. Power Connector Table A–1 lists the supplier for the power connector mating cable. Power Connector Mating Cable TABLE A–1. Supplier Part Number Description...

  • Page 80: Strobe And Trigger Connector

    Visionscape GigE Camera Connectors Strobe and Trigger Connector The standard I/O connector consists of one optoisolated input “Trigger” and one optoisolated output “Flash”. Figure A–2 shows the pinout of the strobe and trigger connector. Strobe and Trigger Connector FIGURE A–2. Strobe and Trigger Connector Table A–3 lists the supplier for the strobe and trigger connector mating cable.

  • Page 81: Gigabit Ethernet Connector

    Appendix Connector Pinouts Gigabit Ethernet Connector Figure A–3 shows the pinout of the Gigabit Ethernet connector. Gigabit Ethernet Connector (RJ45) FIGURE A–3. Gigabit Ethernet Connector (RJ45) Table A–5 lists the supplier for the Gigabit Ethernet connector mating cables. Ethernet Connector Mating Cable TABLE A–5.
  • Page 82 Visionscape GigE Camera Connectors Table A–6 describes the Gigabit Ethernet connector signals. Gigabit Ethernet Connector 1000 Base-T (RJ45) Signals TABLE A–6. Signal Name Description MX1+ Pair 1+ MX1– Pair 1– MX2+ Pair 2+ MX3+ Pair 3+ MX3– Pair 3– MX2– Pair 2–...
  • Page 83 Appendix Connector Pinouts Visionscape GigE Camera Guide...

  • Page 84: Cable Specifications

    Cable Specifications APPENDIX B This section contains information about Visionscape GigE Camera cables. Note: Cable specifications are published for information only. Omron Microscan does not guarantee the performance or quality of cables provided by other suppliers. Cable Part Numbers and Descriptions TABLE B–1.

  • Page 85: 98-000129-01 Visionscape Gige Camera Power M8-3 To Pigtail 5M

    Appendix Cable Specifications 98-000129-01 Visionscape GigE Camera Power M8-3 to Pigtail 5M The 98-000129-01 Visionscape GigE Camera Power cable is a single-ended shielded cable with an M8 x 3 female connector on one end. Figure B–1 shows the wiring for the 98-000129-01 Visionscape GigE Camera power cable.

  • Page 86: Visionscape Gige Camera Strobe/Trigger M8-4 To Pigtail 5M

    98-000126-01 Visionscape GigE Camera Strobe/Trigger M8-4 to Pigtail 5M 98-000126-01 Visionscape GigE Camera Strobe/Trigger M8-4 to Pigtail 5M The 98-000126-01 Visionscape GigE Camera Strobe/Trigger cable is a single-ended shielded cable with an M8 x 4 female connector on one end. Figure B–2 shows the wiring for the 98-000126-01 Visionscape GigE Camera Strobe/Trigger cable.
  • Page 87 Appendix Cable Specifications 98-000133-01 and 98-000134-01 Cat 6 Ethernet with Jack Screws to RJ45 High Flex The 98-000133-01 and 98-000134-01 Cat 6 Ethernet cables are made to a higher standard than Cat 5 and Cat 5e cables consisting of a 4 twisted pair highly flexible cable with RJ45 connectors at both ends.

  • Page 88: 98-000133-01 And 98-000134-01 Cat 6 Ethernet With Jack Screws To Rj45

    98-000133-01 and 98-000134-01 Cat 6 Ethernet with Jack Screws to RJ45 Table B–5 describes the signals for the Visionscape GigE Camera Ethernet Cable. Visionscape GigE Camera Ethernet Cable TABLE B–5. Signal Name Description MX1+ Pair 1+ MX1– Pair 1– MX2+ Pair 2+ MX3+ Pair 3+...
  • Page 89 Appendix Cable Specifications Visionscape GigE Camera Guide...

  • Page 90: General Specifications

    General Specifications APPENDIX C This section contains specifications, dimensions, and spectral sensitivity characteristics for the Visionscape GigE Camera. Visionscape GigE Camera Guide...

  • Page 91: Visionscape Gige Camera General Specifications

    Appendix General Specifications Visionscape GigE Camera General Specifications Physical Characteristics P/N / Model Lens Type Height Width Depth Weight 98-000115-01 C-Mount 36 mm (1.42”) 36 mm (1.42”) 47.8 mm (1.88”) ≤ 90 g (CMG03) 98-000116-01 C-Mount 36 mm (1.42”) 36 mm (1.42”) 47.8 mm (1.88”) ≤...
  • Page 92 Visionscape GigE Camera General Specifications Optics Electronic P/N / Model Resolution Sensor FPS Pixel Size Image Acquisition Shutter 1/3” CCD 7.4 µm x 4 µs to 60 S; 1 µs Progressive Scan; Full and 98-000115-01 656 x 494 Mono 7.4 µm Step Partial Frame Capture (CMG03)

  • Page 93: Communications And I/O

    Appendix General Specifications Communications and I/O P/N / Model Communications Gigabit Ethernet 1 Optoisolated Input and 1 Optoisolated Output 98-000115-01 (CMG03) Gigabit Ethernet 1 Optoisolated Input and 1 Optoisolated Output 98-000116-01 (CMG03c) Gigabit Ethernet 1 Optoisolated Input and 1 Optoisolated Output 98-000117-01 (CMG08) Gigabit Ethernet 1 Optoisolated Input and 1 Optoisolated Output...

  • Page 94: Operating Environment; Agency Compliance

    Visionscape GigE Camera General Specifications Operating Environment; Agency Compliance Operating Storage P/N / Model Humidity Agency Compliance Temperature Temperature 10% to 90% CE, FCC Part 15 Class B, +5° C to +50° C –10° C to +70° C 98-000115-01 (CMG03) Non-Condensing UL, RoHS compliant 10% to 90%...

  • Page 95: Dimensions

    Appendix General Specifications Dimensions Camera Dimensions, CCD, C-Mount (CMG03, CMG03c, CMG08, FIGURE C–1.  CMG13, CMG20, CMG50, CMG04, CMG20c, CMG50c, CMG14, CMG08c, CMG13c) Visionscape GigE Camera Guide...
  • Page 96 Dimensions Camera Dimensions, CMOS, C-Mount (CMGC50, CMGC50c) FIGURE C–2. Visionscape GigE Camera Guide...
  • Page 97 Appendix General Specifications Camera Dimensions, CCD, C-Mount or F-Mount (CMG80) FIGURE C–3. C-Mount F-Mount Visionscape GigE Camera Guide...
  • Page 98 Dimensions Camera Dimensions, CCD, C-Mount (CMG04h) FIGURE C–4. Visionscape GigE Camera Guide...
  • Page 99 Appendix General Specifications Mounting Block Dimensions FIGURE C–5. Visionscape GigE Camera Guide C-10...

  • Page 100: Spectral Sensitivity

    Spectral Sensitivity Spectral Sensitivity Spectral Sensitivity Characteristics (98-000115-01, CMG03) FIGURE C–6. Note: Excludes lens characteristics and light source characteristics. Visionscape GigE Camera Guide C-11...
  • Page 101 Appendix General Specifications Spectral Sensitivity Characteristics (98-000116-01, CMG03c) FIGURE C–7. Note: Excludes lens characteristics and light source characteristics. Visionscape GigE Camera Guide C-12...
  • Page 102 Spectral Sensitivity Spectral Sensitivity Characteristics (98-000117-01, CMG08) FIGURE C–8. Note: Excludes lens characteristics and light source characteristics. Visionscape GigE Camera Guide C-13...
  • Page 103 Appendix General Specifications Spectral Sensitivity Characteristics (98-000118-01, CMG13) FIGURE C–9. Note: Excludes lens characteristics and light source characteristics. Visionscape GigE Camera Guide C-14...
  • Page 104 Spectral Sensitivity Spectral Sensitivity Characteristics (98-000119-01, CMG20) FIGURE C–10. Note: Excludes lens characteristics and light source characteristics. Visionscape GigE Camera Guide C-15...
  • Page 105 Appendix General Specifications Spectral Sensitivity Characteristics (98-000120-01, CMG50) FIGURE C–11. Note: Excludes lens characteristics and light source characteristics. Visionscape GigE Camera Guide C-16...
  • Page 106 Spectral Sensitivity Spectral Sensitivity Characteristics (98-000141-01, CMG04) FIGURE C–12. Note: Excludes lens characteristics and light source characteristics. Visionscape GigE Camera Guide C-17...
  • Page 107 Appendix General Specifications Spectral Sensitivity Characteristics (98-000189-01, CMG20c) FIGURE C–13. Note: Excludes lens characteristics and light source characteristics. Visionscape GigE Camera Guide C-18...
  • Page 108 Spectral Sensitivity Spectral Sensitivity Characteristics (98-000190-01, CMG50c) FIGURE C–14. Note: Excludes lens characteristics and light source characteristics. Visionscape GigE Camera Guide C-19...
  • Page 109 Appendix General Specifications Spectral Sensitivity Characteristics (98-000191-01, CMG14) FIGURE C–15. Note: Excludes lens characteristics and light source characteristics. Visionscape GigE Camera Guide C-20...
  • Page 110 Spectral Sensitivity Spectral Sensitivity Characteristics (98-000220-01, CMG08c) FIGURE C–16. Note: Excludes lens characteristics and light source characteristics. Visionscape GigE Camera Guide C-21...
  • Page 111 Appendix General Specifications Spectral Sensitivity Characteristics (98-000221-01, CMG13c) FIGURE C–17. Note: Excludes lens characteristics and light source characteristics. Visionscape GigE Camera Guide C-22...
  • Page 112 Spectral Sensitivity Spectral Sensitivity Characteristics (98-000222-01, CMGC50) FIGURE C–18. Note: Excludes lens characteristics and light source characteristics. Visionscape GigE Camera Guide C-23...
  • Page 113 Appendix General Specifications Spectral Sensitivity Characteristics (98-000230-01, CMGC50c) FIGURE C–19. Note: Excludes lens characteristics and light source characteristics. Visionscape GigE Camera Guide C-24...
  • Page 114 Spectral Sensitivity Spectral Sensitivity Characteristics (98-000260-01, CMG80) FIGURE C–20. Note: Excludes lens characteristics and light source characteristics. Visionscape GigE Camera Guide C-25...
  • Page 115 Appendix General Specifications Spectral Sensitivity Characteristics (98-000267-01, CMG04h) FIGURE C–21. Note: Excludes lens characteristics and light source characteristics. Visionscape GigE Camera Guide C-26...

This manual is also suitable for:
