  • Page 1 F2Y1*YP**...

  • Page 2: Table Of Contents

    CONTENTS 1. SPECIFICATIONS .............................. 2. FEATURES & TECHNICAL EXPLANATION ....................PARTS IDENTIFICATION ..........................6 INSTALLATION ..............................7 5. OPERATION ..............................5-1. F2Y1*YP** ............................. .
  • Page 3 ITEM Refer to 1 page POWER SUPPLY 220 V - 240 V ~,50HzHz PRODUCT WEIGHT 55kg WASHING 180 W SPIN 355 W ELECTRICITY DRAIN MOTOR 33 W CONSUMPTION WASH HEATER 1900~2250 W WASH 46 rpm REVOLUTION F2Y1*YP* No Spin / 400 / 600 / 800 / 1000 / 1200 SPIN SPEED 0.05 ~ 0.8 MPa (0.5 kgf / cm...

  • Page 4: Features & Technical Explanation

    2. FEA TURES & TECHNICAL EXPLANATION 2-1. FEA TURES Anti Crease function With the alternate rotation of the drum, creasing in the laundry is minimized. More economical by Fuzzy Logic System FUZZY Logic System detects the amount of load and water temperature, and then determines the optimum water level and washing time to minimize energy and water consumption.

  • Page 5: Water Level Control

    2-2. DETERMINE WASHING TIME BY FUZZY LOGIC To get the best washing performance optimal time is determined by sensing of water temperature, selected washing temperature and laundry amount. water temperature washing time the best selected FUZZY washing rinse time washing LOGIC temperature performance...

  • Page 6: Parts Identification

    3. PAR TS IDENTIFICA TION Front View Control Panel Detergent dispenser drawer Drum Door Cover cap Drain pump filter Drain plug Adjustable feet Rear View Power plug Transit bolts Drain hose Accessories * This feature may vary depending on the model purchased. Cold water inlet hose* Spanner Caps for covering transit bolt holes*...

  • Page 7: Installation

    4. INST ALLATION INST ALLATION The appliance should be installed as follows. Check the conditions of installation area. 1. Check level ground. horizontal On raised foundations or upper level homes, the vibrations can be caused by the type of flooring. It may be necessary to move machine...
  • Page 8 Use spanner to remove transit bolts. Without removal of transit bolts Spin noise and shaking. X 4 EA Transit bolts Confirm the distance between the appliance and the wall. If the distance is less than 2cm, More than 2cm the water supply hose will kink or fold.

  • Page 9: Connect Drain Hose

    Connect Drain Hose. If the drain hose is not installed properly, the unit will not drain properly. This allows water to back flow into the unit which can cause odors. Refer to Owner Manual for proper drain hose installation. The odor could also be coming from the home’s drain to which the drain hose is attached. Laundry tub about 100 cm Hose...
  • Page 10 Check the horizontality with a level (Gage). 1 Step If washing machine legs are loose or not screwed, then screw up with the spanner wrench. Using the level, level the washing machine from front to back and side to side. A level Higher Tighten...
  • Page 11 Press the START/PAUSE Press the power touch key. touch key. Turn power off and open the door.

  • Page 12: Operation

    5. OPERATION 5-1. F2Y1*YP** Options By selecting the Intensive option, the wash time may be extended, depending on the program selec ted. Pre Wash is available in Cotton,Cotton Large,and Easy Care Rinse+ : Add Rinse once. Wash program selector depending on the type of the laundry.
  • Page 13 F2Y1*YP** Spin Delay End Power Temp. Delay End When touch theSpin or Temp. TheRpm and Temp will display on the display...
  • Page 14 [Note] RD: Red YL: Yellow BL: Blue SB: Sky Blue WH: White GY: Gray OR: Orange CY: Cyan BR: Brown PL: Purple NA: Natural...

  • Page 16: Troubleshooting

    7. TROUBLESHOOTING 7-1. BEFORE PERFORMING SERVICE Before servicing ask the customer what the trouble is . Check the adjustments. (Power supply :220-240V~, Removal of transit bolts etc..) Check the troubles referring to the troubleshooting. Decide service steps referring to disassembly instructions . Then, service and repair.

  • Page 17: Error Display

    7-4. ERROR DISPLAY If you press the [Start/Pause] button when an error in displayed, any error except software ERROR will disappear and the machine will change into pause status. In case of , if the error is not resolved within 15 sec. In case of other errors, if the error is not resolved within 4 min.

  • Page 18: Ie (Water Inlet Error)

    7-5. TROUBLESHOOTING WITH ERROR Water Inlet Error (IE) [Note] Environmental safety check list 1. No water tap leakage & freeze. 2. No entanglement of water supply hose . 3. No water shortage. 4. No water supply hose leakage. 5. No the inlet filter clogged. Is the water tap closed ? Check the Water tap...

  • Page 19: Ue (Unbalanced Error)

    Unbalanced Error (UE) The few items of clothing will clump together Does the load lean toward one and their weight will be in one place on the drum, side, or is the load a few items? throwing the weight off during spin mode. So add some laundry to overcome UE error.

  • Page 20: Oe (Water Outlet Error)

    Water Outlet Error (OE) Check drain hose for kink and straighten the Hose. Is the drain hose kinked ? Drain Hose Check & Clean Pump Filter. Is the Pump filter clogged ? This kind of accumulation on the drain filter not only prevents proper drainage, but also will promote bacteria growth and cause odors.
  • Page 21 Is the Standpipe Height greater Observe Standpipe Height requirements than 1.0 m above the floor? of 1.0m maximum. - Your washer will not be able to drain out water adequately, if the standpipe exceeds 1.0 m. In this case, water may flow back into the washer. When there is not water in the Check the Air Chamber...
  • Page 22 Over Flow Error (FE) Replace the Inlet Valve assembly . Is the water coming in drawer continuously ? After power off for 10 sec. and power on. Does the water level over reference line and Is the water level frequency 25.5Khz or 26.1Khz ? Or does the water level over reference line and is the water level frequency 25.5Khz or 26.1Khz? F2Y1*YP**...

  • Page 23: Pe (Pressure Sensor S/W Error)

    Pressure Sensor S/W Error (PE) Is the Connector connected correctly to Reconnect or repair the Connector Main PC B and the Pressure Switch Or replace the Harness Or is the Harness alright ? Is the resistance of the Pressure Switch Replace the Pressure Switch out of range?

  • Page 24: Door Open Error)

    Door Open Error (dE) Close the door totally. Is the door closed? Is the Door assembly in line with door Lift up & Close the door. switch ? If the dE is displayed, Replace the Door Bracket Scratch by Latch Hook Touching Does the Spring...

  • Page 25: Te (Thermistor (Heating) Error)

    Thermistor (Heating) Error (tE) Is the Connector connected correctly to Reconnect or repair the Connector Main PCB and the Thermistor Or replace the Harness the Heater? Or is the Harness alright ? Is the resistance of the Thermistor Replace the Thermistor of range 44 ~ 53 K at 25°C ?
  • Page 26 Motor Locked Error (LE)
  • Page 27 No Power Noise Filter...

  • Page 28: Vibation & Noise In Spin

    Vibration & Noise In Spin...

  • Page 29: Detergent & Softener Does Not Flow In

    Detergent & Softener does not flow in Only softener Main Wash Pre Wash (Powder) (Powder)

  • Page 30: Water Leak

    Water Leak Only softener Main Wash Pre Wash (Powder) (Powder)
  • Page 34 option Revolve the Inlet Vale to the arrow direction (After Inlet Valve remove, the Hook may broken, need replace new Inlet valve) • Rating : DC 12V • Resistant : 20~30 Ω Cap Cover/Case Press ‘ - ’ mark to open cover cap and pull out the case to the arrow direction...
  • Page 37 • Rating : DC 26V • Resistant : 2~4 Ω...

  • Page 39: Exploded View

    EXPLODED VIEW .THE EXPLODED VIEW OF CABINET ASSEMBLY A110 A140 A410 A485 A152 A141 A101 A154 A153 A151 A131 A150 A102 A134 A103 A130 A104 A133 A100 A200 A440 A698 A201 A300 A220 A303 A430 A310 A276...
  • Page 40 F321 F160 F462 F300 F432 F464 F441 F310 F225 F220 F430 F120 A450 F215 F110 F210...
  • Page 41 K411 K410 F140 K350 K143 K360 K123 K105 F466 F320 K115 K110 K111 K141 K122 K140 K121 K125 K530 K510 K320 K610 K572 F467 K571 K540 K611 K570 K550 K520 F461 F468 K344 K340 K130 K131 K135...
  • Page 42 P/No.:MFL71892773...

This manual is also suitable for:
