- Page 1 MT2000 series remote I/O module User 's Manual Rev: F Smacq Technologies. Co., Ltd Smacq.com Smacq.cn...
-
Page 2: Trademark Information
Without prior consent and written permission, no content of this manual may be copied, modified, or deleted. Trademark information It is a registered trademark of Smacq Technologies. Co., Ltd. The other products and company names mentioned in this document are trademarks or business names of their respective companies. -
Page 3: Safety Requirements
Safety requirements Warning: Only connect voltage within the specified range. If the voltage exceeds the specified range, it may cause equipment damage and even affect personal safety. The voltage range that can be connected to each port is detailed in the product specification section. -
Page 4: Measurement Category
Measurement category Warning: This device can only be used in measurement category I (CAT I). Do not use this device to connect signals or perform measurements in measurement categories II/III/IV. Measurement category description Measurement Category I (CAT I) refers to measurements taken on circuits that are not directly connected to the main power supply. - Page 5 Environment Temperature Operation 0℃~55℃ Storage -40℃~85℃ Humidity Operation 5% RH~95% RH, non-condensing Storage 5% RH~95% RH, non-condensing Pollution level Highest altitude 2000m Pollution level description Pollution level 1: No pollution, or only dry non-conductive pollution occurs. This pollution level has no impact. For example, a clean room or an air-conditioned office environment. Pollution level 2: Generally only dry non-conductive pollution occurs.
-
Page 6: Product Introduction
MT2003 Wiring Definition Overview The MT2000 series remote I/O module is a set of computer interface modules based on the Modbus TCP standard protocol. MT2000 is remotely controlled through the standard Modbus TCP protocol, with programmable analog input interfaces for multiple channels, and can be converted through... - Page 7 Feature point 8-channel analog input MT2003, MT2013, 12 bit resolution (16 bit in high-resolution mode) Using standard Modbus TCP protocol Multi-range setting Built-in Watchdog Timer will automatically reset the module in case of system failure 9-24V power supply voltage range ...
-
Page 8: Product Specifications
1.2. Product specifications Common Specifications Connection Interface 10/100M Ethernet Adaptive (RJ45) Network Mode TCP SERVER (Default), TCP CLIENT, UDP Protocol Modbus TCP Watchdog Timer Power Supply Input Voltage 9-30 VDC Electric Current MT2003：60mA (Max) @ 24V MT2013：60mA (Max) @ 24V MT2093：60mA (Max) @ 24V MT2003 Product Specification Analog input... - Page 9 MT2013 Product Specification Analog input Channels Input Type Voltage, Current (Switch through Jumper setting) Resolution 12-bit 16-bit (High-resolution mode) Voltage range 0-10V (Default), 2-10V Current range 0-20mA, 4-20mA Integral time 20ms Input coupling mode Voltage input impedance 10M Ω (Typical values) Current input impedance 249Ω...
-
Page 10: Packing List
2. Product unpacking and packing list 2.1. Product unboxing To prevent equipment damage from electrostatic discharge (ESD), please note the following: Please wear a grounded wristband or touch a grounded object first to ensure that the human body is grounded. -
Page 11: Hardware Install
Power Connection Diagram 3.2. Software installation We provide an application for configuring, detecting, and easy-to-use MT2000 series remote I/O modules, which can only be installed on the Windows desktop operating system. Double click to run setup. exe for installation. - Page 12 3.3. Simple testing The MT2000 series remote I/O module is set to its initial value before leaving the factory, as shown in the table below. If the settings of the MT2000 series remote I/O module have been modified and the settings have been forgotten, a wire can be used to connect the Initiate and GND terminals, and then the power of the MT2000 can be turned on.
-
Page 13: Analog Input
4. Analog input In the MT2000 series remote I/O module, the MT2000 is equipped with 8 voltage/Current switchable analog input channels. Inside MT2000, each channel has a Jumper bit to set the input type for that channel. When the Jumper is not connected, this channel is a voltage input channel;... - Page 14 At the leave factory, these Jumper positions will be set according to the default input range. The default range is marked on the front panel of the module, as shown in the figure below. The default range is 0~10V, so there is no Jumper wire connected inside. If you need to measure a 20mA Current signal, you need to open the housing and plug in the Jumper cap on the corresponding channel.
- Page 15 Schematic diagram of voltage signal analog input connection Schematic diagram of Current signal analog input connection...
-
Page 16: Programming Instructions
5. Programming instructions The MT2000 series remote I/O module is a set of computer interface modules based on Modbus TCP, and its programming rules follow The relevant conventions of Modbus TCP protocol. MODBUS TCP Command Message Description For the convenience of users who are using the Modbus TCP protocol for the first time, several commonly used Modbus command messages are briefly illustrated here. - Page 17 04 Function code Used for reading input registers To read the status of the three registers starting from address 30101 in a module, the host sends the following command: Fixed message header* Remaining bytes Module address** Function code Register address No.of registers 0x 0000 0000 00 0x06 0x01...
- Page 18 You can refer to the Modbus TCP protocol manual by yourself, and detailed explanations will not be provided here. **The MT2000 series remote I/O module has a fixed slave address of 0x01 and does not involve any other addresses, so the protocol will not be explained in detail.
- Page 19 Comparison Table of MT2013 High Resolution Mode (Factory Default) Analog Input Register Data and Voltage/Current Values Analog input range Analog input register data values (Decimal) 0-10V 0-65535, 0 corresponds to 0V, 65535 corresponds to 10V 0-65535, 0 corresponds to 2V, 65535 corresponds to 10V 2-10V 0-65535, 0 corresponds to 0mA, 65535 corresponds to 20mA 0-20mA...
- Page 20 MT2003, MT2093 Analog Input Range Register Range and Set Value Comparison Table Analog input range Analog input range register setting value (Decimal) 0-5V 1-5V 0-20mA 4-20mA 3 (Default) MT2013 Analog Input Range Register Range and Set Value Comparison Table Analog input range Analog input range register setting value (Decimal) 0-10V 0 (Default)
-
Page 21: After Sales Service And Warranty
6. After sales service and warranty Smacq Technologies. Co., Ltd. promises that its products are under warranty. If the product malfunctions during normal use, we will provide free repair or replacement of parts for the user. For detailed warranty instructions, please refer to the warranty instructions inside the packaging box. -
Page 22: Ordering Information
7. Ordering information Main Equipment Model Description 12 bit, 8-channel analog input (Voltage_5V/Current_20mA) MT2003 12 bit, 8-channel analog input (Voltage_10V/Current_20mA) MT2013 MT2093 12 bit, 8-channel analog input (Voltage_5V/Current_20mA) Supporting up to 10ms sampling Actively connected report Standard Accessories Model Description Bolt terminal connector, 13 positions, 3.81mm TB13-3.81 DIN-Rail mounting bracket... -
Page 23: Document Revision History
8. Document Revision History Date Edition Remarks First release. 2022.04.14 Rev: A Revise some errors. 2022.07.25 Rev: B 2023.04.26 Rev: C Ad d so m e co nt e nt to MT 2 01 3. Add Jumper instructions. 2024.01.12 Rev: D Ad d so m e co nt e nt to MT 2 09 3.
