A Series Temperature Controller
Thank you very much for purchasing DELTA A Series. Please read this instruction sheet to ensure correct
use before using your A series and please keep this instruction sheet handy for quick reference whenever
necessary.
Notice:
DANGER! Caution! Electric Shock!
1. Do not touch the AC terminals while the power is supplied to the controller in order
to avoid any electric shock.
2. Make sure the power is disconnected while checking the unit inside
WARNING!
This controller is an open-type temperature controller. Make sure to evaluate
any dangerous application in which a serious human injury or serious property
damage may occur.
1. Please use the specified solderless terminals (M3 screw, Max. width is 7.2mm or
less) and tighten them properly.
2. Do not allow the dust or metal fragments to fall inside the controller. These may
cause malfunction.
3. Never modify or disassemble the controller.
4. Do not wire to the No function terminals.
5. Make sure all wires are connected to the correct polarity of terminals.
6. Do not install and/or use the controller in places subject to:
• Dust or corrosive gases and liquid.
• High humidity.
• High radiation.
• Vibration and shock
• High voltage and high frequency
7. Must turn off the power when wiring and changing temperature sensor.
8. Be sure to use compensating wires that match the thermocouple types when
extending or connecting the thermocouple wires.
9. Please use wires with resistance when extending or connecting the wires of the
platinum resistance thermometer (RTD).
10. Please keep the wire route as short as possible when wiring platinum resistance
thermometer (RTD) to the controller and please route power wires as far away as
possible from load wires to avoid interferences and noise affection.
11. This controller is an open-type unit and it must be placed in an enclosure away
from high temperature, humidity, dripping water, corrosive materials, airborne
dust and electric shock or vibration.
12. This controller is an open-type unit and it must be placed in an enclosure away
from high temperature, humidity, dripping water, corrosive materials, airborne
dust and electric shock or vibration
Instruction Sheet
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Delta Electronics A Series
Summary of Contents for Delta Electronics A Series
- Page 1 A Series Temperature Controller Instruction Sheet Thank you very much for purchasing DELTA A Series. Please read this instruction sheet to ensure correct use before using your A series and please keep this instruction sheet handy for quick reference whenever necessary.
-
Page 2: Names Of Parts
: Down key. Press this key to decrease values displayed on the SV display. Holding down this key speeds up the continuously decrements. Model Explanation Series DTA : Delta A Series Temperature Controller 4848 : W48 × H48mm 7272 : W72 × H72mm Panel Size (W × H) 4896 : W48 ×... -
Page 3: Electric Specifications
Electric Specifications Power Supply Voltage 100 to 240VAC 50/60Hz Operation Voltage Range 85% to 110% of rated voltage Power Consumption 7-segment digit LED Display Display Method Process value (PV): Red color, Set point (SV): Green color Thermocouple: K, J, T, E, N, R, S, B Input Temperature Sensor Platinum resistance thermometer (RTD): Pt100, JPt100 Control Method... - Page 4 LED Display Explanation Default OUT: Output value display and output value adjustment in manual tuning control (This function is not available in ON/OFF control or Auto-tuning setting) 2. Regulation function mode: Set the control parameters LED Display Explanation Default AT: Auto-tuning setting. When AT key is set to ON ( ), the execution of the PID auto-tuning function is automatically started.
-
Page 5: Operation Explanation
LED Display Explanation Default T-HIGH: Upper-limit of temperature range 500.0 T-LOW: Lower-limit of temperature range -20.0 CONTROL: Control method setting. PID ( ), ON/OFF control ), or manual tuning ( ) on the SV display HEAT SWITCH: Select Heating ( ) or Cooling ( ) mode AL1 SET: Alarm 1 setting... - Page 6 Setting method: In operation function mode, regulation function mode and initial function setting mode, press key to select desired function and use key to change settings. After the settings are completely changed, press key to save. Flow chart of settings and internal functions are shown as below: Press key less than 3 sec...
- Page 7 Regulate temperature Output value display Alarm 2 setting deviation value and adjust Press Press Press Return to temperature display Communication write in Regulate 20mA output disable/enable deviation value (Display when current output) (only available when the controller has RS-485 function) Press Press Communication...
- Page 8 Temperature Sensor Type and Temperature Range Register Input Temperature Sensor Type LED Display Temperature Range Value Platinum resistance (Pt100) type3 0.0 to 100.0 Platinum resistance (Pt100) type2 -20.0 to 500.0 Platinum resistance (Pt100) type1 -200 to 600 Platinum resistance (JPt100) type2 0.0 to 100.0 Platinum resistance (JPt100) type1 -20.0 to 400.0...
-
Page 9: Alarm Outputs
Temperature sensor is Measured temperature exceeds Setting value Unknown input not connected temperature range Alarm Outputs There are two groups of alarm outputs and each group can select ten alarm types in the initial setting function mode. The alarm output is activated when the temperature of target (PV) is getting higher or lower than set value (SV). - Page 10 Alarm Type Alarm Output Function Value Deviation lower-limit with standby sequence: This alarm output operates when PV value reaches the set value (SV value) and the reached value is lower SV-(AL-L) than set value of SV (AL-L). Note: AL-H and AL-L include AL1H, AL2H and AL1L, AL2L. With standby sequence: It means that the alarm output would be temporarily disabled until when PV value reaches the set value.
-
Page 11: Communication Protocol
Address Content Explanation Temperature regulation error 4714H -127 to +127 value Please refer to the contents of the “Alarm 4715H Alarm 1 type Outputs” for detail Please refer to the contents of the “Alarm 4716H Alarm 2 type Outputs” for detail 4717H Temperature unit display selection : 1 (default),... - Page 12 ASCII mode: Command message: Response message: ‘:’ ‘:’ ADR 1 ‘0’ ADR 1 ‘0’ ADR 0 ‘1’ ADR 0 ‘1’ CMD 1 ‘0’ CMD 1 ‘0’ CMD 0 ‘6’ CMD 0 ‘6’ ‘4’ ‘4’ Starting data ‘7’ Starting data ‘7’ address address ‘0’...
- Page 13 DTA7272 DTA9696 Terminals Connection DTA4848 AC 100~240V 5A 250Vac 14Vdc 4~20mA 50~60Hz / 5VA ALM2 3A 250Vac ALM1 DATA- RS-485 3A 250Vac DATA+...
- Page 14 DTA4896/DTA9696 DATA+ AC 100~240V RS-485 50~60Hz / 5VA DATA- 3A 250Vac ALM2 3A 250Vac ALM1 5A 250Vac 14Vdc 4~20mA DTA7272 DATA+ AC 100~240V RS-485 50~60Hz / 5VA DATA- 3A 250Vac ALM2 ALM1 5A 250Vac 14Vdc 4~20mA...
- Page 15 Panel Cutout (units: mm) Mounting Step-1. Insert the controller through the panel cutout. Step-2. Insert the mounting bracket into the mounting groove at the top and bottom of the controller and push the mounting bracket forward until the bracket stops at panel wall. Step-3.
-
Page 16: Mounting Bracket Installation
Mounting Bracket Installation http://www.deltaww.com ASIA NORTH/SOUTH AMERICA EUROPE DELTA ELECTRONICS, INC. DELTA PRODUCTS DELTRONICS (Netherlands) TAOYUAN Plant/ CORPORATION B.V. 31-1, SHIEN PAN ROAD, Sales Office/ Sales Office/ KUEI SAN INDUSTRIAL ZONE P.O. BOX 12173 Industriegebied Venlo Nr. 9031 TAOYUAN 333, TAIWAN...
