HOLLOW-WALL ANCHOR INSTALLATION METHODS
This notice is intended to be used in combination with the installation Instructions provided with your Robern product.
To ensure correct installation, first identify the type of wall anchors supplied with your Robern fixture, BLUE 203-1309 or RED SS680,
then follow the associated installation method.
BLUE 203-1309 #10 Wall Anchor
If your Robern product has been equipped with the BLUE 203-1309 #10 wall anchors, please install the wall anchors as follows:
1. Drill a 5/16- hole into drywall/wallboard, plaster, brick, or concrete.
2. Insert the wall anchor into hole until anchor flange is flush with the wall.
3. Insert the #10 screw and tighten until contact with Z bar and/or Z clip is achieved.
4. Continue to tighten screw until there is a strong resistance. DO NOT OVER TIGHTEN.
RED SS680 #10 Wall Anchor
If your Robern product has been equipped with the RED SS680 #10 wall anchors, please install the wall anchors as follows:
1. If no furring strip or stud is available, use the supplied plastic anchors. Drill a 9/32" (7mm) hole for wall anchor.
2. Insert wall anchor into hole until flange is flush.
If your product is equipped with washers, fasten fixture by inserting screw with washer through fixture and into anchor. If your product is
not equipped with washers, insert screw through fixture and into anchor.
3. Tighten screw until it is tight against fixture. Keep turning screw at least four more times as shown.
Contact Robern Customer Service (800) 877-2376 of you have any questions.
Installation Notice - Wall Anchor Change
