usha Techne Direct 2000 Instruction Manual page 3

GET TO KNOW YOUR STEAMER
1. Cloth Brush
2. Thick Brush
3. Water Tank Cover
4. Ceramic Soleplate
5. Steam Head
6. Main Unit
7. Handle
8. Steam Button
9. Mode Selector
10. Water Tank
11. Display
12. Cord
13. Auto-Shut Off Indicator
14. Steam Mode
15. Eco Mode
16. Dry Heating Mode
TECHNICAL SPECIFICATIONS
Voltage
Frequency
Power
Water Tank Capacity
Due to continuous efforts for product upgradation, specifications are subject to change without prior notice.
OPERATING INSTRUCTIONS
BEFORE FIRST TIME USE
1. Remove any protective film/stickers from the steam head & body if any
2. Install all the accessories according to the installation instructions, fill water tank with max capacity of water,
and then iron a piece of waste cloth twice according to the operating instructions.
Note: There will be little droplets of water on steam head produced during the first use, and this is normal.
HOW TO ATTACH AND DETACH THE ACCESSORIES
1. Disconnect the appliances from the mains supply.
2. Allow the appliances to cool down completely if it has been heated.
3. Hold the appliance safely on hand and attach the accessory onto the steam head, it locks into position with audible click
4. After using the appliance, allow it to cool down completely. To detach the fabric brush, simply pull the top of the fabric brush.
5. If no accessory is in use, please keep steamer at least 5 cm away from cloth.
USING YOUR GARMENT STEAMER
NOTE: Before operating, make sure the appliance is unplugged and powered off.
1. Remove the water tank from main unit, then open the water inlet cover
2. Fill the water tank with appropriate amount of cold/normal water and then close the water inlet cover.
3. Assemble the water tank properly to the main unit
4. Connect the appliance to a suitable main supply outlet.
5. Once the appliance is plugged in, press the mode selector button (09), the display (11) will flash for 25 secs.
Once the light in display gets solid, the appliance is ready to use.
230 V AC
50 Hz
1600 W
320 mL
6. Press the mode selector button (09) to choose the desired output: Select icon (14) for powerful steam output,
select icon (15) for Eco mode, select icon (16) for Dry Heating mode.
7. Hang the wrinkled article of clothing on a clothes hanger.
8. Pull the clothing tight with one hand.
9. Gently press the steam head against the clothing and move the steamer down the fabric.
10. The steam will gently remove the wrinkles on clothes.
11. The thicker garment or tougher wrinkles may need to be steamed multiple times.
12. After steaming the clothes, let the garment cool down before wearing.
13. If there is a sound and no steam is generated, it means there is not enough water in water tank. Please check
the water tank and add water.
14. To turn off the appliances, press mode selector button (09) for 4 sec and display will turn off.
15. Disconnect the appliance from mains supply outlet.
16. When the appliance is turned on for 20mins, it will auto-shut off by itself and Auto-shut off icon (13) will flash.
This helps in saving power and keeping the unit in safe. If you need to re-start the appliance, press the mode
selector button again (09).
17. This appliance has a separate steam button (08). If you need steam, press steam button (08) once and the
appliance will produce steam continuously. To stop steam, re-press steam button (08), and the steam will turn
off.
18. When the steamer cools down completely, then empty the water remaining in the tank and store it in safe
place.
Warning: Do not touch the steam head while or after usage, until it cools down completely. Ceramic soleplate (04)
has heating function， do not touch it by hand.
Important: Do not apply steam on any clothes or fabrics that are being worn by human or pets. Temperature of
steam is high.
STORING THE APPLIANCE
When the steamer cools down completely, then empty the water remaining in the tank and store it in safe place
CAUTION: Empty all water from the unit. Water will go bad with time and may clog internal parts.
FOR BEST RESULTS
• Some articles can be steamed better by steaming from the underside.
• When steaming, touch material lightly with steam head and move up and down to remove wrinkles better. It
is important that you make contact with the garment and/or fabric.
• The Hand-held steamer will not remove stains from garments.
• Never steam clothes while wearing them.
• The Hand-held steamer works on most fabric, including silk, denim, cotton, polyester and wool.
• Please refer to label on item of clothing to check if garment can be steamed. In general, some fabrics, e.g.,
leather, suede and velvet may not be suitable for steaming.
• To ensure your garment is suitable for steaming, steam a small part of the inside of the garment to test that it
does not damage the fabric before steaming the entire garment or fabric.
• It is not recommended to use the garment steamer around the metal parts of the clothes. High temperature
steam will cause fading in metal fittings.
• Check if the inside of cloth is breathable, in order to not dampen the cloth with steam
• Check cloth pocket to ensure they are empty
• Check the inside of the garment for objects that are easily damaged by steam.
MAINTENANCE
After usage, unplug the garment steamer and allow it to cool completely, and empty the water tank.
NEVER USE ADDITIVES
Use of distilled or de-mineralized water will reduce the need to clean your steamer and will prolong its life, tap
water may be used as well but if you live in area with hard water mix equal proportion of tap and distilled water.
DO NOT use Additives such as cleaning agents, detergents, salt, perfumes, and dyes to the water tank. Some of
these substances are highly flammable which could result in serious bodily harm and some additives will corrode
or clog internal parts.
