ZKTeco ZK-IWBM User Manual

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

Product Name and Model Number

User Manual

ZK-IWBM

Date: August 2023

Doc Version: 1.0

English

Thank you for choosing our product. Please read the instructions

carefully before operation. Follow these instructions to ensure that the

product is functioning properly. The images shown in this manual are for

illustrative purposes only.

I n t e r f a c e

| 1

For further details, please visit our Company's website

www.zkteco.com.

User Manual

Table of Contents

Need help?

Do you have a question about the ZK-IWBM and is the answer not in the manual?

Questions and answers

Summary of Contents for ZKTeco ZK-IWBM

Page 1 The images shown in this manual are for illustrative purposes only. For further details, please visit our Company’s website www.zkteco.com. I n t e r f a c e Copyright©2020 ZKTECO CO., LTD. All rights reserved.
Page 2 User Manual Copyright © 2023 ZKTECO CO., LTD. All rights reserved. Without the prior written consent of ZKTeco, no portion of this manual can be copied or forwarded in any way or form. All parts of this manual belong to ZKTeco and its subsidiaries (hereinafter the "Company"...
Page 3 ZKTeco in no event shall be liable to the user or any third party for any incidental, consequential, indirect, special, or exemplary damages, including, without...
Page 4 Phone +86 769 - 82109991 +86 755 - 89602394 For business related queries, please write to us at: sales@zkteco.com. To know more about our global branches, visit www.zkteco.com. P a g e Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 5: About The Manual
ZK-IWBM User Manual About the Company ZKTeco is one of the world’s largest manufacturer of RFID and Biometric (Fingerprint, Facial, Finger-vein) readers. Product offerings include Access Control readers and panels, Near & Far-range Facial Recognition Cameras, Elevator/Floor access controllers, Turnstiles, License Plate Recognition (LPR) gate controllers and Consumer products including battery-operated fingerprint and face-reader door locks.
Page 6: Document Conventions
The information which is significant. Care taken to avoid danger or mistakes. The statement or event that warns of something or that serves as a cautionary example. P a g e Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 7: Table Of Contents
LAN INTERFACE ....................... 19 ......................19 ONTROL NTERFACE 3.6.1 RS232-IN INTERFACE ..................... 19 PANEL DESCRIPTION ................20 REMOTE CONTROL ................... 21 ..............21 RECAUTIONS FOR SE OF EMOTE ONTROL P a g e Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 8 USB CAMERA ........................32 6.8.3 ACTIVE PEN ........................33 6.8.4 AI CAMERA ........................33 ......................... 34 ALLPAPER ........................35 ATE AND ........................... 35 ANGUAGE ........................ 36 OWER ETTINGS P a g e Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 9 ANAGER ........................45 ELCOME NFC ............................. 47 TECHNICAL PARAMETERS ............... 49 VGA D ......................49 ISPLAY HDMI D ....................... 49 ISPLAY ACCESSORIES ................... 50 TROUBLESHOOTING ................51 P a g e Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 11: Precautions
The main material of the LCD is glass, which is brittle. Do not apply pressure to the LCD to avoid damage. To prevent the panel from falling over, avoid placing it on an unstable a cell P a g e | 10 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 13: Panel Features
The panel includes professional whiteboard writing software that offers a variety of pens, drawing tools, and other features that enable writing and movement on the screen to enhance interactivity. P a g e | 12 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 14: Installation
Tighten the screws during installation to avoid panel damage and injury. The wall installation is shown in the figure below, ventilation space should be kept around the panel. P a g e | 13 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 15: Interface Connection
Some non-standard USB drives may not be recognized; so, please use standard USB drives instead. Recommend using USB 2.0 to upgrade software. P a g e | 14 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 16: Public Usb Interface
TOUCH-USB interface and the signal source are connected to the same device, the external device can be operated on the panel through the touch function. P a g e | 15 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 17: Type-C Interface
7 Technical Parameters. When the 4K@60Hz signal is played, the EDID version in the OSD menu need to be changed to EDID 2.0. P a g e | 16 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 18: Vag Interface And Audio-In Interface
The maximum number of connections is affected by the quality and length of HDMI cable, so it is recommended to use standard cable. P a g e | 17 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 19: Audio Interface
3.4.2 MIC Interface MIC interface can be connected to microphones. 3.4.3 AUDIO-OUT Interface AUDIO-OUT interface can be linked to either earphones or an external speaker. P a g e | 18 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 20: Internet Interface
IP addresses.) Control Interface 3.6.1 RS232-IN Interface After RS232-IN interface is connected to the computer, the panel can be operated through the computer. P a g e | 19 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 21: Panel Description
On-off switch, “I” means ON, “O” means OFF. Pen placement area. Pick up the pen and can quickly choose to enter the whiteboard or comment. P a g e | 20 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 22: Remote Control
Please dispose of waste batteries according to applicable environmental regulations. Do not expose batteries to hot environment, such as direct sunlight or fire. P a g e | 21 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 23: Buttons On Remote Control
The picture is for reference only. Please refer to the physical appearance of the remote control. The button function of the remote control may be different for different models. Please refer to the actual function. P a g e | 22 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 24: Basic Operation
The panel will not enter standby mode, regardless of whether there is a signal input or not. In the non-Android main interface, if there is no signal input within 15min, the panel will automatically enter the standby mode. P a g e | 23 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 25: Save Before Shutdown
Users can view time, date, USB drive information, network information, hotspot information and common software on the home page. Swipe right to view the welcome interface and swipe left to view all the applications. P a g e | 24 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 26: Sidebar
Date and Time, Language, Power Settings, Security, More Settings, and About. Comment Open comment. Multi-task View and manage background running processes. Manager Shutdown Turn off the OPS or the panel. P a g e | 25 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 27: Signal Source
Method 2: Open the sidebar, click the icon to enter the Signal Source interface, select a source and then click to switch. P a g e | 26 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 28: Source Settings
Half Screen Mode Open the sidebar, click the icon to move the screen down overall, and the click the Up button on both sides to exit. P a g e | 27 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 30: Network Settings
Select Auto, and the panel will automatically obtain an IP address and connect to the network. Select STATIC, and users need to manually enter the MAC address and IP address to connect it to the network. P a g e | 29 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 31: Hotspot
Open the sidebar, click the Network Settings > Hotspot to set the hotspot. Turn on the Hotspot option. Enter the hotspot name in the textbox P a g e | 30 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 32: Bluetooth
System Settings interface, click Open the sidebar, click the Network Settings > Bluetooth to set Bluetooth. Turn on the Bluetooth switch. Choose the Bluetooth device pair to connect. P a g e | 31 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 33: Device Management
6.8.2 USB Camera icon to enter the System Settings interface, click Open the sidebar, click the Device Management > USB Camera to connect the camera. P a g e | 32 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 34: Active Pen
AI Camera icon to enter the System Settings interface, click Open the sidebar, click the Device Management > AI Camera to set the AI camera. P a g e | 33 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 35: Wallpaper
1920*1080 or 3840*2160, but the file should not be to larger, so as not to import and affect the smooth operation of the system. P a g e | 34 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 36: Date And Time
24-hour format, time zone setting and date format. Language Open the sidebar, click the icon to enter the System Settings interface, click Language to set language and input method. P a g e | 35 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 37: Power Settings
Open the sidebar, click the icon to enter the System Settings interface, click Security to set close password, pattern password, digital password, NFC password, and view certification. P a g e | 36 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 38: More Settings
More Settings to set the smart lock and remote lock. About icon to enter the System Settings interface, click Open the sidebar, click the About to view the relevant information about of the panel. P a g e | 37 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 39: Comment
Background Process icon to enter the Background Process interface Open the sidebar, click the to view and manage the background running processes. P a g e | 38 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 40: Active Pen Setting Bar
Open the Whiteboard. Comment Comment on the current screen. Close Close the bar. Camera Click the Camera icon on the home page to enter the camera interface. P a g e | 39 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 41: Whiteboard
Menu, include brush, import notes, save file, background setting and quit. Share: Click to share the note via QR code or Email. Hide: Click to hide the sidebar. P a g e | 40 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 42 Loop selection: Click to create selection. Ruler: Click to create a ruler. Figure: Click to create a planer figure, a stereoscopic figure or a lattice template. P a g e | 41 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 43 Add: Click to add a new page. Page: Click to enter the previous page or next page. Preview: Click pagination to preview all pages. P a g e | 42 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 44: Screen Share
Open the EShare APP on the phone, and ensure the panel and phone are connected to the same network. Select the panel on the phone. P a g e | 43 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 45 If using IOS devices, users can mirror the screen directly. Click the iMirror icon on the home page to enter the share interface. P a g e | 44 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 46: Welcome Page
3.2.5 HDMI-IN Interface 3.2.4 Type-C Interface. Welcome Page On the home page, slide right to enter the welcome page. P a g e | 45 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 47 Music Insert music. Enlarge the font size. Reduce the size. Insert text Insert a new text. Bold font. Change font color. Reset Restore initial settings. P a g e | 46 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 48: Files Manager
Shortcut APP  Click the NFC icon on the home page to enter into the NFC interface. Click ADD Card to add a new NFC card. P a g e | 47 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 49 NFC password. Place the NFC card in the NFC sensing area. After the recognition is successful, users can swipe the NFC card to unlock the panel. P a g e | 48 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 50: Technical Parameters
1920*1080 60Hz HDMI Display Mode Mode Resolution Refresh Rate 720*480 70Hz 720*576 50Hz 1280*720 50Hz 1280*720 60Hz 1920*1080 50Hz 1920*1080 60Hz 3840*2160 30Hz 3840*2160 60Hz P a g e | 49 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 51: Accessories
Stylus 2pcs Eraser 1pcs Note: Some models are not equipped with USB A-B cable and HDMI cable as standard. Please refer to the actual configuration. P a g e | 50 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 52: Troubleshooting
Possible Cause: Improper adjustment. Wrong display mode. Solution: Use the auto adjustment function. Enter “PC Screen Adjustment” to adjust the horizontal or vertical position. P a g e | 51 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 54 The touch USB cable is way too long or of low quality. Solution: Check and change the corresponding interface of the touch USB cable. Change another shorter or better-quality touch USB cable. P a g e | 53 Copyright © 2023 ZKTECO CO., LTD. All rights reserved.
Page 55 ZKTeco Industrial Park, No. 32, Industrial Road, Tangxia Town, Dongguan, China. Phone : +86 769 - 82109991 : +86 755 - 89602394 www.zkteco.com Copyright © 2023 ZKTECO CO., LTD. All Rights Reserved.
