  • Page 2 (1-800-888-398) PROTON EDAR SDN. BHD. Centre of Excellence Complex Km33.8 Westbound Shah Alam Expressway 47600 Subang Jaya , Selangor Darul Ehsan , Malaysia.

  • Page 3: Table Of Contents

    37 Member Centre 10 Wi-Fi 10 Bluetooth 11 Personal Hotspot PROTON Link App Centre 12 System Message 39 PROTON Link Mobile App 13 Navigation 40 Home page 13 Starting the Navigation System 41 Dashboard 13 Main Interface Introduction 42 Map...

  • Page 5: Multimedia System

    Multimedia System Multimedia System Operation Instructions Therefore, it is up to the driver to decide which route is the most Notes to Users suitable. • Do not use mobile phone while • The speed limit stipulated by current driving. Park the vehicle in a safe road traffic regulations should be place first if you need to use the more...

  • Page 6: Prompt Message

    Multimedia System Multimedia System Prompt Message Graphics This manual provides relevant information of all models. Due to the variety of configurations, the descriptions in this Indicate the described object. manual may differ from the actual one of your vehicle. The vehicle you actually receive shall prevail.

  • Page 7: Basic Operation

    Multimedia System Multimedia System Basic Operation Home Screen The home screen is designed to give users the experience similar to that of an Android machines. As seen in the home screen, the left side is fixed for navigation and the right side is for widgets.

  • Page 8: Pull-Down Menu Introduction

    Multimedia System Multimedia System Pull-down Menu Introduction Swipe down to show Menu bar, all status can be quick switched. Including quick configure to Wi-Fi, Bluetooth, Wireless Data, Hotspot and daily vehicle settings, brightness and volume adjustment. Long press any shortcut switches to add or delete the quick configurations to pull-down menu bar.

  • Page 9: System Start-Up

    Multimedia System Multimedia System System Start-up When the system is under power off condition, users can start the system automatically by turning the ACC ON or turning the ignition ON. Start-up and Warning images will be displayed on the screen. Start-up Image Warning Image...
  • Page 10 Multimedia System Multimedia System...
  • Page 11 Multimedia System Multimedia System System System Click Settings → System : You can do system settings and information query. Functions include Software Update, VR Setting, Time Mode, Wi-Fi, Bluetooth, Hotspot, System message, Restore Factory Setting, Storage Information, and About (version information).

  • Page 12: Ota Software Update

    Click Settings → System → Software Update : You can check the available new version for updating. Note: During the update, keep the engine running. Power failure may cause the system update to fail. If the system cannot start normally, please contact PROTON authorised service center. Wi-Fi Click Settings →...

  • Page 13: Personal Hotspot

    Multimedia System Multimedia System The selected mobile devices will receive pairing notifications requesting to confirm the pairing process. Android : Click “Sync to Contacts” while connecting. IPhone : Ensure “Sync to Contacts” function enabled. If “Sync to Contacts” fails, click the device name to un-pair and attempt to reconnect the device.

  • Page 14: System Message

    Multimedia System Multimedia System System Message Click Settings → System → System Message : To look the system message, including the storage, version information and reset factory settings. Storage This display shows the storage space allocation status in the IHU. Storage space consists of 5 sections : System : Display amount of space used by system.

  • Page 15: Navigation

    Multimedia System Multimedia System Navigation Starting the Navigation System After starting up, click [Navigation] or say “Open Navigation” to voice command to open the navigation system. Main Interface Introduction Free Navigation Interface The navigation system is divided into two navigation modes which are the Free Navigation and Route Navigation : •...
  • Page 16 Multimedia System Multimedia System Screen description: Mode switch : Click to switch between 2D front up, 2D due North up and 3D front up modes. Road condition : Switch on and off real-time live traffic. Scale bar zoom : the current scale bar, you can change the scale bar size by “+” and “-”.
  • Page 17 Multimedia System Multimedia System Navigation settings : Click to enter the settings interface, favorites, map data reporting and other interfaces. Route Navigation Interface On the route navigation screen, touch anywhere on the map to enter route navigation touch screen, which will display the following operation buttons.
  • Page 18 Multimedia System Multimedia System Screen description: Full route browsing : Enter full route browsing mode; click “Overview”, to display all routes on the map. Exit navigation : Click to stop navigation and re-plan route. “...” button : The menu shows four action buttons. Refer to the following pictures and description when selecting this button.
  • Page 19 Multimedia System Multimedia System Route Edit: Edit the current Route, such as adding, deleting or changing the routes and adjusting the sequence of routes. Turn by turn: View all turn information of the current route. Settings: Click to enter the settings screen.

  • Page 20: Search Location

    Multimedia System Multimedia System Search Location Keyword Search Click the position of “Search main screen” to perform keyword search. You can enter keywords such as “hotel” to display the search results. Online Map Data Update Prerequisites: When the map data used in the current navigation is very old (approximately two years), an online full map data update will be triggered when launching the navigation.

  • Page 21: Vr Voice

    Voice Wake up [WAKE UP] Voice Control Calls • Wake up word:” Hi, Proton”. After Voice wakes up, common voice • Press VR button on steering wheel to commands that can be used for calls are wake up.
  • Page 22 Multimedia System Multimedia System Voice Control Audio • “Turn on Wi-Fi.” • “Turn on Bluetooth.” After Voice wakes up, common voice commands that can be used for music • “Open video.” and radio interaction are as below: • “Turn on hot spot.” •...
  • Page 23 Multimedia System Multimedia System Vehicle voice commands their corresponding functions are not limited to the examples above. The IHU is able to interpret other common phrases with clear instructions. Voice Control Inquiry After Voice wakes up, common voice commands that can be used for general inquiries are as below: •...
  • Page 24 Multimedia System Multimedia System...

  • Page 25: Multimedia

    Multimedia System Multimedia System Multimedia Radio Switch between FM and AM. Seek radio stations via scan. Previous station: automatically search for the last available radio station and play. Pause Radio : pause or play the radio station. Next station: automatically search for the last available radio station and play. Rebroadcast: Second rebroadcast from the current frequency, click this icon to seek the next station in the direction of +, play 5s, and continue to seek in the direction of + repeatedly, until it is returned to the starting frequency of SCAN.

  • Page 26: Usb And Bluetooth Music

    Multimedia System Multimedia System USB and Bluetooth Music Audio files supported based on the following formats: MP3, WMA, AAC, WAV, OGG, FLAC. Music files stored in USB flash drives can be read and played via the audio app in the IHU. Music and audio from a mobile phone can be played via Bluetooth connection with the IHU.

  • Page 27: Photos And Videos

    Multimedia System Multimedia System Photos and Videos The IHU supports the following image file formats: *.JPG , *.JEPG , *.PNG , *.GIF (static), and *.BMP. In the format of *. GIF, the first image in the truncated sequence is displayed. Images stored in USB flash drives can be viewed and displayed from the photo app.
  • Page 28 Multimedia System Multimedia System Videos stored in USB flash drives can be viewed and displayed on the IHU. The videos will be rearranged according to the respective folders. Please be aware that the IHU will not allow videos to be played while the vehicle is moving.

  • Page 29: Store 27 A-Store

    Multimedia System Multimedia System A-Store A-Store A-Store allows users to download preferred applications to be installed on the IHU. The A-Store provides a variety of software such as basic apps, music, weather, themes, and other relevant software and services provided by various partners for the users to download.
  • Page 30 Multimedia System Multimedia System...

  • Page 31: Phone

    Multimedia System Multimedia System Phone Bluetooth Connection Click [Settings] --> [Connect] --> [Bluetooth Switch] Enable Bluetooth, and turn on Bluetooth on mobile phone. Click [Available Devices] to search for available devices to be paired to the IHU.

  • Page 32: Dialing

    Multimedia System Multimedia System Then the mobile phone will receive pairing notification. Android: Click “Sync to Contacts” while connecting. iPhone: Ensure “Sync to Contacts” function is enabled. If “Sync to Contacts” fails, please click the device name to unpaired it and reconnect the device again.
  • Page 33 Multimedia System Multimedia System Call via contacts. Call via recent calls. Call via VR Voice. After awakening the VR Voice, calls can be made via the voice command.

  • Page 34: Answering And Hanging Up

    Multimedia System Multimedia System Answering and Hanging Up Answering and hanging up calls can be done via multi-function control buttons at the steering wheel. To answer and hang up via Voice without awakening the VR, please see Section 1.5 - VR Voice for voice commands.

  • Page 35: Theme

    Multimedia System Multimedia System Theme Switch Theme Click [Theme APP] --> [Theme] Choose from a selection of themes and switch between them for more personalization options according to user preferences.

  • Page 36: Switch Wallpaper

    Multimedia System Multimedia System Switch Wallpaper Click [Theme APP] --> [Wallpaper] Choose from the selected wallpapers and switch more personalized options between them according on user preferences.

  • Page 37: Switch Screensaver

    Multimedia System Multimedia System Switch Screensaver Click [Theme APP] --> [Screensaver clock] Switch to preferred screen saver and set screensaver for the screen lock page.
  • Page 38 Multimedia System Multimedia System...
  • Page 39 The user can access the Member Center using a guest account or by logging in with phone number and password. The PROTON Link application with the associated account linked to the vehicle upon purchase can also be used to scan the QR...
  • Page 40 Multimedia System Multimedia System After logging in, users can view their account information such as Nickname and Profile Picture. Internet data and purchased data can also be viewed in the Member Center.

  • Page 41: Proton Link App Centre

    For iOS mobile phone, vehicle you prefer. please search for “PROTON Link” in the Apple App Store. For Android mobile phone, please search for “PROTON Link” in the Google Play Store. For HuaWei mobile phone, please search for “PROTON Link”...

  • Page 42: Dashboard

    PROTON Link App Centre PROTON Link App Centre Dashboard home page shows weather information, vehicle status, dashboard Slide up the home page to view dashboard and internet data usage information. information, total range, total mileage, average fuel consumption, average Notification speed, oil pressure and electric parking brake (EPB) status.

  • Page 43: Remote Control

    PROTON Link App Centre PROTON Link App Centre Remote Control Press and hold this icon to sound the horn. Press and hold this icon to unlock the tailgate*. If the tailgate is not opened You are required to activate the PIN within 30 seconds.

  • Page 44: Poi Search

    PROTON Link App Centre PROTON Link App Centre POI Search Select a location by pressing your finger on the map to set your destination. A banner will pop up as follows: Press the search bar above the map Press this icon to send the target to enter the search interface.

  • Page 45: About "My Account

    PROTON Link App Centre PROTON Link App Centre About “My Account” Geo-fence Press icon to enter your exclusive Press icon at your map interface of page. your phone to set the fence range. When My account the vehicle exits or enters the set range,...

  • Page 46: Call Service

    PROTON Link App Centre PROTON Link App Centre Trip Log Call Service Press “Trip Log” to view your recent Note: In order to use this function, you travel history. need to set the contact number of your preferred service centre. Refer to topic “My service centre”.

  • Page 47: Settings

    Press “Preferred Service Centre” to customize and modify the details of your preferred service centre. Press “Change password” to modify your login password. Press “Language” and select the type of language you need. Press “About PROTON Link” to view the current version.
  • Page 48 DOM & MHR DOM & MHR NOV 2023 NOV 2023...
