Focus FPS-Plus Assembly Instructions

FOODSER VICE, LLC
Note:
Please dispose of loose, round plastic pieces. These are used to
separate the shelves for shipping purposes.
Helpful Hint:
When placing the plastic tapered sleeves onto the posts
(Step 1), slide the plastic tapered sleeves up or down on the post until you
feel it "snap" into the lines or grooves of the post. It is normal to have a
slight gap in-between the two pieces of the plastic tapered sleeves when
it is placed on the post.
Choose the desired height of the bottom shelf (for added
Step 1
stability, it is recommended that the bottom shelf is installed
no more than 6˝(2 – 3 lines) from the floor and the top
shelf no more than 6˝(2 – 3 lines) from the top.) Snap two
(2) plastic tapered sleeves, with the arrows facing up, at the
desired height on each post. (See Diagram #1) Shelves can
be adjusted every 1˝. (Note: Double grooves in the posts are
placed every 8th groove for simple shelf height reference.)
Place shelf on its side, making sure the wider portion of the
Step 2
four (4) round shelf collars are facing the bottom of the unit,
slide the top of the posts through the round shelf collars on
each corner of the shelves. Push the shelves firmly onto the
plastic tapered sleeves. (See Diagram #2)
After installing the bottom shelf, set the unit upright
Step 3
Snap the plastic tapered sleeves into place on posts at the
Step 4
next desired shelf height. Slide the shelf down from the top
of the posts onto the plastic tapered sleeves and repeat this
step for the remaining shelves. (Note: A rubber mallet may be
used to tap each corner of the shelves so they firmly install
onto the plastic tapered sleeves.) (Note: The leg levelers may
need to be utilized in order to make the unit level or flush
against the wall.)
HEAVY OBJECT S MUST BE PLACED--NOT
WARNIN G :
DROPPED--ONTO THE SHELVES! !
DIAG RAM 1
Top
FPS-Plus Polymer Shelving with SaniGard
Top
ASSEMBLY
INSTRUCTIONS
Anti-Microbial Protection
DIAG RAM 2
™
continued on backside
