The plant builder may include the present manual in the documentation for plant use. Re S.p.A. reserves the right to update its production and/or manuals without updating products already sold and previous manuals.
ELEFLEX Fan electrical connection diagram Only for brakes series B.1201 and B.17101, 110/220V BROWN WHITE CAPACITOR (not included) µF WHITE 110 V 220 V Rev. 01/20 3/10...
ELEFLEX Maintenance Replacement of magnetic powder, seal rings and bearings Step 1-2-3-4-5 Step 6-7-8 Step 9-10-11 Step 12-13 Rev. 01/20 4/10...
Page 8
ELEFLEX Remove the screws from the flange on the side opposite the cable. Then, remove both circlips (detail A) from the end of the rotor. Place the brake on some shims of at least 50mm. The flange kept fixed to the brake must be on top side. Use a press or tap with a mallet to extract the rotor (detail B) with the flange (detail C);...
ELEFLEX Guarantee Re S.p.A. guarantees this device against all defects relative to the materials and manufacturing for a period of 12 months from the date of delivery. Should your device develop operating faults during the guarantee period, please contact the Company’s agent in your country, or, if this is not possible, contact Re S.p.A.
ELEFLEX Revision history Nr. rev. Date Changes 04/16 11/04/2016 Inserted the fan electrical connection diagram. 11/16 15/11/2016 Inserted brake B. 55 01/20 15/01/2020 Added reference to RoHs Directive compliance in Warnings section Rev. 01/20 10/10...
