Apollo 55000-864 Installation Manual

Functional Test Data
O B F
UTPUT IT UNCTION
2 N U
OT SED
1
SELF TEST
1 =
ON
0 =
OFF
0
ZONE RESET
1 =
ON
0 =
OFF
Troubleshooting
Before investigating individual units for faults, it is very important to check that the system wiring
is fault free. Earth fault on a data loop or any ancillary zone wiring may cause communication
errors.
Many fault conditions are the result of simple wiring errors. Check all connections to the unit
and make sure that the correct value resistors are fi tted where necessary.
Fault fi nding
Problem Possible Cause
No response or missing Incorrect address setting
Incorrect loop wiring
Local supply missing
Fault condition reported Incorrect input wiring
Incorrect end-of-line resistor
Analogue value unstable Dual address
Loop data fault, data corruption
Refer to product PIN sheet for protocol compatibility
Constant Alarm Incorrect wiring
Incorrect end-of-line resistor fi tted
Isolator LED on Short-circuit on loop wiring
Wiring reverse polarity
Too many devices between isolators
www.acornfiresecurity.com
39214-523/Issue 1
I B F
NPUT IT UNCTION
2 N U
OT SED
1
SELF TEST CONFIRMED
1 =
TEST ON
0 =
TEST OFF
0
ZONE RESET CONFIRMED
1 =
RESET
0 =
OFF
www.acornfiresecurity.com
Locally Powered Zone Monitor
Installation Guide
General
The Locally Powered Zone Monitor, part no 55000-864, is supplied with a backbox for surface
mounting. It has an integral isolator as standard.
Note: The Locally Powered Zone Monitor is not designed for outdoor use unless it is mounted in
a suitable weatherproof enclosure.
Surface Mounting
1. Mount the backbox as required and install all cables for termination. Ensure that earth
continuity is maintained.
2. Remove the cover plate (if secured) from the Zone Monitor assembly by inserting the blade
of a terminal screwdriver into each of the four securing clips in turn, gently prising the outer
edge of the cover plate over the clips underneath. DO NOT USE EXCESSIVE FORCE.
3. Terminate all cables.
4. Gently push the completed assembly towards the backbox until the mounting holes are
aligned and secure with the two mounting screws provided. DO NOT OVERTIGHTEN.
5. Set the address of the unit as shown on page 3.
6. Finally, when commissioning is complete, fi t the cover plate by placing it in position,
observing the correct orientation (LEDs on the PCB must be aligned with viewing holes).
Apply pressure to the cover plate until all four clips are holding it in position.
