  • Page 1 Instruction Manual RSR-DMX 15-Channel DMX Controller 2024 Version 2.2.0...

  • Page 2: Installation

    fibre optics. 2 Installation Installation should only be carried out by a competent electrician. ● RSR-DMX modules should be mounted in areas that are adequately ventilated, dry, and outside of any metal-enclosed casings that may interfere with the wireless signal.
  • Page 3 DMX Output. The RJ45 port or three-way terminal port may be used. STEP 3: Fit the supplied cable clamps and ensure the cable is unable to move. STEP 4: Replace the cover and replace the screws. RSR-DMX Manual Version 2.2.0...

  • Page 4: Initial Checks

    The setup button can be used as a manual on/off switch to test the circuit. The internal LED on the unit will flicker when the module receives ANY Rako wireless message, which is a useful diagnostic indicator. This function becomes inactive after 20 minutes to avoid a nuisance light spill but can be re-activated by pressing the setup button.
  • Page 5 4. To put the device into setup mode, press and hold the button on the top right of the RSR-DMX, and the LED will begin to flash. Release the button; the LED should continue to flash. 5. Select ‘Device is in setup’, this will send an ‘Ident’ command to the device in setup mode, once this is complete, the LED on the device should no longer be flashing.
  • Page 6 5 Setting DMX Driver Addresses DMX drivers require an address in order to be controlled by the RSR-DMX, the number which is set on the DMX driver will relate to the starting address in the Room the RSR-DMX is programmed in, for example:...

  • Page 7: Colour Wheel

    Rako App, where selecting a colour will automatically mix the Channels without needing to do it individually. The colour wheel is not enabled by default, for a colour wheel to show in the Rako App, the Channels need to be labelled as below: Example: A colour wheel in the App called “Feature”...

  • Page 8: Appendix 1 - Wiring Example

    Appendix 1 - Wiring Example RSR-DMX Manual Version 2.2.0...
