Utilizzare esclusivamente l’alimentatore fornito in dotazione con il prodotto. Le informazioni riportate in questo manuale sono state compilate con cura, tuttavia Fracarro Radioindustrie S.r.l. si riserva il diritto di apportare in ogni momento e senza preavviso, miglioramenti e/o modifiche ai prodotti descritti nel presente manuale.
DESCRIZIONE DEL PRODOTTO La famiglia Wide Fiber è composta da 2 trasmettitori (OPT-TX WB1 e OPT-TX WB2) e 4 ricevitori ottici (OPT-RX WB1 SCD2, OPT-RX WB1 HV, OPT-RX WB2 SCD2 e OPT-RX WB2 HV) basati su 5 lunghezze d’onda, progettati per la distribuzione di segnali terrestri e satellitari in tecnologia Wide Band con la massima qualità...
ISTRUZIONI PER L’UTILIZZO Una volta installati, connessi alla rete ottica ed alimentati, i prodotti danno delle indicazioni sul loro stato di funzionamento attraverso una serie di LED, ognuno dedicato ad un singolo ingresso RF dei trasmettitori o ad ogni lunghezza d’onda ottica su cui lavorano i ricevitori.
SPECIFICHE TECNICHE Trasmettitori OPT-TX WB1 OPT-TX WB2 Codice Fracarro 270901 270904 Ingressi RF Banda di frequenza TV (88-790), SAT (290-2340) Livello RF di ingresso TV e SAT dBµV/Ch 65-91 (con 15 MUX) e 60-85 (con 60 TP) Connettore Tipo F Femmina...
SAFETY WARNINGS XXXX The product must only be installed by qualified persons, according to the local safety standards and regulations. Fracarro Radioindustrie is free from all civil and criminal responsibilities due to breaches of the current legislation derived from the improper use of the product by the installer, user or third parties.
PRODUCT DESCRIPTION The Wide Fiber family consists of 2 transmitters (OPT-TX WB1 and OPT-TX WB2) and 4 optical receivers (OPT-RX WB1 SCD2, OPT-RX WB1 HV, OPT-RX WB2 SCD2 and OPT-RX WB2 HV) based on 5 wavelengths, designed for the distribution of terrestrial and satellite signals in Wide Band technology with the highest quality through the passive PON (Passive Optical Network) network of the building's optical infrastructure.
Page 8
OPERATING INSTRUCTIONS XXXX Once installed, connected to the optical network and powered, the products give indications on their operating status through a series of LEDs, each dedicated to a single RF input of the transmitters or to each optical wavelength on which the receivers work.
TECHNICAL SPECIFICATIONS Transmitters OPT-TX WB1 OPT-TX WB2 Fracarro code 270901 270904 RF Inputs Frequency band TV (88-790), SAT (290-2340) RF input level TV and SAT dBµV/Ch 65-91 (with 15 MUX) and 60-85 (with 60 TP) Connector Type F Female Optical Output...
L’installation du produit doit être effectuée par du personnel qualifié conformément aux lois et aux normes locales sur la sécurité. Par conséquent, Fracarro Radioindustrie décline toute responsabilité civile ou pénale dérivant de violations des normes juridiques en vigueur et de l’utilisation incorrecte du produit de la part de l’installateur, de l’utilisateur ou de tiers.
DESCRIPTION DU PRODUIT La famille Wide Fiber se compose de 2 émetteurs (OPT-TX WB1 et OPT-TX WB2) et de 4 récepteurs optiques (OPT-RX WB1 SCD2, OPT-RX WB1 HV, OPT-RX WB2 SCD2 et OPT-RX WB2 HV) basés sur 5 longueurs d'onde, conçues pour la distribution de signaux terrestres et satellites en technologie Wide Band avec la plus haute qualité...
INSTRUCTIONS D’UTILISATION XXXX Une fois installés, connectés au réseau optique et alimentés, les produits donnent des indications sur leur état de fonctionnement à travers une série de LED, chacune dédiée à une seule entrée RF des émetteurs ou à chaque longueur d'onde optique sur laquelle fonctionnent les récepteurs.
SPÉCIFICATIONS TECHNIQUES Émetteurs OPT-TX WB1 OPT-TX WB2 Code Fracarro 270901 270904 Entrées RF Bande de fréquence TV (88-790), SAT (290-2340) Niveau RF de l'entrée TV et SAT dBµV/Ch 65-91 (avec 15 MUX) et 60-85 (avec 60 TP) Connecteur Type F Femelle...
Page 14
Esempio di istallazione 1 SAT Installation example 1 SAT Exemple d’installation 1 SAT ITA: I segnali di ingresso TV e SAT sono stabilizzati dall’ C.A.G. sia sul TX che sugli RX. Per il corretto funzionamento, assicurarsi di utilizzare dispositivi con filtri LTE/5G. ENG: The TV and SAT input signals are stabilized by the A.C.G.
Page 15
Esempio di istallazione 2 SAT Installation example 2 SAT Exemple d’installation 2 SAT...
Page 16
CONFORMITÉ AUX DIRECTIVES EUROPÉENNES ITA: Fracarro dichiara che i prodotti sono conformi alle direttive 2014/30/UE e 2011/65/UE, mentre i trasmettitori OPT-TX WB1 e OPT-TX WB2 sono conformi anche alla direttiva 2014/35/UE. Il testo completo della Dichiarazione di Conformità UE è disponibile al seguente indirizzo ce.fracarro.com...
