- Page 1 Installation manual SolarEdge EV Charger UK Version 1.01 Translation of the original instructions...
- Page 2 Document: V 1.01 Pages: 56 © SolarEdge Technologies | Version published: 08.2024 Customer Support https://www.solaredge.com/service/support SolarEdge Technologies © KEBA 2021 Specifications are subject to change due to further technical developments. Details presented may be subject to correction. All rights reserved. Reindlstraße 51, 4040 Linz, Austria, www.keba.com/emobility...
-
Page 3: Table Of Contents
Mounting the charging station ......................Connections and wiring............................Connection overview..........................Required tools.............................. Power supply ..............................Enable input X1 ............................Switch contact output X2 ........................Ethernet connection X3 and X4 (optional)..................Configuration................................DIP switch settings ............................. SolarEdge EV Charger UK 1000000282... - Page 4 General................................13.2 Power supply ..............................13.3 Socket / cable............................... 13.4 Ambient conditions ........................... 13.5 Interfaces................................ 13.6 Optional equipment ..........................13.7 Calibratable energy meter........................13.8 Dimensions and weight..........................14 UKCA ....................................14.1 UKCA Declaration of conformity ......................EV Charger UK 1000000282...
-
Page 5: Introduction
Introduction Introduction This manual is valid for the SolarEdge EV Charger. The pictured devices used in this manual are visual examples. The figures and explanations contained in this manual refer to a typical device design. The devices used by you may differ in their appearance. -
Page 6: Purpose Of The Document
Purpose of the document This document describes the complete installation of the SolarEdge EV Charger. This document is an extension of the supplied manuals for the SolarEdge EV Charger. You must comply with all instructions and safety notes in the supplied manuals! -
Page 7: Warranty
Introduction Warranty Only general maintenance work that is expressly permitted by SolarEdge Technologies may be performed. Any other tampering to the device will result in a loss of the warranty claim. WARNING! Risk of electric shock and fire hazard! After the front part has been opened, product safety can no longer be guaranteed. -
Page 8: Notes On This Document
Commissioning of the charging station ● Maintenance of the charging station 1.6.2 Not contained in this document ● Operation of the charging station ● Troubleshooting Further documentation Manuals and additional information are available on our website: www.solaredge.com/resource-library SolarEdge EV Charger UK 1000000282... -
Page 9: Safety Notes
Using adapters of any kind is forbidden. Persons who, due to their special training, expertise and experience as well as knowledge of current standards, are able to assess the work performed and the possible hazards. SolarEdge EV Charger UK 1000000282... - Page 10 Never clean the charging station with aggressive solvents and cleaning agents, abrasive materials, spray water (garden hose, high-pressure cleaner, etc.) or excessive pressure. SolarEdge EV Charger UK 1000000282...
-
Page 11: Scope Of Delivery
Power supply line (top/surface- Cable gland M32x1.5 12 – 22 mm mounted cable installation) Locknut M32x1.5 Cable gland M16x1.5 Data line (top/ surface-mounted 4 – 10 mm with seal ring cable installation) SolarEdge EV Charger UK 1000000282... - Page 12 Mounting set for wall installation Fig. 3-3: Mounting set for wall installation b-series Description e-series c-series x-series Hangar bolts M8x100 Nut ISO 10511 - M8 Washer ISO 7089 - 8.4 Anchors for M10; Fischer UXR-10 SolarEdge EV Charger UK 1000000282...
-
Page 13: Description Of The Charging Station
Fig. 4-4: Overview of charging station ... Housing cover ... RFID reader (optional) ... LED bar ... Permanently installed charging cable (optional) ... Charging socket with cover (optional) ... Holder for charging cable (optional) ... Display (optional) SolarEdge EV Charger UK 1000000282... -
Page 14: Rear View
... Flush-mounting cable insertion openings M20 (for control line or Ethernet) Top view Fig. 4-6: Top view ... Type plate ... Surface-mounting cable insertion openings M32 (for supply line) ... Surface-mounting cable insertion openings M16 (for control line or Ethernet) SolarEdge EV Charger UK 1000000282... -
Page 15: Type Plate
... Product designation ... Material number ... Technical data ... CE marking of conformity ... MID type examination number ... MID accuracy class ... MID marking ... Serial number ... Production site / date ... UKCA marking SolarEdge EV Charger UK 1000000282... -
Page 16: Options
This chapter lists the possible options of the charging station. 4.5.1 RFID The RFID reader is used for the non-contact authorization of a charging process with MIFARE cards or tags according to ISO 14443 and ISO 15693. Fig. 4-8: RFID ... RFID reader SolarEdge EV Charger UK 1000000282... -
Page 17: Displays And Operating Elements
The display may show different information depending on the operating status (e.g., software version, IP address, authorization request). The main task, however, is to display the status of the internal energy meter. The display lights up through the housing and is only visible when the power supply is active. SolarEdge EV Charger UK 1000000282... -
Page 18: Mounting And Installation Instructions
Special hollow-wall anchors must be used for the other mounting screws. It is particularly important to make sure the substructure has sufficient load-bearing capacity. Fig. 6-11: Water drainage ... Water drainage ... Mounting surface ... Charging station SolarEdge EV Charger UK 1000000282... - Page 19 Do not tighten the mounting nuts with force. The tightening torque must not exceed 7 Nm. The mounting surface must be completely flat. Warpage of the housing must be prevented. If adjustment is necessary, the four remaining supplied washers must be used. SolarEdge EV Charger UK 1000000282...
-
Page 20: General Criteria For The Site Selection
The charging process can also subsequently be switched off. ● Observe the permissible environmental conditions (see "Technical data"). Observe the internationally valid installation standards (e.g. IEC 60364-1 and IEC 60364-5-52) and comply with the nationally applicable installation standards and regulations. SolarEdge EV Charger UK 1000000282... -
Page 21: Space Requirements
1.2 m. Observe that national regulations can limit this height. Required tools The following tools are required for the installation: ● Drill Ø 10 mm (suitable for the wall material) ● Screwdriver/bit T25 ● Socket wrench 13 mm SolarEdge EV Charger UK 1000000282... -
Page 22: Mounting The Charging Station
(Surface-mounting cable installation: Cable insertion openings on the top side / Flush-mounting cable installation: Cable insertion openings on the back side) Insert the cable glands (surface-mounted cable installation) or double-membrane seals (flush- mounted cable installation) into the corresponding cable insertion openings. SolarEdge EV Charger UK 1000000282... - Page 23 ... Rear wall of the charging station ... Washer for nut ... Nut ... Hanger bolt ... 20 mm Turn the hanger bolts into the hole / anchors until the thread still protrudes approx. 20 mm (x). SolarEdge EV Charger UK 1000000282...
- Page 24 Position the charging station on the wall and secure it with the 4 washers (3) and nuts (4) to the hanger bolts (5). The charging station is now mounted on the wall and ready for cabling. SolarEdge EV Charger UK 1000000282...
-
Page 25: Connections And Wiring
The fuse on the fuse holder F1 must not be used to switch off the charging station. To interrupt the power supply, always use the line circuit breaker. The connection panel is never permitted to be left open unattended. Before leaving the charging station, the connection panel cover must be mounted. SolarEdge EV Charger UK 1000000282... -
Page 26: Required Tools
(see temperature rating of the supply terminals)! Under certain circumstances, this can lead to an increase of the cable cross- section and to the adaptation of the temperature resistance of the power supply line. SolarEdge EV Charger UK 1000000282... -
Page 27: Cable Installation
(approx. cable diameter times 10). ● For surface-mounted cable installation, the cable gland must be installed properly and screwed sufficiently tightly from the rear of the charging station, otherwise water may enter. SolarEdge EV Charger UK 1000000282... - Page 28 As shown below, the M32 cable entry opening must be used for this. Drilling a cable entry opening is not permitted. Fig. 7-17: Use of the M20 cable gland with reduction insert Use of M16 cable gland (surface-mounted) To use the supplied M16 cable gland, the supplied sealing ring must be used. SolarEdge EV Charger UK 1000000282...
-
Page 29: Connecting The Voltage Supply
Do not press the screwdriver up, down or to the side! To connect the supply voltage, proceed as follows: Shorten the connection wires to the appropriate length (as short as possible). The protective conductor must be longer than the other conductors! SolarEdge EV Charger UK 1000000282... - Page 30 The charging station is set to 10 A in the delivery state. In order to adapt the maximum current to the installed line circuit breaker, configuration via the DIP switches is necessary. For details, see DIP switch settings. SolarEdge EV Charger UK 1000000282...
-
Page 31: Enable Input X1
Fig. 7-18: Connection to a three-wire IT system with 230 V Enable input X1 This function is not available. Input X1 is occupied by the tamper protection sensor. Note Any tampering will result in non-compliance of the device. Do not unplug the sensor. SolarEdge EV Charger UK 1000000282... -
Page 32: Switch Contact Output X2
Pair Color Color 1 (Tx+) white/green stripe white/orange stripe 2 (Tx−) green/white stripe or orange/white stripe or green orange 3 (Rx+) white/orange stripe white/green stripe 4 (Rx−) orange/white stripe or green/white stripe or orange green SolarEdge EV Charger UK 1000000282... -
Page 33: Preparing The Connection Cable
To connect the cable, proceed as follows: Fix the connecting cable at the point of the wrapped-around shielding braid in the shield clamp [K]. Tighten the shield clamp. Clamp the wires to the terminal block [ETH] using an insertion tool. SolarEdge EV Charger UK 1000000282... -
Page 34: Configuration
To restart, press the "Service button" until the first beep (approx. 1 second) or switch off the charging station for a short time via the line circuit breaker. In the following tables, only the affected DIP switches are shown in the illustrations, others are not shown. SolarEdge EV Charger UK 1000000282... - Page 35 Amperage Illustration DSW1.6 Setting available from software ≥1.18.00 / firmware DSW1.7 ≥3.10.56 (for details see „10.3 Display software/firmware DSW1.8 version“) DSW1.6 DSW1.7 10 A DSW1.8 DSW1.6 DSW1.7 13 A DSW1.8 DSW1.6 DSW1.7 16 A DSW1.8 SolarEdge EV Charger UK 1000000282...
- Page 36 10: 1 + 2 + 0 + 8 + 10 = 21 Sum of the DIP switch values + 10 Thus, the addresses 11 to 25 can be set. SolarEdge EV Charger UK 1000000282...
- Page 37 This DIP switch setting must be made for each master and DSW2.5 client charging station to enable charging station communication. Commissioning mode - DSW2.8 DIP switch Function Illustration Activate commissioning mode. DSW2.8 For details, see 9.1 Activating/deactivating commissioning mode. SolarEdge EV Charger UK 1000000282...
-
Page 38: Commissioning
A normal charging process is not possible in commissioning mode. Note For safety reasons, the commissioning mode is indicated on the charging station by an orange display on segment S3 of the LED bar (-/-/orange/-). SolarEdge EV Charger UK 1000000282... - Page 39 Set DIP switch DSW2.8 to OFF (see DIP switch settings). Restart the charging station by pressing the "Service button" until the first beep (approx. 1 second). The charging station starts up again in normal mode and is ready for operation. SolarEdge EV Charger UK 1000000282...
-
Page 40: Perform Safety Checks
For devices with MID approval, at least the terminal cover must be secured with a lead seal. For devices with national approval, the connection panel cover must be secured with a lead seal. To mount all covers, proceed as follows: SolarEdge EV Charger UK 1000000282... - Page 41 Hook in the housing cover at the top and close it at the bottom 2. The housing cover must glide into the guides without considerable resistance. The housing cover must be correctly seated in the housing guide on all sides. SolarEdge EV Charger UK 1000000282...
-
Page 42: Attach Seal
Close the cover of the sealing cap. Thread the sealing wire through the opening of the sealing cap over the screw and place the seal. The seal is attached. If necessary, reinstall all other covers of the charging station. SolarEdge EV Charger UK 1000000282... -
Page 43: Maintenance
Screw the fuse holder counterclockwise until it automatically springs forward due to its spring. Replace the fuse. Press the fuse holder in and tighten it clockwise. Mount the housing covers on the charging station again. The fuse has now been replaced. SolarEdge EV Charger UK 1000000282... -
Page 44: Troubleshooting
Enter the IP address of the respective charging station in a web browser. The simplified web interface is displayed. The currently running firmware version is displayed in the "Software" line (e.g: v 3.10.53). Fig. 10-19: Simplified web interface (status) SolarEdge EV Charger UK 1000000282... -
Page 45: Software Update
The software of the charging station must therefore always be kept up to date, as it may contain security updates, functional enhancements and bug fixes. For a software update ask SolarEdge Technologies. The information and instructions for the current software package from the associated release notes must also be observed. -
Page 46: Support
System configuration information, including the type and number of modules connected and the number and length of strings. ● The communication method to the SolarEdge server, if the site is connected. ● The product's software version as it appears in the status screen. -
Page 47: Disposal
● The materials are recyclable in accordance with their labeling. You can make an important contribution to protecting our environment by reusing, renewing and recycling materials and old appliances. SolarEdge EV Charger UK 1000000282... -
Page 48: Technical Data
8 A / 10 A / 13 A / 16 A / 20 A / 25 A / 32 A Line frequency: 50 Hz Mains forms: TT / TN / IT Power loss Socket: 20 W at 22 kW SolarEdge EV Charger UK 1000000282... -
Page 49: Socket / Cable
-25 °C to +40 °C (without direct sunlight) Storage temperature: -25 °C to +80 °C Relative air humidity: 5 % to 95 % (non condensing) Altitude: max. 2000 m above sea level Rate of temperature change: max. 0.5 °C / min SolarEdge EV Charger UK 1000000282... -
Page 50: Interfaces
IEEE 802.11 b,g,n, 2.4 GHz Supported modes: AP Ad-hoc-Mode, Client Mode 13.7 Calibratable energy meter Meter type: Electricity meter for active power Measurement type: Converter measurement Non-return device: Electronic Minimum current: 0.15 A Reference current: SolarEdge EV Charger UK 1000000282... -
Page 51: Dimensions And Weight
-25 °C to +55 °C accuracy: Overflow of the counter: 99.999 kWh Accuracy class: Class B (according to EN 50470-1 / -3) 13.8 Dimensions and weight Version with standard socket (Type 2) Fig. 13-20: Dimensions in millimeters SolarEdge EV Charger UK 1000000282... - Page 52 Technical data Version with charging cable and holder Fig. 13-21: Dimensions in millimeters SolarEdge EV Charger UK 1000000282...
-
Page 53: Ukca
Regulations 2017. The full text of the UK declaration of conformity is available at the following internet Address: (*2) (*1) Variants Form designation system Example: KC-P30- VIII Basic serie KC-P30 ...Device generation (KeContact-P30) Basic type G ...GB / United Kingdom ...Socket outlet Interface ...Charging cable SolarEdge EV Charger UK 1000000282... - Page 54 X2 functionality 0 ...Switch contact output ...No authorisation ...RFID, PLC Authorisation ...PLC ...RFID xx ...Options for individual customer versions, Customer options not relevant for UK Declaration of Conformity (*2) www.keba.com/emobility-downloads SolarEdge EV Charger UK 1000000282...
- Page 56 SolarEdge Technologies www.solaredge.com...
