SC5815
4 Burner BBQ
with Cabinet Trolley
PLEASE ENSURE YOU PROTECT YOUR
BBQ WHEN NOT IN USE BY USING A
QUALITY COVER
Please read
all instructions
thoroughly
before use
Before using the
BBQ, remove any
packaging material
within and around
the BBQ supplied
for protection
during transit.
assembly &
operating
manual
MAN01
Advertisement
Table of Contents
Related Manuals for Sunco living SC5815
Summary of Contents for Sunco living SC5815
- Page 1 SC5815 4 Burner BBQ with Cabinet Trolley assembly & PLEASE ENSURE YOU PROTECT YOUR BBQ WHEN NOT IN USE BY USING A operating QUALITY COVER manual Please read all instructions thoroughly before use Before using the BBQ, remove any packaging material...
-
Page 2: Table Of Contents
CONTENTS FEATURES & BENEFITS IMPORTANT INFORMATION & SAFETY SAFETY DO`S AND DON`TS INSTALLATION & ASSEMBLY POSITIONING THE BARBECUE PORTABLE GAS CYLINDERS LEAK TEST USING THE BARBECUE MAINTAINING YOUR BARBECUE TROUBLESHOOTING CONNECTING NATURAL GAS BBQ CARE INSTRUCTIONS PARTS DIAGRAM ASSEMBLY INSTRUCTIONS LIST OF SPARE PARTS WARRANTY CONTACT INFORMATION... -
Page 3: Features & Benefits
FEATURES & BENEFITS THERMASTONE COOLTOUCH Ceramic tiles provide even Cooltouch hood brings heat distribution from the burners safety to your gas barbecue. below whilst absorbing the fat and Our double insulated hood MXLFHV WR HOLPLQDWH ÀDUHXSV:LWK reduces the outer roasting DQ DWWUDFWLYH ¿QLVK WKH\ DUH DOVR hood temperature by up to VHOI FOHDQLQJ VLPSO\ WXUQ WKHP... -
Page 5: Safety
SAFETY How do I use a Propane (AUS) or LPG (NZ) Appliance Setting Up The Drip Tray Safely? · Line the primary drip tray with foil. · Put a fat absorbent material NOT sand or kitty litter The safety record for gas appliances in Australia and New in the small secondary drip tray. -
Page 6: Do`s And Don`ts
DO`S DON`TS Have propane (Aus)/LPG (NZ) cylinder (LP units) Don’t install the barbecue closer than 430mm on filled by an authorised LPG supplier. the sides or 430mm in the back to any combustible surface or less than 1 meter beneath any overhead Check all gas line connections for leaks with a combustible construction. -
Page 7: Installation & Assembly
INSTALLATION & ASSEMBLY It is important to read these instructions After connecting the gas supply, turn on the gas thoroughly. If you have any problems, contact the ensuring all gas valves are in the OFF position and manufacturer or contact the retailer. check for leaks by brushing a soap and water solution over all joints. -
Page 8: Positioning The Barbecue
POSITIONING THE BARBECUE This appliance should only be used in an above ground, The following figures are diagrammatical open air situation with natural ventilation, without stagnant representaions of outdoor areas described. areas, where gas leakage and products of combustion Rectangular areas have been used in these figures - are rapidly dispersed by wind and natural convection. -
Page 9: Portable Gas Cylinders
PORTABLE GAS CYLINDERS What is Propane (AUS) / LPG (NZ)? How do I use the Gas Cylinder? Propane and LPG are fuel gas compressed until it turns Most Propane (AUS) / LPG (NZ) cylinders work basically to liquid, then stored in a bottle or cylinder under pressure the same. -
Page 10: Leak Test
LEAK TEST Before lighting your barbecue it is important to carry out this simple test to check whether the gas cylinder, hose and regulator are working / connected correctly. NEVER TEST FOR GAS LEAKS USING A LIT MATCH OR OTHER NAKED FLAME soap MAN10... -
Page 11: Using The Barbecue
USING THE BARBECUE LIGHTING INSTRUCTIONS USING THE JET FLAME IGNITION PREHEATING Light the burners as previously directed and turn to Turn on the gas cylinder. HI and allow the barbecue to preheat for 2 - 5 minutes. With the barbecue hood open, push in and turn PREPARE THE COOKING SURFACE any gas knob in an anti-clockwise direction to the It is preferable to apply a light coat of cooking oil using... -
Page 12: Maintaining Your Barbecue
MAINTAINING YOUR BARBECUE Lift and swing out the burner from position as shown CARING FOR THE BURNERS & INJECTORS below. To ensure continued satisfaction from your barbecue it is essential to keep the burners and injectors clean. Under normal usage, your barbecue should be left burning for five minutes after cooking has ceased. -
Page 13: Troubleshooting
TROUBLESHOOTING My BBQ will not light properly. Why? ‡ 7KHQ UHIHU WR WKH /,67 2) 63$5( 3$576 WR LGHQWLI\ ‡ &KHFN /3* JDV VXSSO\ WKH PLVVLQJ SDUW V DQG JR WR RXU *DUWK 6XSSRUW ZHEVLWH www.garthsupport.com RU FRQWDFW XV RQ RXU ‡... -
Page 14: Connecting Natural Gas
CONNECTING NATURAL GAS This barbecue model is approved for conversion from ULPG / Propane to Natural Gas. The following steps are required to complete the conversion: 1. Contact a registered Gas Fitter / Plumber to obtain a 3. Upon completion of the conversion, the Gas Fitter / quote for the conversion and to confim whether this Plumber is LEGALLY required to issue a Compliance appliance will work efficiently with the current gas... -
Page 15: Bbq Care Instructions
BBQ CARE INSTRUCTIONS GAS CYLINDERS cleaned from the surface before the barbeque is first heated. If this is not Store cylinders in a well-ventilated area and use done properly, finger marks may become a cylinder sealing plug or a Gasfuse to reduce etched into the finish permanently;... -
Page 16: Stainless Steel Maintenance
Half fill a bucket with clean warm water and steel wool or a nylon / plastic type using a barbeque brush or scourer constantly scrubber. Do not use normal steel wool, soaked with water, scrub the cooking surface as it will contaminate the finish and thoroughly. -
Page 17: Parts Diagram
PARTS DIAGRAM FOR SC5815 4 X Phenolic Spacers 1 X Cabinet Right Side Panel 1 X Cabinet Back Panel 4 X Steel Spacers 4 X Legs 1 X Cabinet Left Side Panel 1 X REGULATOR COVER 4 X Castors 1 X Gas Cylinder Bowl... -
Page 18: Assembly Instructions
ASSEMBLY INSTRUCTIONS MAN18... - Page 19 4 X 5mm Hexagon Bolts 4 X 5mm Steel Washers 8 X 6mm Long Bolts MAN19...
- Page 20 MAN20...
- Page 21 4 X 5mm Short Bolts 4 X 5mm Steel Washers 4 X 5mm Short Bolts 4 X 5mm Steel Washers MAN21...
- Page 22 4 X Castors 6 X 6mm Short Bolts 6 X 6mm Steel Washers 6 X 6mm Nuts MAN22...
- Page 23 MAN23...
- Page 24 2 X 5mm Short Bolts MAN24...
- Page 25 MAN23...
-
Page 26: List Of Spare Parts
LIST OF SPARE PARTS MAN26... - Page 27 PART NUMBER PART NAME SUPPLIER CODE AVAILABLE OR NOT Hood inner SC5913-H-01 Rear burner cover SC5912-B-09 Hood hinge screw SC5912-H-05 Hood hinge support bracket SC5912-H-06 Hood hinge SC5912-H-07 Rubber bumper K2224-CB Temperature gauge bezel BS060206 Temperature gauge N06022 Temperature gauge bowl TG-B01 Cast iron hotplate B03159...
- Page 28 Phenolic spacer BPS-006 Cabinet side panel SC5913-T-05 Steel spacer PS-003 Cabinet leg SC5913-T-07 Cabinet rear panel SC5812-T-04 Bolt pack BP-SC5815 Side shelf SC5912-T-03 Side shelf handle SC6112-T-07 Magnet DRSP-8 Side burner shelf lid SC5912-T-11 Side burner shelf SC5912-T-12 Ignition wire...
-
Page 29: Warranty
LIMITED 12 MONTH / 5 YEAR WARRANTY BBQs DEFINITIONS WARRANTY Subject to subclauses 2.4 and 2.5, if a defect appears In this Warranty: in the Product at any time within the period of 12 months Care Instructions means the instructions for care from the Date of Purchase the Manufacturer will at its of the Product described in clause 6;... -
Page 30: Limitation Of Liability
LIMITED 12 MONTH / 5 YEAR WARRANTY BBQs LIMITATION OF LIABILITY The Manufacturer is under no obligation to respond to The benefits given by this warranty are in addition to any other rights and remedies that the Consumer may any claim made by the Consumer under this warranty have under any law which applies in relation to supply which is not a Compliant Claim. - Page 31 For service and warranty queries, please go to www.garthsupport.com Your purchase receipt will be required for warranty claims.
