SC79-15
4 BURNER
OUTDOOR KITCHEN
PLEASE ENSURE YOU PROTECT YOUR
BBQ WHEN NOT IN USE BY USING A
QUALITY COVER
Please read
all instructions
thoroughly
before use
Before using the
BBQ, remove any
packaging material
within and around
the BBQ supplied for
protection during transit.
assembly &
operating
manual
MAN01
Advertisement
Table of Contents
Related Manuals for Sunco living SC79-15
Summary of Contents for Sunco living SC79-15
- Page 1 SC79-15 4 BURNER OUTDOOR KITCHEN assembly & PLEASE ENSURE YOU PROTECT YOUR BBQ WHEN NOT IN USE BY USING A operating QUALITY COVER manual Please read all instructions thoroughly before use Before using the BBQ, remove any packaging material within and around the BBQ supplied for protection during transit.
-
Page 2: Table Of Contents
CONTENTS FEATURES & BENEFITS IMPORTANT INFORMATION & SAFETY SAFETY DO`S AND DON`TS INSTALLATION & ASSEMBLY POSITIONING THE BARBECUE PORTABLE GAS CYLINDERS LEAK TEST USING THE BARBECUE TEPPANYAKI LIGHTING INSTRUCTIONS MAINTAINING YOUR BARBECUE TROUBLESHOOTING CONNECTING NATURAL GAS BBQ CARE INSTRUCTIONS PARTS DIAGRAM ASSEMBLY INSTRUCTIONS LIST OF SPARE PARTS WARRANTY... -
Page 3: Features & Benefits
FEATURES & BENEFITS COOLTOUCH Cooltouch hood brings safety to your gas barbecue. Our double insulated hood reduces the outer roasting hood temperature by up to 25%. This helps to reduce burning if accidently touched. Teppanyaki Unit Sink Unit Enclosed cabinet Enclosed cabinet with gas bottle with gas bottle... -
Page 4: Important Information & Safety
IMPORTANT INFORMATION AND SAFETY This barbecue has been tested and certified in DATA PLATE: accordance with Australia Standards AS 4557:2004 /RFDWHG RQ WKH ERG\ RI \RXU EDUEHFXH \RX ZLOO ILQG WKH VLOYHU GDWD ODEHO ZKLFK FRQWDLQV LPSRUWDQW LQIRUPDWLRQ and is approved for sale and distribution in Australia UHODWLQJ WR WKH WHVWLQJ DQG DSSURYDO RI WKLV SURGXFW DV and New Zealand. -
Page 5: Safety
SAFETY How do I use a Propane (AUS) or LPG (NZ) Appliance Setting Up The Drip Tray Safely? · Line the primary drip tray with foil. · Put a fat absorbent material NOT sand or kitty litter The safety record for gas appliances in Australia and New in the small secondary drip tray. -
Page 6: Do`s And Don`ts
DO`S DON`TS Have propane (Aus)/LPG (NZ) cylinder (LP units) Don’t install the barbecue closer than 430mm on filled by an authorised LPG supplier. the sides or 430mm in the back to any combustible surface or less than 1 meter beneath any overhead Check all gas line connections for leaks with a combustible construction. -
Page 7: Installation & Assembly
INSTALLATION & ASSEMBLY It is important to read these instructions After connecting the gas supply, turn on the gas thoroughly. If you have any problems, contact the ensuring all gas valves are in the OFF position and manufacturer or contact the retailer. check for leaks by brushing a soap and water solution over all joints. -
Page 8: Positioning The Barbecue
POSITIONING THE BARBECUE This appliance should only be used in an above ground, The following figures are diagrammatical open air situation with natural ventilation, without stagnant representaions of outdoor areas described. areas, where gas leakage and products of combustion Rectangular areas have been used in these figures - are rapidly dispersed by wind and natural convection. -
Page 9: Portable Gas Cylinders
PORTABLE GAS CYLINDERS What is Propane (AUS) / LPG (NZ)? How do I use the Gas Cylinder? Propane and LPG are fuel gas compressed until it turns Most Propane (AUS) / LPG (NZ) cylinders work basically to liquid, then stored in a bottle or cylinder under pressure the same. -
Page 10: Leak Test
LEAK TEST Before lighting your barbecue it is important to carry out this simple test to check whether the gas cylinder, hose and regulator are working / connected correctly. NEVER TEST FOR GAS LEAKS USING A LIT MATCH OR OTHER NAKED FLAME OUTDOOR USE ONLY OUTDOOR USE ONLY DO NOT OPERATE THIS APPLIANCE BEFORE... -
Page 11: Using The Barbecue
USING THE BARBECUE LIGHTING INSTRUCTIONS USING THE JET FLAME IGNITION PREHEATING Light the burners as previously directed and turn to Turn on the gas cylinder. HI and allow the barbecue to preheat for 2 - 5 minutes. With the barbecue hood open, push in and turn PREPARE THE COOKING SURFACE the any gas knob in an anti-clockwise direction It is preferable to apply a light coat of cooking oil using... -
Page 12: Teppanyaki Lighting Instructions
TEPPANYAKI LIGHTING INSTRUCTIONS FOR MANUAL IGNITION USING THE WOK BURNER ROTARY IGNITION Light a 90mm barbecue match and hold Turn on the gas cylinder. adjacent to the lighter hole at the right end of the unit to light the pressing burner as With the barbecue lid open, push in and turn left gas shown below. -
Page 13: Maintaining Your Barbecue
MAINTAINING YOUR BARBECUE Lift and swing out the burner from position as shown CARING FOR THE BURNERS & INJECTORS below. To ensure continued satisfaction from your barbecue it is essential to keep the burners and injectors clean. Under normal usage, your barbecue should be left burning for five minutes after cooking has ceased. -
Page 14: Troubleshooting
TROUBLESHOOTING My BBQ will not light properly. Why? ‡ 7KHQ UHIHU WR WKH LIST OF SPARE PARTS WR ‡ &KHFN /3* JDV VXSSO\ LGHQWLI\ WKH PLVVLQJ SDUW V DQG JR WR RXU *DUWK 6XSSRUW ZHEVLWH www.garthsupport.com RU FRQWDFW XV RQ RXU ‡... -
Page 15: Connecting Natural Gas
CONNECTING NATURAL GAS This barbecue model is approved for conversion from ULPG / Propane to Natural Gas. The following steps are required to complete the conversion: 1. Contact a registered Gas Fitter / Plumber to obtain a 3. Upon completion of the conversion, the Gas Fitter / quote for the conversion and to confim whether this Plumber is LEGALLY required to issue a Compliance appliance will work efficiently with the current gas... -
Page 16: Bbq Care Instructions
BBQ CARE INSTRUCTIONS GAS CYLINDERS cleaned from the surface before the barbeque is first heated. If this is not Store cylinders in a well-ventilated area and use done properly, finger marks may become a cylinder sealing plug or a Gasfuse to reduce etched into the finish permanently;... - Page 17 Half fill a bucket with clean warm water and steel wool or a nylon / plastic type using a barbeque brush or scourer constantly scrubber. Do not use normal steel wool, soaked with water, scrub the cooking surface as it will contaminate the finish and thoroughly.
-
Page 18: Parts Diagram
PARTS DIAGRAM FOR SC79-15 1 : Magnet 3 : Cabinet Left 1 : BBQ Unit Cabinet 3 : Cabinet Right 1 : BBQ Unit Cabinet Side Panels Back Panel Side Panels Base Section 1 : BBQ Unit Cabinet Top Panel 2 : Teppanyaki &... -
Page 20: Assembly Instructions
ASSEMBLY INSTRUCTIONS 4 : M5 X 35mm 4 : M5 2: M8 x 45mm 2: M8 4: M8 MAN20... - Page 21 16 : M5 X 15mm 16 : M5 4 : M5 X 15mm 4 : M5 MAN21...
- Page 22 8 : M5 X 15mm 8 : M5 2: M4 x 10mm 2: M4 2: M4 MAN22...
- Page 23 4 : M5 X 35mm 4 : M5 MAN23...
- Page 24 2: M6 x 28mm 2: M8 2: M5 2: M5 x 6mm MAN24...
- Page 25 4 : M5 X 35mm 4 : M5 16 : M5 X 15mm 16 : M5 MAN25...
- Page 26 4 : M5 X 15mm 4 : M5 8 : M5 X 15mm 8 : M5 MAN26...
- Page 27 8 : M5 X 15mm 8 : M5 MAN27...
- Page 28 4 : M5 X 35mm 4 : M5 MAN28...
- Page 29 4 : M5 X 35mm 4 : M5 16 : M5 X 15mm 16 : M5 MAN29...
- Page 30 4 : M5 X 15mm 4 : M5 8 : M5 X15mm 8 : M5 MAN29...
- Page 31 8 : M5 X 15mm 8 : M5 MAN31...
- Page 32 A 12mm tap nut is required for this outdoor kitchen, please contact the local supplier to purchase. (NOT INCLUDED) 1 : Drainage Top 1 : Bottom Rubber Ring 1 : Sink 1 : Top Rubber Ring 1 : Drainage Bottom 1 : Drainage Hose MAN32...
- Page 33 1 : Drainage Connector 1 : Drainage Plug MAN33...
- Page 34 4 : M5 X 35mm 4 : M5 MAN34...
- Page 35 4 : M5 X 15mm 4 : M5 4 : M5 X 50mm 4 : M5 WARNING: Do not lift the appliance by side shelf handle! MAN35...
-
Page 38: List Of Spare Parts
LIST OF SPARE PARTS For spare parts refer to your store of purchase. For warranty visit: www.garthsupport.com MAN38... - Page 39 PART NUMBER PART NAME SUPPLIER CODE AVAILABLE OR NOT Rubber bumper K2224-CB Hood outer SC79-H-01 Temperature gauge N06022 Temperature gauge bowl TG-B01 Temperature gauge bezel BS060206 Hood handle SC79-H-02 Hood inner SC79-H-03 B03105 Warming rack Fascia SC79-B-01 SP89-K8 Hotplate B03075-M Grill S/S pressed burner N1314...
- Page 40 MAN40...
- Page 41 PART NUMBER PART NAME SUPPLIER CODE AVAILABLE OR NOT Lid handle SC79-H2-01 SC79-H2-02 Teppanyaki frame SC79-B2-01 Side Burner Trivet SB005 Wok burner TMB001-2 Spill bowl SB002 Wok burner base TMB001-1 Elbow nut TMA0503 Ignition holder TMA0508 Wok burner elbow TMA0504 Venturi TMA0707 Wok burner under strut...
- Page 42 MAN42...
- Page 43 PART NUMBER PART NAME SUPPLIER CODE AVAILABLE OR NOT GSM0703 Sink frame SC79-B3-01 Cabinet top panel SC79-T3-01 Cabinet side panel SC79-T-02 Cabinet rear panel SC79-T2-02 Cabinet bottom panel SC79-T3-02 Magnet MG01 Door hinge bracket SC3212-T-09 Drainage set GSM008B Cabinet front panel SC79-T2-04 Door hinge SC3212-T-11...
-
Page 44: Warranty
LIMITED 12 MONTH / 5 YEAR WARRANTY BBQs DEFINITIONS WARRANTY Subject to subclauses 2.4 and 2.5, if a defect appears In this Warranty: in the Product at any time within the period of 12 months Care Instructions means the instructions for care from the Date of Purchase the Manufacturer will at its of the Product described in clause 6;... - Page 45 LIMITED 12 MONTH / 5 YEAR WARRANTY BBQs LIMITATION OF LIABILITY The Manufacturer is under no obligation to respond to The benefits given by this warranty are in addition to any other rights and remedies that the Consumer may any claim made by the Consumer under this warranty have under any law which applies in relation to supply which is not a Compliant Claim.
- Page 46 For service and warranty queries, please go to www.garthsupport.com Your purchase receipt will be required for warranty claims.
