UH-3X3VW: 4K60 HDMI2.0 Video Wall Processor Statement Thanks for purchasing this product, please read this user manual carefully before using this product. Pictures are shown in this manual for reference only. Different models and specifications are subject to real product. -
Page 4: Safety Precaution
UH-3X3VW: 4K60 HDMI2.0 Video Wall Processor Safety Precaution To ensure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. Do not dismantle the housing or modify the module to avoid electrical shock or ⚫... -
Page 5: Table Of Contents
Packing List ........................2 Panel Description ....................... 3 System Connection/ Installation Procedures..............5 3.1 Usage Precautions ...................... 5 3.2 System & Connection Diagram UH-3X3VW ............5 3.3 Connection Instructions ....................6 RS232 Control ........................7 Dip Switch .........................10 FAQ ............................12 Technical Specification ....................13... -
Page 6: Introduction
UH-3X3VW: 4K60 HDMI2.0 Video Wall Processor 1 Introduction 1.1 Product Introduction Thanks for choosing the 4K60 HDMI 2.0 Video Wall Processor UH-3X3VW. This product is a 1-in-9-out video wall controller, supports one HDMI source input and nine HDMI outputs. Supports 1x2/1x3/1x4/2x2/2x3/3x2/2x4/4x2/ 3x3 splicing modes, which can be set by RS-232 or dip switch. -
Page 7: Packing List
UH-3X3VW: 4K60 HDMI2.0 Video Wall Processor 1.3 Packing List 1x UH-3X3VW: 4K60 HDMI 2.0 Video Wall Processor with 9 video wall modes ⚫ 2x Mounting Ears ⚫ 6x Mounting Screws ⚫ 1x Grounding Screw ⚫ 1x Terminal Block ⚫ 1x Power Adapter (12V, 2A) ⚫... -
Page 8: Panel Description
UH-3X3VW: 4K60 HDMI2.0 Video Wall Processor 2 Panel Description Figure 2-1 UH-3X3VW ① DC12V Power input: Connect with DC 12V/2A power adapter. ② HDMI signal input: Connect HDMI signal source. ③ HDMI signal output x9: Connect with HDMI splicing display devices. - Page 9 UH-3X3VW: 4K60 HDMI2.0 Video Wall Processor ⑫ Reset: 1) Press to restart the video wall controller; 2) Press and hold for 5 seconds to restore factory settings (wait until the status indicator is flashing fast to let go). Note: Pictures shown in this manual are for reference only, different model and specifications are subject to real product.
-
Page 10: System Connection/ Installation Procedures
3.2 System & Connection Diagram UH-3X3VW The following diagrams illustrates the typical input and output connection that can be utilized with 4K60 HDMI2.0 Video Wall Processor UH-3X3VW: Figure 3-1 Connection and System Diagram: Normal Usage Note: Pictures shown in this manual are for reference only, different model and specifications are subject to real product. -
Page 11: Connection Instructions
UH-3X3VW: 4K60 HDMI2.0 Video Wall Processor 3.3 Connection Instructions Step 1 Connect the controller with the signal source and splicing screen through HDMI cable. Step 2 According to the number of splicing screens, the matching splicing mode can be selected by dip switch. -
Page 12: Rs232 Control
UH-3X3VW: 4K60 HDMI2.0 Video Wall Processor 4 RS232 Control Insert the terminal into the controller and connect it to external equipment. The three pins are GND/ RXD/ TXD, and the splicing mode can be set by RS232 instruction. The default is as follows: Baud rate: 9600;... - Page 13 UH-3X3VW: 4K60 HDMI2.0 Video Wall Processor ‘XX’ represents the baud rate value Baud XX\n 9600 (default), 19200, 38400, 57600, 115200 Example Control command 1 ES 04 On\n Open the ‘04’HDMI port Functional details Return value Received successfully ES 04 On OK...
- Page 14 UH-3X3VW: 4K60 HDMI2.0 Video Wall Processor Notes: 1) "\n" means line break. 2) Splice mode can be switched by "RS-232" or "DIP switch". Only when the dip switch is set to "1111", the splice mode can be switched by RS-232 command.
-
Page 15: Dip Switch
UH-3X3VW: 4K60 HDMI2.0 Video Wall Processor 5 Dip Switch Built-in 9 splicing mode can be switched by dip switch. dip switch means ‘1’ up, dip switch means ‘0’down, and the default is ‘1000’ . Dip switch state Splicing mode horizontally... - Page 16 UH-3X3VW: 4K60 HDMI2.0 Video Wall Processor vertically horizontally vertically horizontally Switch RS-232 U.T.E. electronic GmbH & Co. KG www.ute.de...
-
Page 17: Faq
UH-3X3VW: 4K60 HDMI2.0 Video Wall Processor 6 FAQ Picture quality is not fluent and stable? 1) Please check and make sure all HDMI cables are connected well. 2) Try to connect the source device to display device directly, or change to another source device for a try to see the picture quality. -
Page 18: Technical Specification
UH-3X3VW: 4K60 HDMI2.0 Video Wall Processor 7 Technical Specification Video Signal HDMI Input (1) HDMI HDMI Output (9) HDMI HDMI 2.0 Compatibility HDCP 1.4 / HDCP 2.2 Input: 4096x2160@24/25/30/50/60Hz， 3840x2160@24/25/30/50/60Hz， 3440x1440@60Hz，2560x1600@60Hz， 2560x1440@60Hz，2560x1080@60Hz， 1920x1200@60Hz Output: Resolutions When the mode is 0000/0001/0010, the maximum output is 1080P@30Hz;... - Page 19 UH-3X3VW: 4K60 HDMI2.0 Video Wall Processor Power Input:100V~240V AC; Power Supply Output: 12V DC 2A Power Consumption 17W (max.) Operating Environment Operation Temperature -20 to +60℃ Storage Temperature -30 to +70℃ Relative Humidity 0% to 90%, non-condensing Physical Properties Housing...
-
Page 20: After-Sales / Customer Service
UH-3X3VW: 4K60 HDMI2.0 Video Wall Processor 8 After-sales / Customer Service Any transport costs are borne by the users during the warranty. The return of a product to our Customer Service implies the full agreement of the terms and conditions hereinafter. There terms and conditions may be changed without prior notice. - Page 21 UH-3X3VW: 4K60 HDMI2.0 Video Wall Processor 5) Technical Support: Email to our after-sales department or make a call, please inform us the following information about your cases. ⚫ Product version and name. ⚫ Detailed failure situations. ⚫ The formation of the cases.
- Page 22 UH-3X3VW: 4K60 HDMI2.0 Video Wall Processor U.T.E. electronic GmbH & Co. KG www.ute.de...
- Page 23 UH-3X3VW: 4K60 HDMI2.0 Video Wall Processor U.T.E. electronic GmbH & Co. KG www.ute.de...
- Page 24 U.T.E. electronic GmbH & Co. KG Tel: +49-2302-28283-0 Fax: +49-2302-28283-10 Email: info@ute.de Website: www.ute.de U.T.E. electronic GmbH & Co. KG www.ute.de...
