- Page 1 User Manual UH-2X2VW 4K60 HDMI2.0 Video Wall Processor All Rights Reserved Version: UH-2X2_2022V1.0 www.ute.de...
- Page 2 UH-2X2VW: 4K60 HDMI2.0 Video Wall Processor U.T.E. electronic GmbH & Co. KG www.ute.de...
- Page 3 UH-2X2VW: 4K60 HDMI2.0 Video Wall Processor Statement Thanks for purchasing this product, please read this user manual carefully before using this product. Pictures are shown in this manual for reference only. Different models and specifications are subject to real product.
- Page 4 UH-2X2VW: 4K60 HDMI2.0 Video Wall Processor U.T.E. electronic GmbH & Co. KG www.ute.de...
- Page 5 UH-2X2VW: 4K60 HDMI2.0 Video Wall Processor Safety Precaution To ensure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. Do not dismantle the housing or modify the module to avoid electrical shock or ⚫...
-
Page 6: Table Of Contents
2.1 Front Panel ....................... 2 2.2 Rear Panel ......................2 System Connection ....................3 3.1 Usage Precautions ................... 3 3.2 System & Connection Diagram UH-2X2VW ............. 3 3.2.1 Normal Usage ..................3 3.2.2 Cascade Usage ..................4 4 Video Wall Modes ..................... 4 5 IR Remote ......................... -
Page 7: Introduction
The unit supports 1 HDMI input and 4 HDMI outputs. HDMI input supports resolutions up to 4Kx2K@60Hz 4:4:4 and output resolution is fixed to be 1920x1080p@60Hz. UH-2X2VW supports 9 video wall modes, which can be selected via front panel button and IR remote. -
Page 8: Panel Description
UH-2X2VW: 4K60 HDMI2.0 Video Wall Processor 2 Panel Description 2.1 Front Panel Figure 2-1 UH-2X2VW Front Panel ① POWER LED: The LED illuminates green when power is applied. ② IR: Built-in IR sensor to receive IR signal.. ③ AUDIO: Press the button to turn on/off audio output. -
Page 9: System Connection
3.2 System & Connection Diagrams UH-2X2VW The following diagrams illustrates the typical input and output connection that can be utilized with 4K60 HDMI2.0 Video Wall Processor UH-2X2VW: 3.2.1 Normal Usage Figure 3-1 Connection and System Diagram: Normal Usage ... -
Page 10: Cascade Usage
UH-2X2VW: 4K60 HDMI2.0 Video Wall Processor 3.2.2 Cascade Usage Figure 3-2 Connection and System Diagram: Cascade Usage 4 Video Wall Modes User can press the button on the front panel or IR remote to toggle 9 video wall modes. Figure 4-1 Video Wall Modes ... -
Page 11: Ir Remote
UH-2X2VW: 4K60 HDMI2.0 Video Wall Processor 5 IR Remote The 4K60 HDMI2.0 Video Wall Processor UH-2X2VW has a built-in IR sensor to receive IR control signal from IR remote (included). ① Standby button: Press it to enter/ exit standby mode. -
Page 12: Technical Specification
UH-2X2VW: 4K60 HDMI2.0 Video Wall Processor 6 Technical Specification Video Input Input (1) HDMI Input Connector (1) Type-A female HDMI, 19 pin HDMI Input Resolution Up to 4K@60Hz 4:4:4 HDMI Standard HDCP Version 2.2, 1.4 compliant Video Output Output (4) HDMI... - Page 13 UH-2X2VW: 4K60 HDMI2.0 Video Wall Processor General RGB, YCbCr 4:4:4, 4:2:0 Color Format [YCbCr 4:2:2 is not supported] Color depth 24-bit, 30-bit or 36-bit deep color Audio Format Supports PCM2.0 Output Latency < 1ms Operation Temperature -5 to +55℃ (+23° to +131°F) Storage Temperature -25 to +70℃...
-
Page 14: After-Sales / Customer Service
UH-2X2VW: 4K60 HDMI2.0 Video Wall Processor 7 After-sales / Customer Service Any transport costs are borne by the users during the warranty. The return of a product to our Customer Service implies the full agreement of the terms and conditions hereinafter. There terms and conditions may be changed without prior notice. - Page 15 UH-2X2VW: 4K60 HDMI2.0 Video Wall Processor 5) Technical Support: Email to our after-sales department or make a call, please inform us the following information about your cases. ⚫ Product version and name. ⚫ Detailed failure situations. ⚫ The formation of the cases.
- Page 16 U.T.E. electronic GmbH & Co. KG Tel: +49-2302-28283-0 Fax: +49-2302-28283-10 Email: info@ute.de Website: www.ute.de U.T.E. electronic GmbH & Co. KG www.ute.de...
