Operating Instructions
Hand Test Pump BHP 700
Contents
1.
2.
3.
4.
5.
6.
7.
8.
9.
1.
1
• The manual is aimed at specialists and semi-skilled
2
personnel.
2
• Please read the instructions carefully before carry-
2
ing out any operation and keep the specified order.
3
• Thoroughly read and understand the information in
3
chapter 2 "Safety Instructions".
4
4
If you have any problems or questions, please contact
your supplier or contact us directly at:
4
5
6
6
7
7
ARMANO Messtechnik GmbH
Location Beierfeld
8
Am Gewerbepark 9 • 08344 Grünhain-Beierfeld
8
Tel.: +49 3774 58 - 0 • Fax: +49 3774 58 - 545
mail@armano-beierfeld.com
Location Wesel
Manometerstraße 5 • 46487 Wesel-Ginderich
Tel.: +49 2803 9130 - 0 • Fax: +49 2803 1035
mail@armano-wesel.com
www.armano-messtechnik.com

Information on This Operating Instruction

B10-112
08/24

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BHP 700 and is the answer not in the manual?

Questions and answers

Related Manuals for ARMANO BHP 700

Summary of Contents for ARMANO BHP 700

  • Page 1: Table Of Contents

    B10-112 Operating Instructions Hand Test Pump BHP 700 08/24 Contents Information on This Operating Instruction Information on This Operating Instruction • The manual is aimed at specialists and semi-skilled 1.1 Pictographs Used personnel. 1.2 Exclusion of Liability • Please read the instructions carefully before carry- Safety Instructions ing out any operation and keep the specified order.

  • Page 2: Pictographs Used

    Qualified personnel: ed with this pictograph. The personnel that is charged for the installation and operation of the BHP 700 must hold a relevant quali- The following symbol highlights fication. This can be based on training or relevant tui- actions you have to conduct tion.

  • Page 3: Device Description

    Intended Use item, pressure hose, reference gauge) if the hand test pump is under pressure: The hand test pump BHP 700 shall only be used for Æ Open the pressure relief valve before removing pressure generation in small-volume measuring any of the components.

  • Page 4: Technical Data (Pump With Hose)

    Operating Instructions Hand Test Pump BHP 700 Technical Data (Pump with Hose) Pressure range overpressure 700 bar Medium Hydraulic oil Purified water temperature −10 to +60 °C 0 to 60 °C range (14 to 140 °F) (32 to 140 °F)

  • Page 5: Commissioning With Ventilation

    Æ Tightly screw the adapter for the test item onto the Æ Never put the BHP 700 into operation if MINIMESS® adapter. you found any damage. Immediately re- Æ Turn the test item with seal into the adapter.

  • Page 6: Operation

    Operating Instructions Hand Test Pump BHP 700 Operation Notes on the operation: Please pay attention to the following notes concern- Adhere to the following safety instructions when ing the operation of the hand test pump: operating the hand test pump: •...

  • Page 7: Pressure Measurements

    Operating Instructions Hand Test Pump BHP 700 Pressure increase with the fine adjustment valve: Relief the Pressure Alternatively, you can increase the pressure with the fine adjustment valve. Once the pressure measurements have been com- Æ Turn the handwheel of the valve clockwise towards pleted, the overpressure in the hand test pump, in the stop of the pump body.

  • Page 8: Maintenance / Cleaning, Storage And Transport

    Æ send the hand test pump back to your supplier or for cleaning. to the ARMANO Messtechnik GmbH. • Avoid contact with liquid or aggressive media. © 2024 ARMANO Messtechnik GmbH · Technical changes, replacement of materials and printing errors excepted! www.armano-messtechnik.com...
