Operating Instructions
Hand Test Pump BHP 40
Contents
1.
2.
3.
4.
5.
6.
7.
8.
9.
1.
1
• The manual is aimed at specialists and semi-skilled
2
personnel.
2
• Please read the instructions carefully before carry-
2
ing out any operation and keep the specified order.
3
• Thoroughly read and understand the information in
3
chapter 2 "Safety Instructions".
3
4
If you have any problems or questions, please contact
4
your supplier or contact us directly at:
5
5
6
6
7
7
ARMANO Messtechnik GmbH
Location Beierfeld
8
Am Gewerbepark 9 • 08344 Grünhain-Beierfeld
8
Tel.: +49 3774 58 - 0 • Fax: +49 3774 58 - 545
mail@armano-beierfeld.com
Location Wesel
Manometerstraße 5 • 46487 Wesel-Ginderich
Tel.: +49 2803 9130 - 0 • Fax: +49 2803 1035
mail@armano-wesel.com
www.armano-messtechnik.com
Information on This Operating Instruction
B10-111
08/24
Advertisement
Table of Contents
Related Manuals for ARMANO BHP 40
Summary of Contents for ARMANO BHP 40
-
Page 1: Table Of Contents
B10-111 Operating Instructions Hand Test Pump BHP 40 08/24 Contents Information on This Operating Instruction Information on This Operating Instruction • The manual is aimed at specialists and semi-skilled 1.1 Pictographs Used personnel. 1.2 Exclusion of Liability • Please read the instructions carefully before carry- Safety Instructions ing out any operation and keep the specified order. -
Page 2: Pictographs Used
Qualified personnel: instructions that have to be strictly observed. The personnel that is charged for the installation and operation of the BHP 40 must hold a relevant qualifi- cation. This can be based on training or relevant tui- Exclusion of Liability tion. -
Page 3: Device Description
This en- sures that no pressure can be generated by unin- The hand test pump BHP 40 shall only be used for tentional pumping movements. pressure or vacuum generation in air. The use of oth- •... -
Page 4: Design And Function
Operating Instructions Hand Test Pump BHP 40 Design and Function The generated pressure or vacuum is indicated on the reference gauge and compared with the meas- Controls: ured value of the test item. Handles With the knurled nut , the spring preload can be ad- Fine adjustment valve (handwheel) justed and the pump stroke can be limited. -
Page 5: Operation
Operating Instructions Hand Test Pump BHP 40 Operation CAUTION! Material damage test item! Observe the maximum pressure of the The generation of pressure and the generation of vac- test item! Only generate an initial pressure uum do not only differ concerning operation proce-... -
Page 6: Generating Vacuum
Operating Instructions Hand Test Pump BHP 40 Operation steps pressure generation: Æ Generate vacuum: Æ If necessary, switch on the reference gauge and • Push the handles together: the test item. The spring generates the first negative pres- Æ Close the pressure relief valve: sure, but cannot open the handles completely. -
Page 7: Relieving Pressure / Balancing Vacuum
Operating Instructions Hand Test Pump BHP 40 Practical / Useful Advices Relieving Pressure / Balancing Vacuum Once the pressure or vacuum measurements have Spring preload / stroke limitation: been completed, the positive or the negative pres- The spring preload changes the restoring force of the sure in the hand test pump, the test item and in the handles. -
Page 8: Maintenance / Cleaning, Storage And Transport
Æ Bring the hand test pump to your local recycling plant Æ send the hand test pump back to your supplier or to the ARMANO Messtechnik GmbH. © 2024 ARMANO Messtechnik GmbH · Technical changes, replacement of materials and printing errors excepted! www.armano-messtechnik.com...
