Kohler ELOSIS K-24654T Installation Instructions

BEFORE YOU BEGIN
● Please read these instructions carefully to familiarize yourself with the required
tools, materials, and installation sequences. Follow the sections that pertain to
your particular installation. This will help you avoid costly mistakes. In addition
to proper installation, read all operating and safety instructions.
● All information in these instructions is based upon the latest product
information available at the time of publication. Kohler China. reserves the
right to make changes in product characteristics, packaging, or availability at
any time without notice.
● These instructions contain important care, cleaning, and warranty
information-please leave instructions for the consumer.
● Before installation carefully inspect the new fixture for any signs of damage.
● The product complies with GB/T10357.4-2013, GB/T10357.5-2013 and
GB24977-2010.
ORDERING INFORMATION
This installation covers the following products in the ELOSIS mirrored cabinet
range:
ELOSIS Mirrored Cabinet1526...............................................................K-24658T
ELOSIS Mirrored Cabinet2026...............................................................K-24657T
ELOSIS Mirrored Cabinet2526...............................................................K-24656T
ELOSIS Mirrored Cabinet3026...............................................................K-24655T
ELOSIS Mirrored Cabinet3526...............................................................K-24654T
ROUGHING-IN
Reference Value
参考值
K-24658T
251
PARTS
Parts supplied with your cabinet. (For cabinet body and door replacement, call
customer service with model number.) Be sure to check the cardboard supports
in the carton, glass parts are packed in them.
ZHONGSHAN KOHLER SHOWER CO., LTD. NO13-1, XINGYE ROAD, ZHONGSHAN TORCH
1354622 -T01-B
381
380
505
762
K-24655T
Kohler reserves the right to change marked dimensions without prior notice.
科勒公司保留随时变更图中标示尺寸的权利，无需另行通知。
DEVELOPMENT ZONE, ZHONGSHAN, GUANGDONG, CHINA POST CODE: 528437
中山科勒卫浴有限公司 广东省中山市中山火炬开发区兴业路 13-1 号 邮编 : 528437
INSTALLATION INSTRUCTIONS 安装说明书
K-24654T/K-24655T/K-24656T/K-24657T/K-24658T
安装之前
● 请仔细阅读本指引，以便熟悉所需工具、物料及安装程序。请遵照适用的章节
来安装本产品， 以免安装失当导致不必要的损失。除了有关正确的安装方法之外，
还务请详阅所有操作及安全指引。
● 本指引所载之一切资料，均以印刷时所有之最新产品情况为基础，科勒中国保
留权利随时更改产品特性、包装或供应情况，恕不另行通知。
● 说明书包括重要的安装、清洁及保养方面的内容，请把这些资料交给用户阅读，
保管。
● 安装之前，仔细检查产品是否有损伤。
● 本产品符合 GB/T10357.4-2013、GB/T10357.5-2013 和 GB24977-2010。
订购信息
此安装说明书适用于以下艾洛诗镜柜系列家具的安装：
艾洛诗镜柜 1526 ...................................................................................K-24658T
艾洛诗镜柜 2026 ...................................................................................K-24657T
艾洛诗镜柜 2526 ...................................................................................K-24656T
艾洛诗镜柜 3026 ...................................................................................K-24655T
艾洛诗镜柜 3526 ...................................................................................K-24654T
尺寸图
505
508
K-24657T
379
配件
浴柜附有零件 ( 柜身及门的补换请致电客服部门并告知型号 )，请仔细检查包装箱。
- 1 -
ELOSIS 艾洛诗
MIRRORED CABINET 镜柜
251 378
635
K-24656T
505
890
K-24654T
© Copyright Kohler China Investment Co., Ltd. 2020
© 版权为科勒 ( 中国 ) 投资有限公司所有 2020
UNIT: mm
单位 : 毫米
