AUREL TX uP/LP User Manual

uP Keyfob with Keeloq Coding
TX-uP/LP Keyfob must be used in pair with RX-uP/LP Receiver in order to guarantee correct operation of
wake up of the receiver, furthermore thanks to the Keeloq* alghoritm it ensures an high level safety.
The low battery level signalization is carried out through an Led (Look to the battery substitution character).
Types available
TX-2M-uP/LP: 2 buttons Keyfob
TX-4M-uP/LP: 4 buttons Keyfob
Technical Specification
Reception Frequency
Effective Radiated Power
Modulation
Power supply (CR2032)
Current consumption in Tx
Current consumption in stand-by
Battery life
Serial identification Code length
Hopping Code Length
Combination possible
Working Temperature
Dimensions
(1)
: 70 sec per day as average timing transmission ( 14 transmission of 5 sec/each).
* Keeloq is a Microchip trademark
The technical features can change without forecasting. AUR°EL S.p.A doesn't assume any responsability of demage due to the improper use of the device.
AUR°EL S.p.A. Via Foro dei Tigli, 4 - 47015 Modigliana (FC) – ITALY
Tel.: +390546941124 – Fax: +390546941660
http://www.aurel.it - email: aurel@aurel.it
Min Typical Max
433.82 433.92 434.02
0.5 1.0
OOK
2.2 3 3.3
10 15
1.0 2.0 3.0
(1)
3 5
28
32
2³²
-10 +55
75 x 40 x 16
TX uP/LP
User Manual
Transmission
Led
Unit
MHz
mW
On-Off Keying
V
mA
uA
years
bit
bit
°C
mm
Rev. A - 30.08.2024
Page 1 of 2
