Load Output; Direction For Use - JS LED HM-12RGB5A3-10A3RC4 Manual

Load output

Direction for use

● Connect the load wire at first, following by the power wire;
between connecting wire before you turn on the power；
● Adopt film button control and RF control, function of remote control is with the same of panel. There
are 8keys in total, function of each button as below:：
Symbol
interface:
Button Name
The output switch. In any state，you could turn on or turn
On/Off
off the output of controller;
Play/Pause key. When you want to see the static affection
Pause
of led , you may press this button to pause.
The speed changing progression will add one when you
Speed up
press the button every time, there are 100 steps ;
The speed changing progression will subtract one when
Speed down
you press the button every time.
Adopt the Screw terminal
Please ensure short circuit can not occur
Instruction
3/6
