- Page 1 ASSEMBLY INSTRUCTIONS COASTER FINE FURNITURE Fine Furniture for every stage of life 2734 Vanity Set REVISION 0: 07/06/2018 REVISION 1: 05/02/2019 PAGE 1 OF 6 COASTERFURNITURE.COM...
-
Page 2: Assembly Tips
2734 ITEM: ASSEMBLY INSTRUCTIONS ASSEMBLY TIPS: 1. Remove hardware from box and sort by size. 2. Please check to see that all hardware and parts are present prior to start of assembly. 3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly. -
Page 3: Hardware Identification
2734 ITEM: HARDWARE IDENTIFICATION ALLEN BOLT-LARGE (1/4" x 1-1/2"L - BLK) 10PCS 4PCS ALLEN BOLT-SMALL (1/4" x 1"L - BLK) PLASTIC END CAP (19 x 13H mm - BLK) 6PCS BOLT (Φ23mm x 1/4 x 1-1/4"L - BLK) 2PCS END CAP (12L x 10H mm - BLK) 2PCS PLUG (3/4"... - Page 4 2734 ITEM: ASSEMBLY INSTRUCTIONS STEP 2 VANITY STEP 1 STEP 3 COMPLETE PAGE 4 OF 6 COASTERFURNITURE.COM...
- Page 5 2734 ITEM: ASSEMBLY INSTRUCTIONS STEP 5 STOOL STEP 4 STEP 6 STEP 7 COMPLETE COMPLETE PAGE 5 OF 6 COASTERFURNITURE.COM...
- Page 6 2734 ITEM: 624mm (24.5”) 325mm (12.75”) 1410mm (55.5”) 130mm (5”) 589mm (23”) 895mm (35.25”) 438mm (17.25”) 775mm (30.5”) 419mm (16.5”) 508mm 343mm (20”) (13.5”) PAGE 6 OF 6 Note : Dimension tolerance ±5% COASTERFURNITURE.COM...
