ASSEMBLY INSTRUCTIONS
REVISION 02/19
NOTES
BEFORE COMMENCING SHED ASSEMBLY, CHECK ALL PARTS.
DO NOT ASSEMBLE IN WINDY CONDITIONS
THE MANUFACTURERS CANNOT BE HELD RESPONSIBLE FOR ANY CONSEQUENCES DUE TO SHEDS THAT ARE NOT
INSTALLED PER INSTRUCTIONS OR FOR DAMAGE DUE TO WEATHER CONDITIONS, ACTS OF GOD OR FOR SHEDS THAT
ARE LEFT PARTIALLY ASSEMBLED OVERNIGHT. PARTS MAY CONTAIN SHARP EDGES & CORNERS. CARE MUST BE TAKEN
WHEN HANDLING VARIOUS PIECES TO AVOID A MISHAP, FOR SAFETY SAKE, PLEASE USE A PAIR OF WORK GLOVES, EYE
PROTECTION & PROTECTIVE CLOTHING WHEN ASSEMBLING OR PERFORMING ANY MAINTENANCE ON THE BUILDING.
Subject to changes © STEEL SHEDS AUSTRALIA PTY LIMITED
W 1410mm x D 1070 mm x H 1480mm(Rear) x H 1265mm(Front)
UTILITY STORAGE UNIT-S43
READ INSTRUCTIONS FIRST
1
ST
2 PERSON ASSEMBLY
Advertisement
Related Manuals for FASTTRAK UTILITY STORAGE UNIT-S43
Summary of Contents for FASTTRAK UTILITY STORAGE UNIT-S43
- Page 1 UTILITY STORAGE UNIT-S43 ASSEMBLY INSTRUCTIONS REVISION 02/19 W 1410mm x D 1070 mm x H 1480mm(Rear) x H 1265mm(Front) NOTES BEFORE COMMENCING SHED ASSEMBLY, CHECK ALL PARTS. DO NOT ASSEMBLE IN WINDY CONDITIONS READ INSTRUCTIONS FIRST 2 PERSON ASSEMBLY THE MANUFACTURERS CANNOT BE HELD RESPONSIBLE FOR ANY CONSEQUENCES DUE TO SHEDS THAT ARE NOT INSTALLED PER INSTRUCTIONS OR FOR DAMAGE DUE TO WEATHER CONDITIONS, ACTS OF GOD OR FOR SHEDS THAT ARE LEFT PARTIALLY ASSEMBLED OVERNIGHT.
- Page 3 PRODUCT ID Length 363mm Quantity Description: Front Wall Top Channel...
- Page 4 PRODUCT ID Length 1175mm Quantity Description: Roof Holder (30x30 or 20x30 Angle)
- Page 5 Phillips Head Bit...
-
Page 6: Parts List
PARTS LIST Quantity Quantity Description: Description: Plastic Washer and Screw Cap Sheet Hinges FOUNDATION Recommended edge thickening Recommended slab rebate detail Although not required, it is strongly recommended that, to avoid water leakage around the base of your shed, a rebate be cast into the slab. This will allow the shed to sit below the slab level and prevent water from reaching the upper level of the slab. - Page 8 May need to stretch or press sheeting to align screw holes together Outside T emp Corner s crews to help Ensure that the small lip of the channel is to the w ith building outside of the shed. Large Rib Small Rib Fit the top and bottom channel and door jambs to the wall panels.
- Page 9 May need to stretch or press sheeting to align screw holes together Outside Ensure that the small lip of the channel is to the outside of the shed. Large Rib Small Rib Fit the door jambs to the wall panels. **Cut 2 of the plastic corner cap to the size of...
- Page 13 Rear side D o not Screw W here marked w ith Attach the channel “S” to the rear side and secure it with 3 screws leaving the corners as shown. Align the other “S”channel at front, do not screw yet (refer next page). outside Lay the Lid panels out with the large rib overlapping the small.
- Page 14 Rear side Do not screw yet Place the front gutter trim “V” on top of the channel “S” and secure it by screwing 3 middle holes as shown with the mark ” “ Make sure the screws are securing the Trim through channel “S” and to the sheeting. Do not screw where it marked with “...
- Page 16 Now screw the angle “T” to rear wall top channel Use the pre drilled holes on top and sides Make sure you do not screw the holes for fixing 4 Hinges later.
- Page 17 Use pre punched holes to screw through Make sure to place the hinges 15mm above the bottom edge of the angle T. Fix the Hinges as shown take this dimensions as reference (these dimensions are approximate)
- Page 19 LID PANEL Now place the gutter trim “V” at the rear side of shed as shown. Fix this Angle “V” through the sheeting in 3 places (Remove the screws previously fixed). Now Slide the Angle “W” underneath the front and rear Angle “V”.
- Page 20 Slide the Bracket assembly between the channel “O” and the wall Sheet. Keep 110mm away from edge. L L L O L L L X...
- Page 33 Warranty does not cover damage caused by storms, wind, rain, hail, snow or any other adverse environmental event or ”act of god" ® Warranty only applies if the shed is used solely for domestic purposes and installation is in accordance and compliance with the FASTTRAK instruction manual and manufacturer recommendations.
-
Page 34: Owners Details
Please attach here a photocopy of proof of purchase Retain the original for your records You must submit your warranty registration certificate within 60 days of the purchase date of your FASTTRAK® garden shed. Post your certificate and supporting documentation to: Australia... - Page 35 NOTE: PAGE 35...
- Page 36 · &...
