FASTTRAK SPACEMAKER F64-D Assembly Instructions Manual

Hide thumbs

Advertisement

Table of Contents

SPACEMAKER F64-D
REVISION 10-14
How to build Video
NOTES
BEFORE COMMENCING SHED ASSEMBLY, CHECK ALL PARTS. IF THERE IS A DISCREPANCY, PLEASE CALL
SPANBILT (SEE REAR OF INSTRUCTION BOOK)
DO NOT ASSEMBLE IN WINDY CONDITIONS
THE MANUFACTURERS CANNOT BE HELD RESPONSIBLE FOR ANY CONSEQUENCES DUE TO SHEDS THAT ARE NOT
INSTALLED PER INSTRUCTIONS OR FOR DAMAGE DUE TO WEATHER CONDITIONS, ACTS OF GOD OR FOR SHEDS THAT
ARE LEFT PARTIALLY ASSEMBLED OVERNIGHT. PARTS MAY CONTAIN SHARP EDGES & CORNERS. CARE MUST BE TAKEN
WHEN HANDLING VARIOUS PIECES TO AVOID A MISHAP, FOR SAFETY SAKE, PLEASE USE A PAIR OF WORK GLOVES, EYE
PROTECTION & PROTECTIVE CLOTHING WHEN ASSEMBLING OR PERFORMING ANY MAINTENANCE ON THE BUILDING.
Subject to changes © Versatile Buildings (Australia) Pty. Ltd.
Subject to changes © SPANBILD PTY LIMITED
ASSEMBLY
INSTRUCTIONS
W2105mm x D1410mm x H1800mm
READ INSTRUCTIONS FIRST
1
ST
2 PERSON ASSEMBLY

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPACEMAKER F64-D and is the answer not in the manual?

Questions and answers

Related Manuals for FASTTRAK SPACEMAKER F64-D

Summary of Contents for FASTTRAK SPACEMAKER F64-D

  • Page 1 SPACEMAKER F64-D ASSEMBLY INSTRUCTIONS REVISION 10-14 How to build Video W2105mm x D1410mm x H1800mm NOTES BEFORE COMMENCING SHED ASSEMBLY, CHECK ALL PARTS. IF THERE IS A DISCREPANCY, PLEASE CALL SPANBILT (SEE REAR OF INSTRUCTION BOOK) DO NOT ASSEMBLE IN WINDY CONDITIONS...
