User Manual
Better Geiger
Radiation Detector
Model S-2
www.bettergeiger.com
1. Warnings
Any use of the device not in accordance with this user guide voids
any applicable warranty. There is no guarantee of performance
specifications, accuracy, or reliability. Battery terminals and
compartments should be kept clean, dry, and free of debris. Batteries
should be removed for long-term storage of the detector. Unless
authorized by the manufacturer, enclosure screws should not be
removed, and internal components should not be modified or
accessed.

Advertisement

loading
Need help?

Need help?

Do you have a question about the S-2 and is the answer not in the manual?

Questions and answers

Related Manuals for Better Geiger S-2

Summary of Contents for Better Geiger S-2

  • Page 1 User Manual Better Geiger Radiation Detector Model S-2 www.bettergeiger.com 1. Warnings Any use of the device not in accordance with this user guide voids any applicable warranty. There is no guarantee of performance specifications, accuracy, or reliability. Battery terminals and compartments should be kept clean, dry, and free of debris.
  • Page 2 2. General Information “Dosimetry” means measuring radiation levels specifically in the context of human health effects. The Better Geiger S-2 uses a solid scintillator sensor primarily designed to measure radiation dose rate. Except for very specialized applications, dosimetry only involves X- ray/gamma measurement and not alpha/beta measurement because alpha/beta radiation is typically not an external hazard.
  • Page 3 3. Technical Specifications Best estimates subject to change (10 µSv/hr = 1 mrem/hr) • Power supply: 2x AA batteries, accepts all standard types including rechargeable, typical life >50 hours in normal display modes, >95 hours in dark mode • Minimum sensitive energy: 50 keV •...
  • Page 4 4. Basic Operation Buttons: The device has six buttons. The top left controls power on/off. The top middle cycles through display modes. The top right turns the clicking sound on and off. The bottom middle is used to access detector settings. Other button functionality is explained on the display when appropriate.
  • Page 5 Alarms: One alarm is “rate” alarm and will be triggered when the dose rate goes above a given threshold. The “rate” alarm will beep until confirmed by pressing the > button. If the rate drops below the alarm threshold and then goes back above it, the alarm will trigger similarly again.
  • Page 6 5. Display Modes Mode 1: Top line shows BATT:OK to indicate that battery status. The top right indicates ALARM: then RATE/SUM/NONE/BOTH depending on which alarm(s) are active. The lower left indicates qualitative dose rate RANGE (“NORMAL”, “HIGH”, or “DANGER”). Bottom right indicates unit of µSv/hr and main number on display shows dose rate.
  • Page 7 6. Understanding Display Numbers Counts per minute (CPM) gives the raw rate of detected interactions in the scintillator. Incoming X-ray/gamma photons can have higher or lower energies, but the CPM value only counts interactions. Radiation dose is a unit related to the health effect on the human body of radiation.
  • Page 8 All people are exposed to background radiation from natural and unnatural sources. The amount can vary widely but 2,000-3,000 µSv per year is common. At the time of writing this document, in the US the annual whole-body limit allowed for workers exposed to radiation is 50,000 µSv.
  • Page 9 7. General Tips To measure general X-ray/gamma dose rate levels in a uniform radiation field, the detector orientation is typically not important. If there is a strong point-like radiation source then the detector response will strongly depend on distance from the source. This is because the intensity of a radiation field coming from an X- ray/gamma source tends to decrease roughly according to I=1/D where “I”...
  • Page 10 10. FCC User Guide Statement NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 11: Declarations Of Conformity

    11. Declarations of Conformity FCC Supplier's Declaration of Conformity 47 CFR § 2.1077 Compliance Information Product Name: Better Geiger S-2 Radiation Detector Product Model Number: S-2 Description: Handheld portable radiation measurement device Responsible Party: www.bettergeiger.com This device complies with the following regulations: 47 CFR Part 15, Subpart B –...
