Rheem RGEA16 Installation Instructions

INSTALLATION INSTRUCTIONS
WHITE RODGERS TWO-STAGE
VALVE WITH DIRECT SPARK IGNITION
BEFORE INSTALLING THIS KIT, CHECK THE "CONVERSION KIT INDEX" (92-21519-47) TO BE SURE YOU
HAVE THE RIGHT KIT FOR THE FURNACE MODEL YOU ARE CONVERTING.
Installation Instructions
Conversion Label
WR LP Conversion Kit 92-1008
Orifice - Burner (#55)
Orifice - Burner (#56)
Recognize this symbol as an indication of Important Safety Information!
WARNING
THESE INSTRUCTIONS ARE INTENDED AS AN AID TO QUALIFIED, LICENSED SERVICE PERSONNEL FOR PROP-
ER INSTALLATION, ADJUSTMENT AND OPERATION OF THIS UNIT. READ THESE INSTRUCTIONS THOROUGHLY
BEFORE ATTEMPTING ANY MAINTENANCE OR OPERATION. FAILURE TO FOLLOW THESE INSTRUCTIONS CAN
RESULT IN IMPROPER INSTALLATION, ADJUSTMENT, SERVICE OR MAINTENANCE RESULTING IN FIRE, ELEC-
TRICAL SHOCK, CARBON MONOXIDE POISONING, EXPLOSION, PROPERTY DAMAGE, PERSONAL INJURY OR
DEATH.
FOR CANADIAN INSTALLATIONS, THE CONVERSION SHALL BE CARRIED OUT BY A MANUFACTURER'S
AUTHORIZED REPRESENTATIVE, IN ACCORDANCE WITH REQUIREMENTS OF THE MANUFACTURER, PROVIN-
CIAL OR TERRITORIAL AUTHORITIES HAVING JURISDICTION AND IN ACCORDANCE WITH THE REQUIREMENTS
OF THE CAN/CGA-B149.1 OR CAN/CGA-B149.2 INSTALLATION CODES.
IMPORTANT: DAMAGE TO THE PRODUCT RESULTING
FROM FAILURE TO FOLLOW INSTRUCTIONS OR USE OF
UNAUTHORIZED PARTS MAY BE EXCLUDED FROM THE
MANUFACTURER'S PRODUCT WARRANTY COVERAGE.
IMPORTANT NOTE FOR ALTITUDES ABOVE 2,000 FEET:
The main burner orifices in this kit are sized for nameplate
input and intended for installations at elevations up to 2,000
feet only. For elevations above 2,000 feet, the burner orifices
must be sized as shown in Chart
21519-47.
Heating Value of Gas ( TU/Ft
Input TU/HR =
Time in Seconds (for 1 cu.ft.) of Gas
In USA: All gas piping must comply with the latest NFPA 54
National Fuel Gas Code and all state and local codes. All elec-
trical wiring must comply with the latest NFPA 70, National
Electrical Code and all state and local codes.
RGEA16 GAS FURNACE
RXGJ-FP35
TO CONVERT FROM NATURAL TO LP GAS
USE KIT NUMBER FP35 (US/CANADIAN)
DESCRIPTION
in Conversion Kit Index 92-
3 ) x 3600 x correction factor
PARTS LIST
PART NUMBER
92-22999-106
92-18153-05
60-21193-06
62-21551-55
62-21551-56
In Canada: All gas piping must comply with the latest CAN1-
B149-1 & 2 installation codes for gas burning appliances and
all provincial and local codes, Part1-CSA Standad C22.1 and
all provincial and local codes.
WHEN CONVERTING NOx MODELS
WARNING
TURN OFF ELECTRICAL POWER AND MAIN GAS SUPPLY
BEFORE BEGINNING MODIFICATION. FAILURE TO DO
SO CAN RESULT IN ELECTRICAL SHOCK OR EXPLO-
SION CAUSING PROPERTY DAMAGE, PERSONAL
INJURY OR DEATH.
This furnace does not require the stainless steel inserts locat-
ed in the burner tube in order to meet SCAQMD Nox emission
levels when run on LP gas. Carefully remove these inserts and
retainer plate before firing this furnace on LP gas.
FP35
1
1
1
5
5
92-22999-106-01
SUPERSEDES 92-22999-106-00
