- Page 1 Installation Manual b.safe Direct Filling System b.safe Direct Filling System A product brand of Bohlender...
-
Page 2: Table Of Contents
Content Scope of delivery Assembly of the b.safe Direct Filling System 3-12 Functional test Information about the b.safe Mini-Display Declaration of Conformity b.safe Mini-Display Information about the b.safe Isolated Amplifier Note: Please read all the following Information carefully before starting the Installation. We urge you to follow the Installationsequence and the corresponding Instructions. -
Page 3: Scope Of Delivery
Scope of delivery b.safe Funnel 130 made of static dissipative PE-EX with GL 45 cap, hinged lid and sieve b.safe Mounting for Extraction bell level sensor, vent hose and collecting vessel b.safe Telescopic disposal tube made of stainless steel for working height 90 cm with lock nut, canister lid, capacitive fill b.safe Mini-Display Wall (1 channel) -
Page 4: Assembly Of The B.safe Direct Filling System
Assembly of the b.safe Direct Filling System Place the Safety-Storage-Cabinet in front of the final Position. Insert the supplied Marking-Aid with the Pin, onto the Hole in the Fire-Protection-Bushing on top of the Cabinet. Slide the Safety-Storage-Cabinet under the Worktop into the final Position. - Page 5 Center the Hole in the Tabletop with a Ø 40 mm core Drill-Bit and drill the necessary Opening required for the subsequent Feed-through of the telescopic Waste-Pipe into the Safety- Storage-Cabinet. Ø40 mm Define the Position of the Mini Display on the Front near the Safety-Storage-Cabinet.
- Page 6 Pull out the “Sensor Out” Sensor Cable from the on the Rear of the Safety-Storage-Cabinet mounted isolated Sensor Cable Amplifier through the Mounting-Opening for the Mini Display. Connect the Signal Cable to the Sensor-Connection of the Mini Display. Carefully insert Sensor 1, then screw it in.
- Page 7 Make a Function Test on the Mini Display. If Power Cable and Signal Cable are connected, the LED lights up green continuously and Installation can be continued. If the LED does not light up, check the Power Connection. If the LED is red and the Alarm sounds the Signal Cable is not connected correctly or is defective.
- Page 8 Tighten the fastening Screws until you feel Resistance and the Mini Display is firmly attached to the Wall. Glue the Covers of the fastening Screws at the Cutouts provided. b.safe...
- Page 9 For the Ventilation of the Waste Canisters, a corresponding Hose is mounted at the Rear of the Safety-Storage-Cabinet, which still needs to be connected to an Extraction System. When you connect the the Safety-Storage-Cabinet directly to an Extraction System via the rear ventilation Connection, we recommend to drill a Ø...
- Page 10 Guide the telescopic Waste Pipe from above through the the Tabletop and the Fire-Protection-Bushing into the Safety- Storage-Cabinet. Remove the protective Film from the Sealing Ring and stick it onto the Tabletop. protective Film Pay attention to the Position of the Surface in Relation to the Edge of the Table.
- Page 11 Screw the Funnel onto the Connection Thread on the telescopic Waste Pipe. Open the Door of the Safety-Storage-Cabinet. Slide the Holder for the Drip Tray from below onto the telescopic Thread Waste Pipe up to the Cabinet Wall and secure it with two Clamping Nuts on the Thread of the telescopic Waste Pipe.
- Page 12 Spread slightly Fastening of the Canister Cover: Guide the Canister Cover (pre-mounted in the Safety-Storage-Cabinet) to the Holding Arm on the Drip Tray. Use a Screwdriver to slightly open the Holder as shown. From below, push the Sensor on the Cover (blue Cable) through the corresponding Hole on the Holding Arm.
- Page 13 Move the telescopic Waste Pipe to the lower Position. Now attach the Earthing Cable to the Earthing Connection on the Wall of the Safety-Storage-Cabinet. Open one of the Waste Canisters supplied and place it on the left-hand side of the Drawer. This Canister is filled after Commissioning.
-
Page 14: Functional Test
Functional test Move the telescopic Waste Pipe several times from Top to Bottom. The telescopic unit must be inserted and removed without resistance. Filling the Canister Move the telescopic Waste Pipe downwards and lock it to the Table Top by tightening the fixing Screw. Open the Funnel and pour approx. -
Page 15: Information About The B.safe Mini-Display
Information about the b.safe Mini-Display Scope of Delivery Taking into Operation b.safe Mini-Displays are delivered ready for Power Supply installation in the variants built-in or stand-alone. Connect the power supply unit supplied with Each variant is available with 1 channel or 2 channels. the b.safe Mini-Display to a suitable socket and The suitable power plug and various primary plugs prepare the cable for installation. - Page 16 Mini - Display Wall Cat.No. R 658-01/02/03/04 The manufacturer / distributor Bohlender GmbH • Waltersberg 8 • 97947 Grünsfeld • Germany declares that the products fulfil the provisions of EMC Directive 2014/30EU Electromagnetic Compatibility. Low Voltage Directive 2006/95/EG has been complied with according to2006/42/EG in view of its protection targets.
-
Page 17: Information About The B.safe Isolated Amplifier
Information about the b.safe Isolated Amplifier Scope of Delivery Taking into Operation The b.safe Isolated Amplifier is delivered ready for Plug the power supply into a suitable power socket. With the included installation in a plastic housing that protects against accidental contact of live contacts. - Page 18 Better b.safe Sophisticated Sophisticated Safety Solutions Safety Solutions for HPLC. for HPLC. www.bsafe.de +49 (0) 93 46-92 86-0 Bohlender GmbH · Waltersberg 8 · 97947 Grünsfeld · Germany...
