b.safe
Installation Manual
b.safe Mini-Display
A product brand of Bohlender
b.safe
b.safe
Mini-Display Wall
Mini-Display Wall
Mini-Display Wall
Cat.No.:
Cat.No.:
R 658-01 / R 658-02
R 658-01 / R 658-02
R 658-01 / R 658-02
R 658-03 / R 658-04
R 658-03 / R 658-04
R 658-03 / R 658-04
b.safe
b.safe
b.safe
Mini-Display Table
Mini-Display Table
Cat.No.:
Cat.No.:
R 659-01 / R 659-02
R 659-01 / R 659-02
R 659-01 / R 659-02
R 659-03 / R 659-04
R 659-03 / R 659-04
Advertisement
Table of Contents
Summary of Contents for BOHLENDER BOLA b.safe Mini-Display R 658-01
- Page 1 R 658-03 / R 658-04 b.safe b.safe b.safe Mini-Display Table Mini-Display Table Cat.No.: Cat.No.: R 659-01 / R 659-02 R 659-01 / R 659-02 R 659-01 / R 659-02 R 659-03 / R 659-04 R 659-03 / R 659-04 A product brand of Bohlender...
-
Page 2: Table Of Contents
content Scope of Delivery Functionality Compatibility Safety Information Taking into Operation Installation information Installation instructions Connection of b.safe Waste Caps with main alarm, 1-channel Connection of b.safe Waste Caps with main alarm, 2-channel Connection of b.safe Waste Caps DLC with pre and main alarm Connection of b.safe Waste Caps with main alarm, 2-channel + Splitter More b.safe products Declaration of Conformity... -
Page 3: Scope Of Delivery
Scope of Delivery Safety Information b.safe Mini-Displays are delivered ready for Sensors used in explosion-hazardous areas installation in the variants built-in or stand- (EX zone) generally have to be secured alone. Each variant is available with 1 channel or with an additional isolated amplifi er 2 channels. -
Page 4: Taking Into Operation
Taking into Operation Power Supply Connect the b.safe Mini-Display with the included power plug to a suitable socket. Input Output - AC 100 bis 240 V - 24 V - Alternating voltage 50-60 Hz - Direct current - 1 A Option: Connection of sensors via isolated amplifi... -
Page 5: Installation Information
Installation information min. 35 mm Ø 68 mm For the installationof the b.safe Mini-Display a The mounting hole must have a diameter of 68 mm minimum installation depth of 35 mm is needed. min. 1 mm max. 26 mm You can install the b.safe Mini-Display in wall thicknesses between 1 mm and 26 mm... -
Page 6: Installation Instructions
Installation instructions Tools required: cavity wall drill, Phillips screwdriver, spirit level, pencil Ø 68 mm ATTENTION! Note cable! Mark the hole with a diamter of 68 mm and drill Pull the cables that are ready behind the wall through the hole using a cavity wall drill the hole to the front. - Page 7 ATTENTION! ATTENTION! do not crush the cable! tigthen the screws by hand! Push the box of the b.safe Mini-Display into the hole Align the b.safe Mini-Display using a spirit level and carefully tighten the screws (hand-tight) until it rests on the wall using a hand screwdriver.
-
Page 8: Connection Of B.safe Waste Caps With Main Alarm, 1-Channel
Connection of b.safe Waste Caps with Main alarm, 1-channel b.safe Mini-Display Wall 1-channel (Cat. No. R 658-01) Insert carefully the sensor 1, then screw together. Next connect Sensor surface the power cable. (Snooze/Reset) Sensor-LED (main alarm) Power supply 24V Sensor (main alarm) b.safe Mini-Display Table 1-Kanal (Cat. -
Page 9: Main Alarm
Main alarm (Cat. No. R 658-01, R 659-01) Neutral state As soon as the b.safe mini display is supplied with power and the sensors are connected, the respective sensor LED lights up in GREEN. Alarm state If a signal is recognized at sensor entry 1, the sensor LED changes from green to a fl... -
Page 10: Connection Of B.safe Waste Caps With Main Alarm, 2-Channel
Connection of b.safe Waste Caps with main alarm, 2-channel b.safe Mini-Display Wall 2-channel (Cat. No. R 658-02) Insert carefully the sensor 1 + 2, then screw together. Next connect Sensor surface the power cable. (Snooze/Reset) Sensor-LED 2 (main alarm) Sensor-LED 1 (main alarm) Power supply 24V Sensor 1 (main alarm) Sensor 2 (main alarm) - Page 11 Main alarm (Cat.No. R 658-02, R 659-02) Neutral state As soon as the b.safe mini display is supplied with power and the sensors are connected, the respective sensor LED lights up in GREEN. Alarm state If a signal is recognized at sensor entry 1 and/or 2, the sensor LED changes from green to a fl...
- Page 12 Connection b.safe Waste Caps DLC with per- and main alarm b.safe Mini-Display DLC Wall 1-channel (Cat. No. R 658-03) Insert carefully the sensor PRE and MAIN, then screw together. Sensor surface Next connect (snooze/reset) the power cable. MAIN Sensor-LED (main alarm) PRE Sensor-LED (pre alarm) Power supply 24V...
- Page 13 Pre- and main alarm (Cat. No. R 658-03, R 659-03) Neutral state As soon as the b.safe mini display is supplied with power and the sensors are connected, the respective sensor LED lights up in GREEN. Alarm state Pre alarm: If a signal is recognized at sensor entry PRE, the sensor LED changes from green to a fl...
-
Page 14: Connection Of B.safe Waste Caps With Main Alarm, 2-Channel + Splitter
Connection of b.safe Waste Caps with main alarm, 2-channel + splitter mode b.safe Mini-Display Splitter Wall 2-channel (Swivel left, swivel right) (Cat. No. R 658-04) Insert carefully the sensors Sensor surface 1 + 2 and the (Snooze/Reset) splitter left and right, then screw together. - Page 15 Main alarm in splitter mode (Cat.No. R 658-04, R 659-04) Neutral state As soon as the b.safe mini display is supplied with power and the sensors are connected, the respective sensor LED lights up in GREEN. Alarm state Main alarm sensor 1 (left) If a signal is present at sensor entry Sensor 1, the sensor LED changes from green to a fl...
-
Page 16: Cat. No
More b.safe Products b.safe Signal Cables Cat. No. Cat. No. Cat. No. R 645-02 2 m length R 644-07 0,3 m length R 643-12 2 m length R 645-03 3 m length R 644-12 2 m length R 645-05 5 m length R 645-10 10 m length b.safe Isolated Amplifi... -
Page 17: Declaration Of Conformity
Mini D isplay Wall Cat. No. R 658-01/02/03/04 The manufacturer / distributor Bohlender GmbH • Waltersberg 8 • 97947 Gruensfeld • Germany declares that the products fulfi l the provisions of EMC Directive 2014/30EU Electromagnetic Compatibility. Low Voltage Directive 2006/95/EG has been complied with according to2006/42/EG in view of its protection targets. - Page 18 +49 (0) 93 46-92 86-0 www.bsafe.de +49 (0) 93 46-92 86-0 Bohlender GmbH · Waltersberg 8 · 97947 Grünsfeld · Germany Bohlender GmbH · Waltersberg 8 · 97947 Grünsfeld · Germany Bohlender GmbH · Waltersberg 8 · 97947 Grünsfeld · Germany...
