Lucci Fresco SOUTHAMPTON 231232 Installation Instructions

Installation Instructions
Thank you for purchasing this quality Lucci product. To ensure correct function and safety, please read and follow all
instructions carefully before assembly, installation and use of this luminaire. Please keep instructions for future reference.
Warranty
• This luminaire is covered by a 12-month warranty. The warranty is from date of purchase, not the date of installation.
• If the luminaire is not assembled and installed by a licensed electrician, the warranty will be void.
• Please retain the proof of purchase and evidence of installation by a licensed electrician for any warranty enquiries.
• Warranty will be void if there is any damage due to improper usage or modification to the luminaire.
• Failure to comply with the instructions in this manual may increase the risk of damage or injury and will void the
warranty.
Installation Requirements
• This luminaire must be assembled and installed by a licensed electrician.
• All wiring and installation of the luminaire must adhere to the latest local and national wiring rules.
E.g. AS/NZS 3000 Electrical Installations.
• The luminaire is a Class I product and must be earthed during wiring and installation.
• This luminaire is rated IP23 or IP44, this must be maintained during wiring and installation of the luminaire.
NOTE:
This luminaire is rated IP23 when the bottom shade (I) is NOT installed.
This luminaire is rated IP44 when the bottom shade (I) is fully installed.
• Do not exceed the maximum wattage rating.
• The luminaire must not be used if the protective shield or shade has been cracked or damaged. Replace the protective
shield or shade before using the luminaire.
• Select a suitable location for installation:
−
The mounting point must be able to support 2 times the weight of the luminaire.
−
This luminaire is rated against water penetration to IP23 standards when the bottom shade (I) is NOT installed,
which is spraying water at and angle of up to 60°.
−
This luminaire is rated against water penetration to IP44 standards when the bottom shade (I) is fully installed,
which is water splashing from any direction.
• Take care not to pull any electrical wires during unpacking as this may damage the connection.
• Lay out all the components on a smooth surface and make sure no components are missing before assembling.
If parts are missing, return the complete product to the place of purchase for inspection or replacement.
• Check whether the luminaire has been damaged during transport. Do not operate/install any product which appears
damaged in any way. Return the complete product to the place of purchase for inspection, repair or replacement.
• Ensure power to the circuit you are working on has been switched OFF before commencing any electrical work.
1 | P a g e
SOUTHAMPTON EXTERIOR WALL SCONCE
SKU# 231232
Rated Voltage 220-240V~ 50Hz
v 1 . 1 ( 0 8 / 2 0 2 1 )
