INSTALLATION, OPERATION AND
MAINTENANCE INSTRUCTIONS
3035443
IAS 9-90:1991 Gas-Fired, Desiccant Type Dehumidifiers and Air Conditioners
Gas Unit Heaters, Gas Packaged Heaters, Gas Utility Heaters, And Gas-Fired Duct Furnaces
Gas Unit Heaters, Gas Packaged Heaters, Gas Utility Heaters, And Gas-Fired Duct Furnaces
Gas-Fired Central Furnaces [ANSI Z21.47:2021 Ed.7]
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious injury,
death or property damage.
Be sure to read and understand the installation, operation and service
instructions in this manual.
Improper installation, adjustment, alteration, service or maintenance can
cause serious injury, death or property damage.
Do not store or use gasoline or other flammable vapors and liquids in the
vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
·
·
·
·
·
Installation must be performed by a qualified installer, service agency or gas
supplier
This manual must be kept with the appliance for future reference.
Manufactured by
Heatco Inc
50 Heatco Court
Cartersville, Ga. 30120
HP SERIES
AIR HEATER MODULE
[ANSI Z83.8:2016 Ed.6]
[CSA 2.6:2016 Ed.6]
Gas-Fired Central Furnaces [CSA 2.3:2021 Ed.7]
WARNING:
!
Do not try to light any appliance
Do not touch any electrical switch; do not use any phone in your building
Leave the building immediately
Immediately call your gas supplier from a phone remote from the
building. Follow the gas supplier's instructions.
If you cannot reach your gas supplier, call the fire department.
.
MP5157
HP-MAN-E-2024-7
Advertisement
Table of Contents
Related Manuals for heatco HP Series
Summary of Contents for heatco HP Series
- Page 1 INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS HP SERIES AIR HEATER MODULE 3035443 MP5157 IAS 9-90:1991 Gas-Fired, Desiccant Type Dehumidifiers and Air Conditioners Gas Unit Heaters, Gas Packaged Heaters, Gas Utility Heaters, And Gas-Fired Duct Furnaces [ANSI Z83.8:2016 Ed.6] Gas Unit Heaters, Gas Packaged Heaters, Gas Utility Heaters, And Gas-Fired Duct Furnaces [CSA 2.6:2016 Ed.6]...
-
Page 2: Table Of Contents
Listing Considerations HP Series Modules are listed by both Intertek Testing Services (ITS / ETL) and Underwriters Laboratories (UL). For Installation in Desiccant Dehumidification Systems on the positive or negative side of the circulating air fan. This Product is intended for installation by Original Equipment Manufacturers of Listed Heating Equipment in Duct or Cabinet mounted Applications. -
Page 3: Furnace Module Ratings
Table 1 – Furnace Module Ratings Min. Air Flow @ Model Input Min. Duct Min. Clearances to Tube Depth Duct Output Temp Rise Min. Duct Rate Opening duct from tube. Area Opening Height Min. (No. of Min. Max. Bottom Rear Min. -
Page 4: Installation Codes
These units must be installed in accordance with local building codes, the National Fuel Gas Code (NFPA54 / ANSI Z223.1), or in Canada with the Canadian Natural Gas and Propane Installation Code (CSA B149.1). HP Series models are available for indoor and outdoor installations depending on configuration. The appliance must be properly located. - Page 5 A statement to cover replacement wiring “If any original wire supplied with the appliance must be replaced, it must F).” be replaced with a comparable wiring material having a temperature rating of at least 105 C (221 Required Marking WARNING label provided as required by Z83.8-CSA 2.6 Sections 4.31.7. must be attached to exterior of cabinet Attach Safe Lighting and Operation Label as required by Z83.8-CSA 2.6 Sections 4.31.5 provided in conspicuous place.
-
Page 6: Handling & Installation
6. Materials for flue venting that cannot withstand 480 F (249 C) should not be installed with the Heatco HP Series furnaces. 7. A condensate drain fitting is provided in the flue box. If module is located downstream of the cooling system, a drain tube must be connected to this fitting to drain condensate formed in tubes during air conditioning operation. -
Page 7: Furnace Module Application & Airflow Distribution
Furnace Module Application & Airflow Distribution All HP product series heaters ship standard with a heat exchanger sheet metal wrapper that defines the air tunnel clearances around the heat exchanger. If the air tunnel opening is larger than heater profile, provide panels that fasten to the heat exchanger sheet metal wrapper to block by-pass air and direct all airflow over the heat exchanger as shown in Figure 2 below. -
Page 8: Multiple Heaters Application
Figure 4 – Typical Negative Pressure Installation Airflow Proving Integral High Limit Auxiliary High AHU Cabinet Switch Switch Limit Switch Min. Inlet Discharge Temperature Temperature -40 oF 325 oF Max Rise = 125 oF Fan Sized on 36" Required cfm air min. -
Page 9: Outdoor Installations
The maximum temperature rise across any one unit in series must not exceed 125 F. This could cause nuisance safety trips or even failure of components. When installing units in series, the modulating unit should be located furthest downstream in the heating assembly. - Page 10 Pressure in the vent duct is positive up to the discharge opening and all vent connections in the vestibule area should have joints sealed to prevent leakage of flue gases into the combustion air supply. The vent discharge opening should be located to provide an unobstructed discharge to the outside and should be located as far from the combustion air inlet as possible but must always be located in the same pressure zone as the combustion air inlet.
-
Page 11: Indoor Installation
Figure 8 – Vertical Venting Field Starkap or equal listed Vent cap Field Starkap or equal listed Vent cap 12 in. Min 12 in. Min. 4 ft. Min. 4 ft. Min. 18 in. Min. Rectangular to Round adapter Rectangular to Condensate Cap T Round adapter... -
Page 12: Vertical Venting - Category
Table 2 – Vent Connector Diameter Gas Input (Btuh) Gas Input (W) Diameter of Flue Vent 50,000 – 149,999 21,980 – 43,958 5” (126 mm) 150,000 – 400,000 43,960 – 117,228 6” (152 mm) 401,000 – 500,000 117,229 – 146,536 7”... -
Page 13: Horizontal Venting - Category
Horizontally Vented Furnaces -Category III (See Figure 10) Vent pressures in horizontally vented furnaces are positive and therefore are classified as Category III venting systems in accordance with ANSI standards. Use only Category III vent materials listed to UL1738 / ULC S636 for vent pipe and fittings. -
Page 14: Separated Combustion Systems
Separated Combustion Systems HP furnace modules are not approved for separated combustion systems. Due to the high discharge air temperatures and internal furnace vestibule ambient temperatures, electrical component temperatures may exceed manufacturer’s recommendation. Contact factory with questions pertaining to separated combustion applications. Gas Supply, Piping and Connections 1. -
Page 15: Electrical Connections
WARNING ! WARNING ! 1. When pressure testing at ½ PSI or less, 1. All field gas piping must be pressure / close the manual shut-off valve on the leak tested prior to operation. NEVER appliance before testing. use and open flame to check for 2. -
Page 16: Start-Up
3. Use only hand force to push and turn the gas control knob to the “ON” position. NEVER use tools. If knob does not operate by hand, replace gas valve prior to starting the unit. Forcing or attempting to repair the gas valve may result in fire or explosion. - Page 17 Figure 13A – Honeywell VR8305Q Gas Valve Stage (Hi Fire) Manifold Stage (Lo Fire) Manifold Pressure Adjustment Pressure Adjustment (3/32” Allen Key) Electrical Connection Block 1/8” NPT Inlet Manual Shut-off Pressure Tap Control Knob Figure 13B – White Rodgers 36H Gas Valve 1/8”...
-
Page 18: Burner Flames
Figure 13D – White Rodgers 36H27 ModCombo Valve Burner Flames Prior to completing the start-up, check the appearance of the main burner flame. See Figure 14 below for flame characteristics of properly adjusted Natural gas systems. 1. The burner flame should be predominately blue in color, well defined, and centered at the tube entry as shown in Figure 14. -
Page 19: For Your Safety
FOR YOUR SAFETY The use and storage of gasoline or other flammable vapors and liquids in open containers in the vicinity of this appliance is hazardous. Controls Combustion Air Pressure Switch A combustion air pressure switch is provided as part of the control system to verify airflow through draft inducer by monitoring the difference in pressure between the draft inducer and the atmosphere. - Page 20 Figure 15 A19 Temperature Limit Control A19 Temperature Capillary Bulb ½ Button Temperature Limit High Limit Switch Mounting Bracket Temperature settings of the ½” Button Temperature Limit and the the A19 Temperature Limit Control are pre-set at the factory. Do not adjust A19 Temperature Limit Control in the field. Consult factory before adjusting limit(s).
-
Page 21: Optional Controls
Figure 16 – Auxiliary Limit & Airflow Probe – Suggested locations 6.00 " 3.00 " 6.00" Auxiliary Manual Reset Limit Airflow Air Probe Horizontal Air Flow Optional Controls Low Gas Pressure Switch A low gas pressure switch may be factory installed on the inlet side of the gas train to monitor gas pressure upstream of the gas controls. -
Page 22: Maintenance
Annual Maintenance This duct furnace should be inspected and serviced annually by a qualified service agency, to assure proper operation Furnace Module Inspection Turn off all electrical power to the unit before inspection and servicing. 1. The condition of the burners, heat exchanger, draft inducer, vent system and operating controls should be determined. - Page 23 (Page Left Blank) Heatco Inc. 50 Heatco Court Cartersville, Ga. 30120...
