- Page 1 IQTX Quick Start Guide quantifiphotonics.com...
- Page 2 • Clean connector fiber end-faces each time before connecting it to the instrument, and cover unused optical connectors with clean dust caps. Ensure the power isolation switch on the rear of the IQTX is turned OFF and connect the power cord.
- Page 3 Choose from programming tools such as LabView, C++, Python etc. to work with the instrument’s fully SCPI-compliant command set. For detailed information, refer to the IQTX User Manual included on the USB drive. Step 4. Operate your IQTX from the touchscreen The IQTX touchscreen provides controls for the installed lasers and modulator bias control, display settings and network settings.
- Page 4 ABC has locked, the laser power may be increased to the desired level. Step 6. Apply the RF signal Once the ABC has locked, connect the RF signal generator to the IQTX and turn the RF driving signal on. The peak-to-peak voltage amplitude of the driving signal should be set to below 1.8 x Vpi for QPSK signals, and around...
- Page 5 Test. Measure. Solve. Quantifi Photonics is transforming the world of photonics test and measurement. Our portfolio of optical and electrical test instruments is rapidly expanding to meet the needs of engineers and scientists around the globe. From enabling ground-breaking experiments to driving highly efficient production testing, you’ll find us working with customers to solve...
- Page 6 +1-800-803-8872 quantifiphotonics.com Quantifi Photonics Ltd © 2024. All rights reserved. No part of this publication may be reproduced, adapted, or translated in any form or by any means without the prior permission from Quantifi Photonics. All specifications are subject to change without notice. Please contact Quantifi Photonics for the latest information.
