- Page 1 EASYBIKE USER MANUAL AND WARRANTY CARD EASYBIKE MI5 STUDY CAREFULLY BEFORE DRIVING!
-
Page 2: Table Of Contents
1.YOUR NEW ELECTRIC BIKE.............................3 1.1. Home 1.2. General performance 2.WHEEL MAINTENANCE............................4 2.1. Settings 2.2. Safety instructions before driving 2.3. Rear wheel mounting and adjustment 2.4. Suspension fork 2.5. Driving in bad weather 3. ELECTROSADA ................................6 3.1. Batteries 3.1.1. Removing and installing the battery 3.1.2. -
Page 3: Your New Electric Bike
If any changes are made to the EasyBike without the prior consent of AutoKelly otherwise polluting your surroundings. a.s., this declaration shall become void. -
Page 4: Wheel Maintenance
2.Service bikes 2.1.SEATING SETUP Saddle height adjustment Release the quick-release lever and adjust the seat height to the desired level. However, do not exceed the maximum extension level marked on the seat tube. Doing so could either damage the seat or to break out of the frame. After adjustment, reverse the lever to secure the quick release. -
Page 5: Rear Wheel Mounting And Adjustment
Observe the rules of safe driving on roads laid down by generally binding legal regulations. Remember that a cyclist is a full-fledged road user who is subject to the same rules as the driver of a motor vehicle. The bicycle is equipped with reflective elements for daytime riding. -
Page 6: Driving In Bad Weather
2.5.RIDING IN BAD WEATHER In light rain, the ride doesn't matter. However, it is not advisable to leave or park your bike where it is not protected against rain, snow and sun. 3. Elektrosada 3.1. BATTERIES 36 V / 13 Ah, Li-Ion technology, Samsung cells 3.1.1. -
Page 7: Important Notices
IMPORTANT NOTICES! •Charge the battery in a dry environment to prevent damage from short circuits. •Charge the battery ideally once every 2 months, even when the bike is not in use, to at least 60% capacity. •Do not cover the battery or charger. Overheating could occur. •Do not leave the battery connected to electricity at all times. -
Page 8: Driving Distance Factors
3.1.5. DISTANCE FACTORS Tyre rolling resistance Correct tyre inflation is important. If you have under-inflated tyres on your e-bike, for example, your range will be reduced and there is a risk of a puncture. Weight of the electric bike The lower the weight of the e-bike, the longer the range. Battery status It depends on whether the battery was fully charged before the journey. -
Page 9: Control Display
3.2.Control display 3.2.1. BUTTON/FIELD LAYOUT DISPLAY The following indicators are Changing assistance - standard on the display when it's plus ON/OFF Changing switched on: cruising speed, assistance level indicator, battery indicators indicator, Change of assistance - minus distance and travel time display. - Page 10 1.Assistance level indicator 3.Error code To change the level of assistance, press the +/- buttons. Contact your distributor if you see it. The error message will The assist level can be set to 0-6 remain on the display until the fault is corrected. (0 - no assistance, 6 - highest possible level of assistance).
- Page 11 6.Distance and travel time display Press the SET button to switch between the ODO, Trip1, Trip2 and Time indicators. ODO - total distance travelled indicator. Trip1 - after 500 km, the display automatically resets to zero. Trip2 - shows the last distance travelled by the e-bike, to reset, long press the SET button. Time - displays the travel time, to reset press the SET button for a long time.
-
Page 12: Security Information
4.Security information 4.1.ENSURING SAFE OPERATION Conditions of operation The EasyBike Mi5 is designed for use on normal roads and light off-road terrain. It is not suitable for jumping or riding in water and is not equipped for heavy terrain. Helmet Always wear a protective bicycle helmet. -
Page 13: Maintenance
4.2. MAINTENANCE NOTICE Bike maintenance and repairs require specific experience and the right tools. Do not repair defects or make adjustments to the wheel if you have the slightest doubt about your ability to do the right thing. In this case, contact your dealer or a qualified service centre. Any repairs or adjustments that are not done properly may cause damage to the wheel or lead to injury. -
Page 14: Notice
4.3. NOTICE Do not lend an e-bike to persons who have not been instructed in its operation. Claims arising from improper handling will not be accepted. The e-bike should not be used by persons who are unable to pedal or handle it independently. The manufacturer is not responsible for any injury or damage to the e-bike! The ideal weather conditions for operating the e-bike are dry days when the outside temperature is above 10 °C. - Page 15 Frames: In particular, a frame breakage due to a manufacturing or material defect that exists, even hidden, at the time of acceptance of the product by the buyer may be recognized as a legitimate claim. In particular, any mechanical damage caused by an accident, a fall or unprofessional adjustments to the frame geometry shall be considered an unjustified claim.
- Page 16 Clicks: A legitimate complaint can be accepted as e.g. a broken crank due to poor casting, a loose converter on the crank, a bad hole including the thread on the crank, crooked converters. Routine clearance adjustments are not covered by the warranty. Here- formed threads on the crank caused by improper assembly and normal wear and tear of the gearboxes due to operation are considered as unauthorized claims.
- Page 17 Battery and charger: The battery is guaranteed for 12 months from the date of sale. For example, loss of battery capacity during the first year of use below 70% of the manufacturer's stated capacity may be accepted as a legitimate claim. The warranty does not cover defects caused by neglected maintenance and "undercharging"...
-
Page 18: Warranty Inspection
The voucher is then sent to the electric bike dealer. If the warranty inspection is not carried out within the above mentioned period, the warranty entitlement will expire. EasyBike e-bikes are subject to technical development, all information and images are subject to change without notice. 5.3.WARRANTY SHEET AUTO KELLY a.s.
