Bernette 502060 14 87 Manual

Pintuck Foot
1
www.bernette.com
5600005.00A.04 | 2022-05 EN
Information
Scope of delivery
• For b33/b35: Pintuck Foot with 5 grooves, for twin needles at widths
of 1.5 – 4.0 mm.
• For b37/b38: Pintuck Foot set, consisting of 1× Pintuck Foot with 5
grooves and 1× Pintuck Foot with 7 grooves, for twin needles at
widths of 1.6 – 6.0 mm.
Purpose
• For sewing even pintucks with the twin needle.
For your safety
Before using this accessory, please read this instruction manual as well
as the instruction manual of your machine carefully.
Application
Sewing Pintucks
> Fit the twin needle.
> Thread the needles according to the instructions.
> Fit the Pintuck Foot.
> Set the straight stitch with needle position to center.
> Set the stitch length to 2 – 3 mm.
> Set the optimal thread tension.
> Thread-up command.
> Sewing the first pintuck.
