Zigzag Foot with
Guide
1
E
10
3/8 1/2 5/8 3/4 7/8 1 9/8
2
www.bernette.com
5600001.00A.04 | 2022-05 EN
A
B
C
D
15
20
25
30
mm
inch
Information
Purpose
• To sew seams at an exact distance of up to 30 mm (9/8") from a
fabric edge or a seam that has already been sewn.
• Ideal for quilting parallel lines, for parallel decorative seams or
topstitching.
For your safety
Before using this accessory, please read this instruction manual as well
as the instruction manual of your machine carefully.
Markings
A Read mark mm
B Read mark inch
C Distance to the needle in mm
D Distance to the needle in inch
E
Center needle position
Application
How to adjust the spacing between the seams
> Push the lever upwards and slide the guide into the desired position.
(Fig. 2)
> To fix the position, lower the lever. (Fig. 2)
Advertisement
Related Manuals for Bernette 502060 14 90
Summary of Contents for Bernette 502060 14 90
- Page 1 Center needle position Application How to adjust the spacing between the seams > Push the lever upwards and slide the guide into the desired position. (Fig. 2) > To fix the position, lower the lever. (Fig. 2) www.bernette.com 5600001.00A.04 | 2022-05 EN...
- Page 2 > Place the fabric under the presser foot and align the fabric edge (A) or the already sewn seam (B) with the guide. (Fig. 3) > Lower the presser foot and sew, guiding the fabric along the guide. www.bernette.com 5600001.00A.04 | 2022-05 EN...
