11
1. When the temperature is too high, HI will be displayed in the temperature erea to express the
room temperature over the display range. When the temperature is too low, LO will be displayed
in the emperature erea to express the room temperature blow the display range.
2. Within 1hour after power off, time and week will keep running.
3. There is preservative on the LCD when out of the factory, users can remove it or not.
4. If you need to remove the preservative, just pull it from the corner and no need to open the thermostat.
5. Don't force to install. When it is hard to connect the pin, move the display panel slightly . After the
pin aimed at the port, press the thermostat hard.
6. It is precision electronic products. Don't knock or fall it.
7. Don't let the water, mud into the thermostat.
12
1. Please don't touch the screen when the oil or the water stainson your hands.
2. lf the screen is stained by water or dusty, it will reduce the .sensitivity, even result the touch screen
failure.
3. Please use the soft cloth to clean the touch screen.
4. Please don't operate the touch screen with hard objects, toprevent scratching the surface.
13
the display range of temperature.............44℉ to 90℉ ( 7℃ to 32℃)
the control range of temperature.............44℉ to 90℉ ( 7℃ to 32℃)
Load rating...............................................1 amp per terminal, 1.5 amp maximum all terminals combined
Display accuracy .....................................± 0.5℃
Power source...........................................18 to 30 VAC, NEC Class II, 50/60 Hz for hardwire (common wire)
Operating ambient....................................41℉ to +95℉(5℃ to +35℃)
Operating humidity....................................90% non-condensing maximum
Dimensions of thermostat.........................118mm*86mm*27mm
16
QD-HVAC15
WIFI
Notes for touch screen
Dear client:
Thanks for choosing QD-HVAC15 WIFI thermostat
series. It's our best wish to bring you convenience
for your daily life. Before using, please read the
User's Manual carefully. It will help you to use it
correctly.
Description
1 stage Heat and 1 stage Cool
Gas or Oil Heat
Electric Furnace
Heat Pump( NO Aux. or Emergency Heat)
Heat Only Systems
Heat Only Systems - Floor or Wall Furnaces
Cool Only Systems
Millivolt
Touch-Screen Progammable Thermostat
Be able to operate your air conditioner whenever
and wherever you are with your mobile phone.
Mobile phone control and suitable for Android
& IOS system.
Programmable thermostat
5+2 Programmable
Easy to program
Easy to install
7 square inch display
Full and touch screen
24V Hardwire
Operate on 1 stage Heat and 1 stage cool
Heat Pump without Aux or Emergency Heat
Separate heating and cooling swing(cyclerate)
adjustments
5 minutes compressor delay protection
(selectable on or off)
Gas, Electric or Oil
Optional temperature display of Fahrenheit or
Celsius scale.
Display temperature calibration
Download on the
App Store
GET IT ON
Google
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
play
