RANGEMASTER TREBLE BOOSTER We hope you enjoy your new RANGEMASTER TREBLE BOOSTER! In this manual, you will find documentation and guidelines helpful to put it together. Here we have put together a few links that detail some of the aspects explained in this manual and that we think you can find helpful: Kit &...
Page 3
RANGEMASTER TREBLE BOOSTER Bill Of Materials Resistors (4) 3.9k 470k Capacitors (4) 4.7n C2, C3 (electro) Transistors (1) Germanium Transistor Potentiometers BOOST 10kA (log.) Other (2) 1N4007...
Page 4
RANGEMASTER TREBLE BOOSTER Part Placement – Ubicación de componentes...
Page 5
RANGEMASTER TREBLE BOOSTER STEP BY STEP GUIDE...
Page 6
STEP 1 – Resistors and diodes Place the resistors and diodes. If you have troubles reading the values, check out our “Reading Part Values” tutorial. Resistors (31) 3.9k 470k Other (2) 1N4007...
Page 8
STEP 3 – Capacitors and Transistors Solder the capacitors and transistors. If you have troubles reading the values, check out our “Reading Part Values” tutorial. Pay attention to the orientation, as well as to the polarity for electrolytic capacitors. Capacitors (4) 4.7n C2, C3 (electro)
Page 9
NOTE: How to correctly place your Germanium Transistor All our Germanium Transistors are individually tested and hand- picked to guarantee that they have the optimal parameters for the Rangemaster. Nevertheless, due to availability we can’t always ensure the same model of transistor. Check your transistor model before placing it.
Page 10
STEP 4 – LED and Battery Clip Solder wires Then, solder then to the LED (the red connection (red to the “+” sign). wire is connected to the longer pin). Solder the battery clip, connecting the red wire to the “+” sign:...
Page 11
STEP 5 – DC Power Jack wires Solder three wires (about 5cm each) to the DC connection as shown (don’t solder anything to the other end yet!):...
Page 12
STEP 6 – Audio Jacks Now, solder the audio jacks to the board (DC, battery and led wires are not present to make it clearer):...
Page 13
STEP 7 – Potentiometers A – Preparing the potentiometers Cut 3 pieces of wire for each potentiometer you have to solder (i.e. 9 pieces for 3 potentiometers). Then, solder them to each lug. The first lug is the one in the left in top view (the black wire in the picture).
Page 14
The pin 1 is shown in the PCB, either as a dot or as a “1” number (left picture). If your board doesn’t specify a “1” or a dot, then the default 1 pins are being used. Below you can find the default pin 1 for our PCBs. You can solder the potentiometers from above or from below (which we prefer) depending on how you plan to build the pedal.
Page 15
Then, solder them to the board like in the picture in the left, and then place the board inside the enclosure:...
STEP 8 – DC Power Jack First of all, insert the DC jack in the enclosure and tighten the nut: Then, solder the three wires from the DC connector in the board to the DC jack as follows:...
Page 17
STEP 9 – 3PDT A – Solder the pin to the adapter B – Solder the 3PDT Pay attention, the pins and the 3PDT Now solder the 3PDT to the PCB and must be soldered to the same side of remove all the nuts but one, that should the PCB adapter (the one labeled be set at a middle height:...
Page 18
C – Solder the 3PDT directly to the board (optional) If you prefer to solder the 3PDT directly to the board, you can wire it as shown in the schematic. We recommend to use the provided 3PDT PCB adapter to make the soldering easier.
Page 19
STEP 10 – Connect the 3PDT STEP 11 – Your pedal is finished! By now you should have a fully functional effect pedal, we hope you enjoy it!
